Catalog excerpts
11113104080 Low-pressureconveying Medium-pressureconveying Gentle conveyingThrust conveyingPlug conveying,PulseLineԙ GERICKE GERICKE lean phase conveying dense phase conveying Loading (mixing ratio) =kg productkg conveying air > Annual costs MechanicalconveyingLean phaseconveyingDense phaseconveyingPay back / investment Lean phaseconveyingPulseLinegentle conveying Energy Maintenance / service Product loss through degradation Example 1: Silo loading of raw materials e.g. flour, sugar or salt, which do not require slow speed conveying.Example 2: Mixer feeding with friable granulateddetergent...
Open the catalog to page 3Applications: for coarse and fine powders, grains and granulates Throughput: 0.1 to 4 m > 3 /h Distance: 1 to 50 m Advantages: high vacuum possible (up to 900 mbar) (multi-ejector)Օmodular assembly, easy to clean no electrical components Օlow dust emmissions pharmaceutical version available > 1 Entrainment hopper2 Vacuum pipe 3 Cyclone separator 4 Filter 5 Ejector pump 6 Discharge flap 7 Product discharge Applications: for coarse and fine powders, grains and granulates Throughput: 1 to 10 m > 3 /h Distance: 1 to 100 m Advantages: Օdust escape ruled out low investment costs Օflexible design...
Open the catalog to page 4Applications: for coarse and fine powders, grains and granulates Throughput: 0,1 to 50 m > 3 /h Distance: 1 to 100 m Advantages: Efficiency low investment costs Օself contained system simple design Օeasily extended conveying pressure up to 800 mbar using ablower or side channel compressor.Օproduct feed by rotary valve or injector. continuous product conveying Օproduct discharge via cyclone separator > Product feed from silo via rotary valve. In-line sifter placed directly in lean phase pressure or suctionconveyor. Gericke in-line sifter Advantages: Reduce height and improve maintenance...
Open the catalog to page 5Gericke pulse conveyor Pulse-Flow PTA type Applications: for free-flowing to cohesive powders, coarse-grained products and granulates. Throughput: 0,1to 100 m > 3 /h Distance: 1 to 500 m Advantages: ٕlow velocity, kind to the product minimum segregation Օhigh loading/low conveying gas consumption How it works: The design of the pressure vessel ensures that the product is forced into the conveying pipe in a mass flow form. The conveying gas (air, nitrogen) enters the vessel and conveying pipe in pulses. Depending upon the product, separate or wave plugs are formed, which are moved slowly by...
Open the catalog to page 6Applications: for coarse, fine and fluidisable powders. Throughput: up to 150 m > 3 /h Distance: up to 800 m Advantages: low-wear (no rotating parts) Օminimum air and energy consumption PHFK 20: compact installation height How it works: The product is conveyed in layers using medium pressure and velocity. The air is introduced separately into the discharge elbow for conveying and the vessel for fluidising. > 3 /h with double sender. Applications: for products extremely fragile and abrasive products. > Vibration Throughput: 5 m > 3 /h max. Distance: 50 m max. Advantages: Օgentlest product...
Open the catalog to page 7Feeding the conveyor: Feeding into the > Dependant upon the product characteristics, filling capacity and available space, the most suitable feeding equipment is selected: e.g. gravity, discharge aids, screws. conveying pipe: > Rotary valves, venturi, special valves for abrasive products and for plastic granules, easy clean rotary valves. Pipeline couplings: > Flanged pipe connections, compression, dairy fittings, tri-clover. Gericke pipe bend > Type GB to counter wear andproduct degredation. Diverter valves: > Pinch, butterfly, plug valves, rotating tube, hose. Modern Gericke...
Open the catalog to page 8Typical: flexibility of design layout Օlow height at pick up point Sugar and dextrose for chocolates, sweets, yoghurt, infant foods or beverages Advantages: extremely slow and gentle Օconstant velocity, no final expansion thanks to double sender conveying > Advantages: Pulse-Flow type How it works: Typical: The product characteristics and the minimum conveying velocity are the most important factors when selecting the most appropriate conveying system. Low velocity conveyors not only minimise product degradation but also reduce noise and equipment wear. All materials are trialed in the...
Open the catalog to page 9Dust-free emptying andmedium-pressure conveying from bulk vehicles into silos. Road tankerDense phase conveying with Pulse-Flow plug conveying to mixer. for components used in vitamin production. Advantages: ٕefficient discharge of road vehicles or sea bulk containersproducts treated gently > from containers, big bags or drums. Products with minimum conveying gas (e.g. nitrogen)direct to the reactor or agitated vessel. Advantages: Օautomated feed nitrogen blanketing Օproduct delivered above or below liquid level > for pharmaceutical products Advantages: absolutely dust-free and hygienic...
Open the catalog to page 10Advantages: reliable conveying in N > 2 circuitՕeconomical using N > 2 recycling circuitno angel's hair > 2 supply detergent ingredients, intermediate and end products > 1 Silo2 Sender 3 Conveying pipe 4 Filter 5 Pressure equalisation vessel 6 Compressor 7 Cooler, filter N The PulseLineՙ dense phase conveying system includes self-regulating additional air into the conveying pipe. This system is also ideal for conveying plastic pellets. Advantages: extremely gentle product handling Օhigh reliability as blockages in the conveying pipe are prevented > for cement, gypsum, lime, sand Plaster...
Open the catalog to page 11GB -Ashton-u.L. OL6 7DJTel. 0161 344 1140Fax 0161308 3403 Singapore 787813Tel. (65) 4528133Fax (65) 4520392 CH -8105 RegensdorfTel. 01 871 36 36Fax 01 871 36 00 > gericke.uk@gericke.net gericke.sg@gericke.net gericke.ch@gericke.net D -78239 Rielasingen F -95100 Argenteuil NL -3870 Hoevelaken > gericke.de@gericke.net gericke.fr@gericke.net gericke.nl@gericke.net Visit our Internet site: www. gericke.net >
