Anti-creep cross roller guide rail FYFV
1 / 3Pages

Anti-creep cross ball guide Anti-fretting, high precision, high rigidity The Anti-creep Cross Roller Guide Rail The Anti-creep Cross Roller Guide Rails is a kind of high precision linear motion rail set which can prevent dislocation. It has inner gear racks and gear mechanism, which can completely solve the dislocation problems while in moving.lt is the most appropriate design of the track.The cage is provided with a gear which engages with the rack on the guide rail to prevent the sliding of the rolling body. It is suitable for difficult lifting devices on cross guide rails and applications FIJYIJ MAKE HIGH-ENDPRECISION GUIDE RAILS LET FUYU GUIDE RAIL SERVICE WORLDWIDE High precision and repeated positioning accuracy Effectively restrain the displacement deviation caused by sliding friction and ensure the stability of motion. Vacuum heat treatment Uniform hardness Prevent deformation i/. Chamfer to avoid vacancy Avoid interference with other combined product accessories Use special steel The material has good toughness,high density, uniform hardness, and will not break and deformation The width of guide rail mounting surface shall be less than or equal to B1. ±gR\tMain size £*RTf Assembly size Cage Dimensions Number A11^MU1 Basic load Rating „ Allowable Countersunk face,bottom hole chamfering and clearing can achieve1^11 interference in screw assembly

±HN\N\/lain size Assembly size Cage Dimensions Number aiiI1mu Basic load Rating MAKE HIGH-ENDPRECISION GUIDE RAILS LET FUYU GUIDE RAIL SERVICE WORLDWIDE Installation Instruction of Anti-creep Cross Roller Guide Rail FYV3-75-8Z 3.3 Then move the moving rail to the left end of the fixed rail until two ends paralleled.Then the cage will be in the middle of two rails.Put double U fixed plate at the end of two rails.Fix the two rails and cages by end screws.This mehod is suitable for returning the other side cages.

MAKE HIGH-ENDPRECISION GUIDE RAILS LET FUYU GUIDE RAIL SERVICE WORLDWIDE Gear cagel Fixed guidewayl 4 Installing the work table, cover the working table to the moving rail and attach the screws loosely on the working table and moving raiLAfter installing the adjusting upper screw on the lateral of working table,we can adjust the prepressing upper screw with proper stress,and then fasten the lateral rail of working table. Remove the fixed plate on the end of rail and fasten the end screws. Install the clock style dial indicator in the middle and lateral of working table. © Move the worktable...
