SERVINGYOUR MARKING NEEDS SINCE1895 www.gtschmidt.com >

established 1895 > Original Plant at 4100 Ravenswood Ave. Chicago, Illinois.

Fixturing Press Marking Roll Marking Knurl Carriages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Shank Style Knurl Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Free Running Knurl Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Roller Bearing Cradles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Stud Arbor Fixtures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Introduction Manual Marking Shank Style Typeholder...

Standard Code & Inspection Stamp Designs Standard Code Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Numbering Heads Company Information Shank Style Repeat-O-Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Model 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Select-O-Heads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Barrel-Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Special...

The Marking Tool Guide presents a general overview of the toolsrequired for permanently marking a wide array of industrial products. With it you can review your present mark- ing application in light of the latest industry developments to be sure that you are using the most efficient and economical marking methods for your operation. A Schmidt Sales Engineer or Customer Service Representative will be glad to asist you in this evaluation. Their many years of experience addressing marking applications, on a full time basis, is available to you without cost or obligation.Contact us via telephone,...

Pressure Requirements for Marking Pressure to mark one character (in tons). Character SoftCharacter SizeMild SteelAluminumTool SteelDepth 1/16.25.15.38.003Ԕ 3/32.05.30.75.004Ԕ 1/8.75.451.13.006Ԕ 5/321.00.601.50.007Ԕ 3/161.881.132.82.008Ԕ 1/42.101.263.15.010Ԕ 5/163.001.804.50.013Ԕ 3/84.002.406.00.016Ԕ 7/164.752.857.13.016Ԕ 1/25.703.428.55.017Ԕ 5/87.504.5011.25.020Ԕ 3/49.255.5513.88.020Ԕ 7/811.006.6016.50.020Ԕ 113.007.8019.50.020Ԕ > These are pressures for Sharp Face characters.In order to estimate marking pressure requirements, multiply the single character tonnage found above bythe number of...

Knurl Step Type Blank Dimensions > L = length W = width H = height Hs= height from step tobottom of die D = depth of step Wb= overall width ofblank A = angle (L x W x H) step: Hsx D angle: A) Straight Step Type > L = lengthW = width H = height Hs= height from step tobottom of die D = depth of step Wb= overall width ofblank (L x W x H) step: (Hsx D) Shank StyleRound Die > L = length of bodyD = diameter of body Ls= length of shankDs= diameter of shank(D x L) shank: (Dsx Ls) Straight GrooveType > L = lengthW = width H = height Hg= height from middleof groove to bottom of die Wg= width of grooveD...

With indented characters , size should be determined by measuring the face of the tool. Sharp Face andAerocut tools are measured at the apex of the engraved face indicated in the sketch. Flat Face and Outline style characters are measured to the outside edge or overall dimension of the engraved face. Embossed characters are the exception and are measured from the impression rather than the face of the die.The size is determined by the height of the impression at the point where the raised portion meets the back- ground. Debossed characters . The size of a debossed character is measured at the...

Depth Of Engraving ( GTS Standards ) Character SizeDepth Character SizeDepth 3/64.012Ԕ 5/16.040Ԕ 1/16.014Ԕ 3/8.050Ԕ 3/32.018Ԕ 7/16.055Ԕ 1/8.023Ԕ 1/2.060Ԕ 5/32.028Ԕ 5/8.062Ԕ 3/16.031Ԕ 3/4.078Ԕ 7/32.033Ԕ 1.093Ԕ 1/4.035Ԕ > Extra Deep Engraving : > Required when material is removed from apart after marking and an abnormally deep mark is required. Branding dies are engraved extra deep and with a flat face so the background of the hot die will not touch the material Controlled Depth Engraving : > In some applications, engraving maybe shallower than standard depth. Trademarks and other lettering layouts...

Hi-Loy Steel Letter and Figure Hand Stamps . Used with ahammer to mark changeable legends on a limited production basis. Size of Blank Stock No.Character SizeSquare X Length 0326651/165/16Ԕ x 2-7/8 0326663/32Ԕ5/16 x 2-7/8Ԕ 0326671/85/16Ԕ x 2-7/8 0326685/32Ԕ3/8 x 3Ԕ 0326693/163/8Ԕ x 3 0326701/4Ԕ3/8 x 3Ԕ 0326715/161/2Ԕ x 3-1/4 0326723/8Ԕ5/8 x 3-1/2 0326731/2Ԕ3/4 x 3-1/2Ԕ > Flat Steel Hand Stamps. Used with a hammer to stamp anentire legend with one blow...faster and more evenly than with single handstamps. All are made special according to customer specifica- tions. Aerocut and Aerocut Dot Face...

Plain Code Stamps . > These stamps provide onthe spot information. Select symbols from standard code designs shown on the chart (pg. 29) or speci- fy your own design. Blank Size Design SizeSquare x Length 1/165/16Ԕ x 2-7/8 3/32Ԕ5/16 x 2-7/8Ԕ 1/85/16Ԕ x 2-7/8 5/32Ԕ3/8 x 3Ԕ 3/161/2Ԕ x 3-1/4 1/4Ԕ1/2 x 3-1/4Ԕ 5/165/8Ԕ x 3-1/2 3/8Ԕ5/8 x 3-1/2Ԕ 1/23/4Ԕ x 3-1/2 > Inspection and Code Stamps . > Record twokinds of information with a single impression. Available in sizes from 3/16Ԕ to 1/2. When order- ing specify design number, size and key letter or figure desired. Key characters are engraved as large...

Hand Style Repeat-O-Head > A time saver whenrepeat numbers are required. Each wheel has 10 figures and a blank space, permitting any figure setup. Individual wheel release permits freeing only one wheel without dis- turbing the entire setup. Standard heads available in 3/32 or 1/8Ԕ character sizes, 4-7 wheels with all wheels being figure wheels. Letter wheels are available for an additional charge per wheel. Larger characters are also available. Radial Typeholder > Designed for radially marking flatsurfaces. A pilot can be provided to guide the holder into marking position. This insures accurate...
