2 Weaving loom at the Düren site A unique combination: competence in filter media and plant engineering As a technological leader in challenging niche markets the GKD Group with its two corporate divisions is setting standards worldwide. WORLD WIDE WEAVE, our corporate division for technical mesh made from metal and other materials, comprises three business units: SolidWEAVE develops industrial solutions based on innovative filter media, WEAVEinMotion is the name for state-of-the-art process belt technology and CreativeWEAVE stands for exclusive architectural and design mesh. In the CAPITAL EQUIPMENT...

3 MAXFLOW 503 filter head opened Filter package covered with YMAX® stainless steel composite mesh C o m p a c t f i l t e r e q u i p m e n t

4 Filtration principle Compact design: filtration and briquetting in a single unit As an integrated compact filter system, MAXFLOW combines efficient filtration and briquetting in a single compact unit. With no need for filter aids – or at least with far fewer if required – the patented concept provides particle separation right down to the micro-filtration range. The system’s superiority lies in the ability to design the filter media according to the process and carry out precise adjustments specific to the materials. For this the number of filter discs and heads can be adjusted by modular means...

5 Cross-section of the MAXFLOW compact system 1000-504/ MAXFLOW 504 DN 100 Residues discharged as a briquette MAXFLOW compact system 1000-504 with round tank system Many benefits Modular compact system • Integrated, space-saving concept • Process-specific dimensioning • Expandable tank system • User-friendly operation, easy maintenance • As-required accessories (cooling, lifting pump) Integrated briquetting • Automated pressing • Discharge with low residual moisture • Minimal carry-over of the process media • Reduced waste volume weight Process-wide savings potential • Minimal filter aids or...

6 Twin system with additional platform for second filter head Added value through its modular design: customised configuration The compact modularity of the MAXFLOW filter system is being continued with the round tank design. As a tank-within-atank system it needs little space to prove just how efficient it is. The standard tank with a 1,000 l capacity can be extended at any time to up to 2,500 l, depending on requirements. A dirt tank integrated into the clean tank effectively prevents deposits from accumulating thanks to the tapered design of the tank floor. Linear circulation in the clean...

7 Opened filter heads of the twin system Cross-section of the twin system C o m p a c t f i l t e r e q u i p m e n t

8 Discharge as a briquette Cooling lubricant before and after filtration through MAXFLOW Impressive results: filtration without aids, with dry discharge The treatment of operating media and process fluids used in the automotive and metalworking industries for honing, lapping and grinding places complex demands on the filtration process. This is where MAXFLOW offers previously unknown potential for simplifying processes and optimising costs. This efficient, filter aid-free filtration system with integrated briquetting produces outstanding results – an automated system suitable for even the most...

9 Automatic discharge Comparison of a dirty and clean sample during an external series of tests on the MAXFLOW compact system 1000-504 C o m p a c t f i l t e r e q u i p m e n t

10 Flow simulation using the WEAVEGeo software Filtration test in our own laboratory Image of MAXFLOW 503 in the SolidWorks design software MAXFLOW meets all the requirements of established standards. Through its precise, individual adaptability, this flexible-use system can be reliably utilised for even the most specific production parameters. Its modular design ensures simple integration of the compact filter system into the customer’s processes as well as long-term cost-efficiency and performance. MAXFLOW grows in response with demand and thus combines process reliability and investment security...

11 Loading a grinding machine Integrated cooling coil in the clean tank Photos: Page 7 at the top GKD/Stettin, all others GKD C o m p a c t f i l t e r e q u i p m e n t
