Product catalog summary
Sample Preparation Overview
The document provides detailed information on various laboratory and field instruments for sample preparation, focusing on the DRB 200 Dry Thermostat Reactor, Digesdahl Digestion Apparatus, and distillation apparatuses.

DRB 200 Dry Thermostat Reactor
This reactor is designed for standard and special digestions, offering easy and fast operation with safety features. It accommodates various test vials and has an optional dual block for simultaneous digestions. The reactor heats from ambient to 150°C in less than 10 minutes and includes preprogrammed Hach procedures.

Specifications:
  • Temperature Range: 37 to 165°C
  • Timer Range: 0 to 480 minutes
  • Power: 100 to 240 Vac, 50/60 Hz
  • Compliance: CE, GS, cTUVus

Digesdahl Digestion Apparatus
This apparatus reduces digestion time to 10 minutes and eliminates the need for metal catalysts. It uses sulfuric acid and hydrogen peroxide for rapid digestion and is suitable for various elements like nitrogen, phosphorus, and metals.

Specifications:
  • Power: 115 or 230 Vac, 50/60 Hz
  • Weight: 3.85 kg

Distillation Apparatus
The document describes various distillation apparatus sets for different applications, including arsenic and cyanide determination. These sets are designed to meet EPA distillation requirements and include all necessary components for setup.

MICRO DIST System
This system offers a revolutionary approach to distillation, allowing for the processing of up to 21 samples in 30 minutes. It is EPA-approved for cyanide reporting in drinking water and wastewater.

Xenosep Oil and Grease System
The Xenosep SPE System provides an EPA-approved method for testing oil and grease using Method 1664A. It offers fast, reliable results and includes a training video for lab procedures.

Key Features:
  • Fast processing with minimal sample waste
  • No fume hood required for MICRO DIST
  • Cost-effective and easy to use
See more

Catalog excerpts

Sample Preparation-1

Sample Preparation See page 99. Lachat MICRO DIST now EPA approved for reporting of cyanide in drinking water and wastewater! ՕNEW Xenosep Oil and Grease System EPA-approved method! See page 100. ׅand Much More! >

 Open the catalog to page 1
Sample Preparation-3

Sample Preparation Cut digestion time to 10 minutes with the patented DigesdahlDigestion Apparatus. Use the Digesdahl to determine Kjeldahl nitrogen (crude protein), phosphorus, calcium, potassium, iron, copper, magnesium, manganese, lead, zinc, cadmium, and chromium in a variety of solid and liquid samples.The system uses sulfuric acid and concentrated hydrogen peroxideto rapidly digest organic materials. Quantitative dilution directly in the digestion flask allows fast preparation for analyses by photometric or other methods.A water aspirator purges reaction products. Each Digesdahl unit includes...

 Open the catalog to page 3
Sample Preparation-6

Pr Xenosep Solid-Phase Extraction (SPE) Systems offer the easiest andmost cost effective way to test for Oil and Grease using EPA Method 1664A. Fast, in-house results enable you to maintain control over your plant discharges in real time without the complications of the hexane LLE procedure. Xenosep SPE filters feature a unique triple layer that prevents premature clogging and flows 10 times faster than typical SPE filters. It is now possible to easily achieve reliable, consistent Oil and Greaseresults and decrease your sample turnaround time. A free training video on CD is included with each...

 Open the catalog to page 6
