Fascinating Electrotechnics 2BSecure Protect your Interfaces secure simple flexible

ÎMaximum security for USB and ETHERNET interfaces Machines and systems are more and more networked, which increases the risk of unauthorised access and cyber attacks. The new EU Machinery Regulation 2027 and the CRA (Cyber Resilience Act) contain strict cyber security regulations. Companies are obliged to comprehensively protect their machines against attacks and manipulations. 2BSecure, the innovative security solution for controlling USB and ETHERNET interfaces, offers the perfect answer. ÎHow does 2BSecure work? disabled data enabled charging enabled 2BSecure is a compact black box that is...

ÎThe advantages of 2BSecure at a glance: Maximum control of USB and ETHERNET interfaces Prevents unauthorised access and protects against cyber attacks Interfaces are disabled by default B thus access is impossible Only authorised personnel can activate the interface, for example via software (PLC/IPC) or key switch or RFID system connected in between Easy integration in existing machines and plants Compatible with the CRA and ther Machinery Regulation 2027 Modular and exible, adaptable to different application scenarios

Î2BSecure-RJ45 – network security at the highest level ETHERNET interfaces on machines enable access to networks and control systems – and this is where major risks lie. With 2BSecure-RJ45, your network interfaces remain deactivated by default and can only be activated manually by an authorised user, e.g. via key switch or RFID. Network security is a central component of the CRA and the Machinery Regulation 2027. With 2BSecure-RJ45 you not only meet legal requirements, but also effectively protect your machines against cyber attacks, unauthorised network access and manipulation. Protect your...

Î2BSecure-USB – protection for your machines and data The USB interfaces on machines and systems pose a signicant safety risk if they are accessible without control. With 2BSecure-USB, these interfaces are deactivated by default and only activated after explicit authorisation, e.g. by a key switch or RFID. This prevents the unnoticed introduction of malware or the unauthorised copying of sensitive data. In times of increasing cyber threats and stricter security requirements, such as the new Machinery Regulation 2027 and the CRA, protection against external access is crucial. 2BSecure-USB ensures...

LED illuminated ring disabled red data green charging blue Connection _DCZv_\_Jr-^C

2BSecure-USB with key switch Key switch +24 V S1 S2 safe data green charging blue

Application examples ^ 2BSecure-RJ45 with RFID data green data green

Î 2BSecure-RJ45 with key switch Connection +24 V 0 V / GND LED illuminated ring disabled red data green All information subject to change and without any claim to completeness. Photos are exemplary.
