300TWG Threaded Wheel Grinder.
6Pages

The machine was also developed for the production of small lots. Rapid changeover is part of this. Changing the grinding wheel is simple and straightforward using a specially developed tool change assist device. Changeover after wheel and workholdingchanges is done fully automaticallywithout any involvement of the operator. Gleason is building decades of expertise in gear grinding:the 300TWG Threaded Wheel Grinder will exceed yourexpectations. > ● Rapid changeover. > ● Maximum cleanliness. The workpiece is spun on the optional integrated spin-clean to reduce or eliminate oil carry off. The...

High flexibility and high productivity are standard on the Gleason 300TWG Threaded Wheel Grinder.The machine is configured to satisfy your every requirement. Workholding situation with dressing gear (bottom) on workholding fixture and Gleason dresser (top). Dressing with diamond-plated dressing gear. > ● upto 20 % more parts between dressing operations,due to sharper grinding wheel topography.The dressing gear and roller are integrated into the workholding fixture. Gleason has many years of experience in the production of diamond-plated dressing gears ensuresquality as well as short...

Machine NC axes:A-axis:grinding head swiveling B-axis:grinding spindle B1-axis:dressing spindle C-axis:workpiece spindle C1-axis:two-station ring loader(option)V-axis:indexing unit (NC axis as an option)X-axis:radial slide Y-axis:tangential slide Z-axis:axial slide Z4-axis:tailstock slide (option) > VRM noise-optimized surfaces. Gleason has a rich tradition of manufacturinggear honing machines and threaded wheelgrinders and as such,will be glad to adviseyou which of the two hard finishing methods will be of most benefit for your machiningrequirements. If you decide in favor of grinding,you...
