Your test needs are unique Combining the perspective of an industry-leading RF instrument and microwave component manufacturer with decades of switching experience under the ASCOR brand Giga-tronics can provide a solution that optimizes the performance of your entire test system.

RF Interface Units, Signal Switching and System Integration for ATE Benefit Your Bottom Line For over 30 years, Giga-tronics ASCOR has excelled as an industry leader in the automated Test and Measurement community. Whether you need to bring products to market faster or make your operations more efficient, we take the time to understand your business objectives and then recommend the best economic and technical solution for the application. Get the Right Solution for You Giga-tronics ASCOR is not just in the business of providing “off-the-shelf” solutions. We are very experienced in...

Giga-tronics is different from typical switching providers. Having 30 years of experience in microwave test equipment and microwave components, Giga-tronics is uniquely positioned to apply a total system perspective to ensure an optimally performing switching solution.

Giga-tronics will Design, Build, Document, and Test an RFIU Design An RF Interface Unit is central to the ATE system + Signal conditioning (amplifiers, attenuators, circulators, filters, mixers…) + Frequency translation, up/down conversion + Phase-matching & delay-matching (for radar, antennas, high speed serial/signal integrity...)

THAT MEETS THE KEY REQUIREMENTS OF YOUR SPECIFIC APPLICATION. Whether it's a focus on superior signal integrity, extended reliability, or global service-ability, Giga-tronics is a proven provider of products and services used in applications ranging from mission critical military/aerospace test to high volume consumer device manufacturing. Eiga tranics

“The RFIU is probably the most overlooked and undervalued part of automated test system design. Even with the most sophisticated test instrumentation, the performance of a test system is only as good as the switching system routing the signals.” –Jeffrey T. Lum CTO

We pull from the Best Technology in the Industry To provide a standard, tailored or new solution that best meets your needs. + Wide signal bandwidth and frequency ranges: DC to 50 GHz + Broad range of switch components SPDT-SP12T, Transfer & Star + Low-level through high-power signal handling capability + Integration of a wide variety of signal conditioning components + Hundreds of existing designs on multiple platforms: VXI, PXI, Ethernet, GPIB Often from paper to product in as little as 4 weeks

RETHINK Designing your own Switching Solutions Every business decision can be boiled down to one simple factor, ROI. Business is about profit. When making “make or buy” decisions, ask the question: Does your test system drive revenue or profit or would resources be better spent elsewhere? More and more companies are electing to stick to their core competencies.

wide bandwidth, low noise, high isolation Ultra-high density + 500 MHz backplane + No external wires! Star Switching + Ultimate flexibility + Re-purpose pins! Point-to-point software giga-tronics provides Superior Performance + Wide breadth of capabilities + Large variety of platforms + From cards to systems

Why Giga-tronics? + roven track record with decades of experience P + readth of offering B + uperior performance S + ustomer partnership to tailor or design new solutions C + S9100 A Giga-tronics Supports Mars Rover Giga-tronics ASCOR’s understanding of switching systems, and ability to quickly process special configurations, resulted in core changes to the system design and a critical test role in the Delta Rocket Program which delivered the Mars Rover.

We see the whole picture RF & Microwave Test Microwave Synthesizer Modules & Subsystems Service & Support Online Resources Giga-tronics’ core manufactures best-in-class certification. Support microwave signal filtering have enabled us to services include application generators, microwave design unique integrated engineering assistance power amplifiers, power electronic assemblies to help your team with meters and power sensors. including microwave synthesizer modules, integrated microwave front process technology. ends, ultra-low phase Technical Assistance applications@gigatronics.com...

Whether your needs lie in test and measurement instrumentation, signal switching solutions or microwave subassemblies Giga-tronics ASCOR provides switching solutions to fit your needs. Contact us today Why Struggle? When you think of RFIUs and Signal Switching for ATE, think Giga-tronics ASCOR. Visit us at www.gigatronics.com for technical support and product information. E-mail applications@gigatronics.com for technical assistance. E-mail inquiries@gigatronics.com for quotes, order assistance or demo requests. Call toll 1-800-726-4442 (USA) or +1-925-328-4650 (International)
