Up to 2000 lbsSteel, Aluminum & Stainless Steel Average 28% increaseCAPACITIES:TRACKS:PRODUCTIVITY: >
Open the catalog to page 1Thrust and Pull Requirements > All WSJ200 or AL100 Jib Cranes require a structurally adequate wall or column to support the jib. Refer to the thrust & pullӔ forces on the following pages to determine the forces that your structural support must resist to properly support the jib. Pre-engineered for Powered Hoists Hoist trolleys are included in the base price of all Gorbel Work Station Jib Cranes. Afactor of 15% of the jib capacity is allowed for the weight of the hoist, trolley, and below-the- hook device. Afactor of 25% of the jib capacity is allowed for impact (covers hoist speeds up to...
Open the catalog to page 2In most cases, Gorbel WSJ360 Free Standing Series JibCranes can be bolted directly to your existing floor without adding special foundations (see the specific product information on the pages that follow for more details). These cranes feature a retaining pin through the pivot pin to help resist accidental upward dislodgment of the boom assembly. The wall or column mounted WSJ200 crane uses tapered rollerbearings at the pivot points for unsurpassed ease of rotation. To ensure that the jib is aligned through the pivot axis and thus avoid unwanted drifting of the boom, shim stock up to 7/32...
Open the catalog to page 3Festoon Clamps > Festoon clamps anchor the festooning at the start of the jib boom. They also prevent the festoon gliders from exiting the track and they can provide a redundant stop for the trolley. Festoon clamps for vacuum hose are also available (not shown). Festoon Clamp Festoon Gliders > Festoon gliders are used to support flat electrical cable along the jib boom. No tools are required to attach the festooning to the gliders. One festoon
Open the catalog to page 9FREE STANDING WORK STATION BRIDGE CRANES & MONORAILS CEILING MOUNTED WORK STATION BRIDGE CRANES & MONORAILS Up to 4000 lbsUp to 30' Up to 4000 lbsUp to 30'Steel, Aluminum & Stainless SteelAverage 28% increaseCAPACITIES:SPANS:ENCLOSED TRACKS:PRODUCTIVITY: FREE STANDINGCEILING MOUNTED ERGONOMIC STUDY > G-FORCE > EASY ARM > ERGONOMIC STUDY > PERFORMANCE JIB CRANES GANTRY CRANES WORK STATION JIB CRANES ARTICULATING WORK STATION JIB CRANES 1/4 to 5 tons CAPACITIES:SPANS:APPLICATIONS: Up to 2000 lbsUp to 16'Reaching around or under obstructionsReaching through doorways JIB CRANESGANTRY CRANES...
