GRAMMER
Maximo Evolution

Maximo Evolution

Product catalog summary

Sitting Comfort for Enhanced Well-Being
The Maximo seating systems prioritize comfort to promote health, featuring ergonomic backrests, wide cushions, and adjustable components like backrest height, seat angle, and lumbar support. The Maximo Evolution model includes active seat climate control to maintain comfort during long work hours.

Seat Adjustments Made Easy: “Design for Use”
The Maximo Evolution offers intuitive controls for easy use without a manual, enhancing user experience through uniquely shaped and positioned controls.

Maximum Suspension Comfort
The Maximo Evolution and XXL models feature suspension systems designed to absorb vibrations and jolts from heavy machinery, ensuring driver comfort and control with low-frequency fore/aft and lateral suspension systems.

Common Features Across Maximo Models
All Maximo seats include height-adjustable armrests, 100 mm suspension travel, 210 mm fore/aft adjustment, adjustable backrest angle, lumbar support, and fore/aft isolator. Optional features include lateral suspension, seat heating, and a seat switch for automatic driver detection.

Maximo Evolution Features
The Maximo Evolution offers adjustable backrest height, pneumatic lumbar support, active weight adjustment, and lateral suspension. It includes a low-frequency suspension system and an active seat climate system with heating. The seat length and angle are adjustable, and the design includes foldable armrests and a new cover design for added comfort.

Overview of Maximo Seating Systems
The document details the Maximo seating systems, focusing on comfort and ergonomic features for vehicles like tractors and construction machines. The Maximo Evolution model is highlighted for its advanced features and user-friendly design.

Key Features and Specifications

Adjustable Backrest Height: Personalized comfort with a range from 475 to 645 mm in 13 steps.
Pneumatic Lumbar Support: Provides back support to prevent spinal injuries.
Active Weight Adjustment: Automatically adjusts to the driver's weight for optimal suspension performance.
Design for Use: Intuitive controls for ease of use.
Lateral and Low-Frequency Suspension: Absorbs vibrations for a comfortable ride.
Active Seat Climate System: Maintains a pleasant temperature and includes seat heating.
Variable Seat Length and Angle: Adjustable to support different body sizes.
Foldable Armrests: Height and angle adjustable with fabric covers.

Additional Features

Fore/Aft Isolator: Minimizes vibrations during travel.
Adjustable Shock Absorber: Tailors to different conditions.
Rotary Adapter: Facilitates easy entry and exit.
Extra-Wide Cushions: Prevents slipping and provides comfort.
Height Adjustment: Offers 80 mm adjustment for ideal seating position.

Model Variants and Options
The document lists various Maximo models (Evolution, XXL, XL, L, M) with standard and optional features such as armrests, shock absorbers, suspension types, and climate systems, catering to different vehicle types and user needs.

Conclusion
The Maximo seating systems enhance driver comfort and well-being through ergonomic design and advanced features, suitable for a wide range of vehicles with customizable options to meet individual driver requirements.

Overview: The document provides detailed information about GRAMMER AG's Maximo seating systems for medium- and heavy-duty tractors, highlighting features and options for different models.

Key Features:

Comfort and Performance: The Maximo Evolution model offers enhanced comfort and performance, setting new standards in ergonomic design.
Equipment Options: Features include lateral suspension, seat heating, a restraint system, and a seat switch for automatic driver detection.
Suspension Systems: Options include air suspension with a 12V compressor, mechanical suspension, and low-frequency suspension.
Adjustability: Features include height-adjustable and foldable armrests, adjustable seatback angle, and fore/aft adjustment.
Climate Systems: Both passive and active climate systems are available.
Additional Features: Pneumatic and mechanical lumbar support, integrated seatback extension, and adjustable seat cushion length and angle.

Optional Features: Seatbelt and other customizable options are available.

Important Considerations: Users should check the individual mounting situation before using the seat.

Catalog excerpts

AN EVOLUTION IN SITTINGCOMFORT. For medium- and heavy-duty tractors > New: the Maximo Evolution More comfortՕ More performance size="-1">

Open the catalog to page 1

Seat Adjustments Made Easy:Design for UseӔ Maximum Suspension Comfort toSupport Hard Work The Maximo Evolution excels with its user-friendly Design for UseӔ. The controls are designed to let the user tell by touch how Sitting Comfort for Enhanced Well-Being they work and which way to move them. Each has a unique shape to prevent them The suspension system of the Maximo Evolution and the Maximo XXL is designed to absorb the vibrations and jolts typical of heavy tractors and tractors with axle and cabin suspension. It reduces the horizontal from getting mixed up. All controls are lo- The other...

Open the catalog to page 2

Adjustable Backrest Height Every back is different. The integrated backrest extension provides for personalized comfort: precisely geared to the drivers body size to prevent poor posture from causing injuries and keep him relaxed during long stretches at the wheel. The setting range extends from 475 to 645 mm in 13 steps. If wished, the extension can be pushed all the way in. > Body heat Perspiration FabricVentilation layer Active Seat Climate System with Heating The most important requirement for feeling good in the driverҒs seat is a > Activated charcoal pleasant temperature. But even with...

Open the catalog to page 3

New Cover Design Attractive and Robust. Foldable Armrests with Fabric Covers With adjustable height and angle. The cover effectively prevents the arms from rubbing and slipping. >

Open the catalog to page 4

Design for Useԓ The Maximo Evolution is characterized by Design for UseӔ - the controls are designed so the user can tell by touch how they work and which way to move them. Each has a unique shape to prevent them from getting mixed up. All controls are located where you would intuitively expect them. > NEW Document Box Switch for Active Seat Climate System Rotary Adapter Tapered Backrest For greater freedom of movement. Pneumatic Lumbar Support Back care at the press of a button. The pneumatic lumbar support adjusts quickly and precisely to the drivers back. A comfort feature that not only feels...

Open the catalog to page 5

MAXIMO M > FRONT VIEWSIDE VIEW All dimensions in mm. Subject to technical and dimensional changes. size="-2">

Open the catalog to page 6

Seating systems that keep you fit:GRAMMER offers state-of-the-art products for all mobile work- places - from tractors, construction machines, and forklift trucks all the way to trucks, buses, vans, and trains. Ergonomically de- signed, they set new standards of sitting comfort and operating convenience. Just ask us - well be happy to personally advise you. GRAMMER AG Seating Systems ҕ P.O. Box 1454 92204 Amberg, Germanywww.grammer.com > XXXXX/XXՖXX 1027419 3/04 - V Fri size="-1">

Open the catalog to page 8
