APU Unicub Systems

Product catalog summary

Overview of GLOBE High Pressure System
The GLOBE High Pressure System is designed for efficiency and versatility, featuring a high-pressure pump integrated with necessary couplings and connections within a compact stainless steel frame. It is portable, easy to control, and ready for immediate use. The system is part of the Unicub Series, capable of handling pressures up to 982 bar (14250 psi), and is constructed primarily from stainless steel for durability and longevity.

Product Range and Services
GLOBE offers a wide range of high-pressure equipment and systems, supported by a global distributor network. Established in 1986, the company specializes in gas boosters, high-pressure test equipment, and systems. GLOBE provides annual inspections to ensure system safety and functionality, along with customization, maintenance, and calibration services.

APU Unicub Series Specifications
The APU Unicub Series is an air-driven high-pressure system designed for test pressures up to 982 bar (14250 psi) with a 7 bar (100 psi) air drive pressure. It is suitable for mobile applications and uses air pressure and fluid as energy sources. The system is maintenance-friendly, ensuring a long lifespan, and is capable of testing various fluids.

Applications

Static or burst testing of hoses, tubing, and valves
Testing of pressure vessels or hydro systems
Energy source for static or mobile test systems
Impregnation and molding systems
Hydraulic press systems, bolt cutter, tensioning systems
Hydrostatic testing of valves, tanks, pressure vessels, etc.
Burst and cycle fatigue testing
Lifting and jacking operations
Hydraulic operations like clamping devices
Leak testing

System Features

Portable, compact design with low noise
Reliable and maintenance-friendly
Stainless steel hydraulic components and frame
Test pressure range from 5 bar (72 psi) to 982 bar (14250 psi)
Designed for various fluids including water, oil, and emulsion
Pressure hold without air consumption and auto start
Minimum air pressure for startup is approximately 1 bar (14.5 psi)
Flow rate and outlet test pressure are easily adjustable
Optional features include a recorder, tank, and special valves

Dimensions and Connections
The APU Unicub Series offers various models with different specifications for air inlet, fluid inlet, and outlet connections. The dimensions are compact, with a length of 400 mm, width of 264 mm, and height of 325 mm, weighing approximately 15 kg.

Performance Specifications
The series includes models with varying ratios and outlet test pressures, with maximum inlet air pressure at 7 bar (100 psi). The volume per stroke and maximum liter per minute performance vary across models, catering to different testing needs.

Catalog excerpts

The GLOBE High Pressure System Efficient and versatile GLOBE Test Equipment is the specialist in everything that has to do with high pressure. The high pressure systems consists of a high pressure pump in combination with all the necessary couplings and connections, built into a compact stainless steel frame. The system is easy to control, portable and ready for immediate use. We offer our Unicub Series standard high pressure test systems for pressures up to 982 bar (14250 psi). Our systems are made in a stainless steel (inox) frame and mainly consist of stainless steel parts. This way we provide a high quality product with a long life span. Why choose a GLOBE product? Woldwide network we use a worldwide distributor network to sell our products. As specialists we keep close contact with our customers, establishments and distributors. High quality We can inspect and approve your system on a yearly basis to ensure it continues to work correctly and safe. In-house engineering and production As a team of experts with lots of experience we do not just exactly know what we sell, we can also provide customization for all our products. Wide product program We are here to help you with all your questions about high pressure equipment and – systems and everything that is related. GLOBE Service Whether you are looking for customization, high pressure couplings, maintenance of your existing system or the calibration of your pressure gauges. We are happy to help. Since 1986 The GLOBE Group was founded in 1986. Our focus has been on developing, producing, advising and sales of gas boosters, high pressure test equipment and systems.

Open the catalog to page 1

APU UNICUB Series Air Operated High Pressure system Up to 14250 psi / 982 Bar Our smallest standard testsystem. The APU Unicub Series air driven high pressure systems are specially designed for test pressures up to 982 bar (14250 psi) at 7 bar (100 psi) air drive pressure. Commonly used when high pressure is used in a mobile situation. The main energy sources of the high pressure systems are air pressure and fluid. The frame, valves and tubing used in the APU Unicub Series are made of stainless steel and are therefor of a very high quality. Because the system is designed and constructed to be...

Open the catalog to page 2

Air Operated High Pressure system Our smallest standard testsystem. The APU Unicub Series air driven high pressure systems are specially designed for test pressures up to 982 bar (14250 psi) at 7 bar (100 psi) air drive pressure. Commonly used when high pressure is used in a mobile situation. The main energy sources of the high pressure systems are air pressure and fluid. The frame, valves and tubing used in the APU Unicub Series are made of stainless steel and are therefor of a very high quality. Because the system is designed and constructed to be maintenance friendly, the unit has a long lifetime....

Open the catalog to page 3
