Digital Flowmeter Models: 3 cc/min, 6 cc/min, 30 cc/min & 300 cc/min Fine adjustment needle valve & isolation valve Volumetric and mass flow measurement USB connection to Leak detector The FCO220 Digital Microcalibrator is a traceable flow rate meter designed primarily to provide calibration for production line leak detectors. The unit comprises a mini flow meter using a laminar flow element and a low range differential pressure transducer to resolve leak rate readings in cc/min, cc/hr or mm³/s. The leak rates are adjustable using the built-in fine needle valve and the set leak rate is read on an LCD display. Built-in atmospheric pressure and temperature sensors corrects the flow readings for variable ambient conditions providing volumetric flow, standard flow and mass flow.

Flow ranges Flow Units Accuracy @ 20°C Temperature Coefficients Display Long Term Drift (span) Flow Measurement Zero: Semi-automatic Zero facility Span: < 0.1% per °C 8 character LCD < 1% per year Electrical Power Requirements Battery Life Operating Temperature 9 volt battery (PP3/6LR61/MN1604) Up to 100 hours 0 to 50°C Pneumatic Media Compatibility Overload Pneumatic Connection Vent port Static Pressure Effective Volume Clean dry air or non corrosive gas. Viscosity corrected for air only. 20 x Range ⅛” BSP female input (option for Quick Connector) M5 (DO NOT RESTRICT) Vacuum to 14 bar gauge...
