GE Motors - Product Line

GE Motors - Product Line

Product catalog summary

Product Line Overview:
GE Motors offers a diverse range of motors and drives designed for various applications, including industrial, commercial, and specific use cases. The product line includes motors with different specifications, such as horsepower, voltage, and construction materials, catering to different operational needs.

Specifications:

EPAct Efficient Motors: Available in 1-400HP, with voltage options of 200, 230/460, 460, and 575 volts. Features include cast iron frame, 1.15 service factor, and inverter capability.
Severe Duty Motors: Ranging from ¾ to 250HP, these motors are designed for harsh environments with full cast iron construction and shaft slinger.
Explosion Proof Motors: Designed for hazardous locations, available in 1-200HP with non-sparking fans and oversized conduit boxes.
Direct Current Motors: Includes Permanent Magnet DC and Kinamatic II models, offering continuous torque and drive capability.
Application Specific Motors: Includes X$D Ultra7 models for severe duty applications, meeting API and IEEE standards.
Vertical Motors: Weather-protected and custom vertical designs available, suitable for high thrust applications.
Electric Vehicle Systems: Motors designed for OEM replacement in electric vehicles, offering traction and power steering capabilities.

Standards and Compliance:

Motors meet various industry standards such as NEMA, IEEE, and API, ensuring reliability and performance in specific applications.
Explosion proof and severe duty motors are designed to meet safety and operational standards for challenging environments.

Drive Systems:

Low Voltage Drives: Includes VAT 20, AF-300 G11, Mini, and P11 models, offering flexibility and cost-effectiveness for small to medium applications.
Medium Voltage Drives: Dura-Bilt 5i MV offers high performance with sensorless vector control and IEEE 519 compliance.

Additional Features:

Motors are equipped with advanced insulation systems like GEGARD20007 and bearing systems for enhanced durability.
Customizable options available for specific applications, including vertical and horizontal configurations.

Contact Information:
GE Motors, Fort Wayne, IN 46802, USA. Phone: 260 439 2000. Website: www.gemotors.com

Catalog excerpts

Motors Product Line >

Open the catalog to page 1

Totally Enclosed Fan CooledExplosion Proof 1-200HP 230/460 Volt Full Cast Iron Construction Brass Flinger on both ends Non-Sparking fan Oversized Conduit Box Totally Enclosed Fan CooledSevere Duty - 250HP 230/460, 460, 575 volt Full Cast Iron Construction1.15 S.F.F-1 to F-2 modifiable Inverter Capable Shaft Slinger > Totally Enclosed Fan Cooled ޾ - 150HP 200, 230/460, 460, 575 Volt Cast Iron Frame & Endsheilds 1.15 S.F.F-1 to F-2 modifiableInverter Capable C-Face or Footmount Open Drip Proof 1-400HP200, 230/460, 460, 575 Volt Cast Iron Frame & Endsheilds 1.15 S.F. F-1 to F-2 modifiable Inverter...

Open the catalog to page 2

Vertical MotorsWeather-Protected (WPI) X$D Ultra 7 661 Extra Severe DutyTotally Enclosed Fan CooledHeat Exchanger Custom Vertical 5-300HP230/460, 460 Volt (Part Winding Start) Cast Iron Frame & EndshieldStamp Steel Top HatBall Ratchet High Thrust Inverter Capable 1-800HP 230, 460, 2300 or 4160 VoltCast Iron FrameWPI, WPII, TEFC Solid or Hollow Shaft Designs Normal, High or Extra-High Thrust Designs Standard or Energy Efficient Electrical Designs 5-75HP 380, 460 volt Meets API 661 & IEEE 841 Standards GEGARD2000 7 Insulation SystemRoller Bearing L10 Life: 40,000 hrs D.E. and O.D.E. Inpro Seal...

Open the catalog to page 3

8200-8900 Frame HorizontalMedium & High Voltage Induction 500-15,000 HP (11,000 kW)Up to 13800 VoltsFabricated Steel Frame Construction NEMA & IEC Designs API 541, 547 WPI, WPII, TEAAC, TEWAC > 500 FrameLow & Medium Voltage 250-800HP 460,2300, 4160, 6600 VoltODP, WPII, TEFCVertical or Horizontal Configuration Custom Polyseal 8200-8900 Frame Vertical Medium & High Voltage Induction 500-12,500 HP (9,000 kW) Up to 13800 VoltsFabricated Steel Frame ConstructionNEMA & IEC Designs API 541 Normal or High Thrust Designs WPI, WPII, TEAAC, TEWAC Large AC Synchronous Motors 1000-100,000 HP (75,000 kW) Up...

Open the catalog to page 4

AF-300 Mini 1/8 - 5 HP 115, 230 & 460 Volt Compact with built-in dynamic braking controlSingle turn potentiometerIdeal for pumps, fans, and conveyors VAT 20 AF-300 E11 1/4 - 3 HP 230 & 460 Volt UL, CSA, and CESmall, Flexible, Low CostIdeal for small fans and conveyors 1/8 - 10 HP 230 & 460 Volt DeviceNet, Profibus, Interbus-S,Modbus Plus, CAN CommunicationNetwork OptionsRemote mount keypad High-performance, ideal for OEM machinery, fans, and pumps AF-300 P11 1/4 - 150 HP, 230 Volt 1/2 - 800 HP, 460 Volt General Purpose Variable TorqueNEMA 1, 4, 12 Enclosure OptionsSoft-Switching Technology allows...

Open the catalog to page 5

, X$D Ultra, GEGARD2000, and the Six Star Bearing Systemare trademarks of General Electric Company. NEMA Premium is a trademark of NEMA.DEA-M0377 1106 > 2006 General Electric Company All rights reserved. GE, >
