BE TOUGH ON YOUSITTING DOESNT HAVE TO > The Universal Tractor Seat to Suit Every Driver >

Suspension so good you dontknow itҒs there. > The secret of comfortable, correct suspensionis individual adjustment to suit your own weight. The Universos weight range of50Җ130 kg (110286 lbs) with 80 mm sus-pension travel minimizes vibrations, while the new hardwearing guide system guaran-tees a long, reliable service life. There֒s alsoa fore/aft isolator to cut vibrations and pre- vent potentially damaging jolts to your back. Comfort isnt a luxury җ its vital to your well-being. The new Universo has all the features thatmake sitting a pleasure: a tapered seatbackfor greater freedom of movement,...

New cover design In fully waterproof imitation leather or attractive fabric. > Tapered back support For greater freedom of movement. > Folding armrests (optional) The wide, cushioned armrests promote a relaxed arm posture and boost your performance. > Optimum cushion angle For maximum support. > Weight adjustment The crank is easy to use, and in an ergonomically ideal posi-tion. It can be steplessly adjusted from a sitting position to suitoperator weights between 50 and 130 kg (110 and 286 lbs). The weight display can be easily read from the front. > Fore/aft isolator A new dimension in spring...

Height adjustment Raise and lower the seat instantly and easily. Height adjustment in 20 mm steps: The handle is in an ergonomically ideal posi- tion, letting you adjust the seat with minimum effort and opti- mize your sitting position, whatever your height. > Ventilation channels Multifunction vents for maximum sitting comfort. > Practical, attractive design Superb styling makes sitting a pleasure. > Suspension comfort > Customized comfort. 80 mm suspension travel to cut vibra-tions to a minimum. Plus individual weight adjustment for the ultimate in relaxed, stress-free driving and a truly comfortable...

UNIVERSOFEATURESMXM Art. nos. for Galinaђ fabric 10473881047387 Art. nos. for imitation leather Mechanical suspension 1405781047386 Suspension 80 mm > PP Suspension travel 80 mm > PP Height adjustment Glide rail > PP Fore/aft adjustment over 210 mm range > P Ball rail > P Fore/aft isolator > P OPTIONAL FEATURES Armrests > pp Lap belt > pp Mount for angled installation > pp Seatback extension > pp Seat switch > pp P Standard p Optional > All measurements in diagrams in mm. We reserve the right to make technical and dimensional changes. Illustration may deviate from series. >

Sitzgelegenheiten, die fit machen.GRAMMERbietet modernste Sitz-systeme fr alle rollenden Arbeits- pltze - ob Traktor, Baumaschineoder Gabelstapler bis hin zu Lkw, Bus und Transporter. Ergonomisch sinnvoll gestaltet, setzen sie Ma줟stbe in punctoSitz- und Bedienkomfort. FragenSie uns - wir informieren Sie gern persnlich. GRAMMERAG Seating Systems > ? Postfach 1454 > ? D-92204 AmbergTelefon +49 (0) 9621/880-870 > ? Fax +49 (0) 9621/880-880 > ? www.grammer.com > ? [email protected] > 1015722 3/04 - IV Fri size="-2">
