GRIPHOLD Torque Wrenches

Product catalog summary

Overview: This document provides specifications for a range of mechanical dial torque wrenches under the Industrial Quality series, including models D1-30i, D1-75i, D1-150i, D1-250i, D1-600i, D1-50F, D3-100F, D3-175F, and D3-250F.

Specifications:

Torque Range: Models cover a range from 0-30 in.lb. (0-3.5 Nm) to 0-250 ft.lb. (0-350 Nm).
Graduation: Varies by model, with increments as small as 0.5 in.lb. (0.1 Nm) to 5 ft.lb. (10 Nm).
Drive Size: Available in 1/4”, 3/8”, and 1/2” drive sizes.
Length: Standard length is 10.63” (270mm) for D1 series and 22” (560mm) for D3 series.
Case: All models come with a plastic blow molded case.
Weight: D1 series weighs 1.6 lb (0.73 kg), while D3 series weighs 3.0 lb (1.4 kg).

Features:

Non-length dependent design with an alloy steel precision torsion drive.
Dual scale and dual direction capability.
Memory follower needle included on each wrench.
Dial protected with a steel guard.
Accuracy of 3% from 20-100% of the range.
Each wrench comes with a GRIPHOLD calibration certificate traceable to NPL standards and a hard-marked serial number.

Additional Information: Specifications are subject to change without notice. For more details, contact [email protected] or visit www.griphold.com.
