Product catalog summary

Overview: This document is a comprehensive product guide from Fujitsu Microelectronics, detailing various electronic components including ASSP, Memory, ASIC, and Microcontrollers. It provides technical specifications, features, and applications for these products.

ASSP - MB3789 Switching Regulator Controller:

Description: A PWM switching regulator controller ideal for DC/DC conversion and power supply to LCD back-lighting.
Features: Operates on 3V to 18V, low current consumption, wide input voltage range, built-in error amplifiers, external sync signal oscillator, timer latch short protection, variable dead time, and supports power MOSFET.
Package: 16-pin SSOP.

Memory - MB81ES123245 FCRAM:

Description: A 128 M-bit Single Data Rate Interface Fast Cycle RAM designed for low power and high performance.
Features: Fully synchronous operation, low power consumption, high bandwidth, and low voltage operation.
Product Lineup: Includes parameters like clock frequency up to 133 MHz, burst mode cycle time, and various current specifications.

ASIC - CS101 Series Standard Cell:

Description: A 90 nm CMOS ASIC offering low power consumption and high speed, with integration up to 91 million gates.
Features: Uses 7-10 metal layers, low-K dielectric materials, supports various core transistors, and complies with industry standards.

Microcontrollers - F2MC-8FX MB95100AM Series:

Description: General-purpose, single-chip microcontrollers with a compact instruction set and various peripheral functions.
Features: Includes F2MC-8FX CPU core, multiplication and division instructions, 16-bit arithmetic operations, and multiple clock options.

RF and Communication Products:

RF and IF PLLs: Designed for RF and IF applications with frequency ranges from 50 MHz to 6.0 GHz, featuring low noise and high-speed lock-up.
Sigma-Delta Fractional-N PLLs: Offer high-speed lock-up and low noise for RF applications up to 3.5 GHz.
VCOs and Transmitter Modules: Suitable for CDMA, GSM, PCS, and PHS applications.
SAW Filters: Available for various mobile communication systems, offering high attenuation and low insertion loss.
Communication Control Products: Provide communication control for ISDN and IP packet processing.

Video/Audio Products:

IF SAW Filters: Designed for NTSC and PAL systems with specific frequency requirements.
Demodulator Products: For satellite, cable, and ISDB-T OFDM systems, featuring high tolerance to spectrum distortion.
Video Encoder and Decoder: Include Full HD H.264 codecs and MPEG-2 to H.264 transcoders.
Power Management Applications: Describe AC/DC converters, general-purpose DC/DC converters, and power management ICs for portable products.

Power Management Applications:

DC/DC Converters: Detailed with specifications such as power supply voltage, switching frequency, output voltage, and current.
Charge Control: Designed for lithium-ion battery charging, supporting multiple cells.
Voltage Detectors: Offer wide operating voltage ranges and accurate supply voltage drop detection.
Motor Drivers: Provide motor drive capabilities with wide operating voltage range.
Smart Card/RFID Systems: Support ISO standards and feature FRAM memory.

Memory Products:

FCRAM: Includes SDR-SDRAM and DDR-SDRAM with capacities ranging from 16M-bit to 512M-bit.
FRAM: Detailed with capacities from 256K-bit to 2M-bit, featuring parallel and serial interfaces.
Flash Memory: Covers products from SPANSIONTM, including single 1.8V and 3V options.

ASIC Products:

CS101 Series: Supports up to 91 million gates using 90 nm Si-gate CMOS technology.
CS91 Series: Uses 0.11 μm Si-gate CMOS technology with a maximum of 48 million gates.
CS86 Series: Offers up to 40 million gates with 0.18 μm technology.

Legal and Ordering Information: Specifications are subject to change without notice, and Fujitsu does not assume responsibility for patent infringements. Customers should consult Fujitsu sales representatives before ordering.

Conclusion: This document serves as a reference for Fujitsu Microelectronics' product offerings, providing essential information for ordering and usage while highlighting legal and safety considerations.

Catalog excerpts

FUJITSU MICROELECTRONICS PG00-00091-2E PRODUCT GUIDE [ ASSP > Memory > Օ ASIC ] >

Open the catalog to page 1

tr.row {} td.cell {} div.block {} div.paragraph {}

Open the catalog to page 2

Ethernet is a registered trademark of XEROX Corporation in the United States.ՕFCRAM is a trademark of Fujitsu Microelectronics Limited, Japan.FerVID family is a trademark of Fujitsu Microelectronics Limited, Japan.ՕMirrorBit is a trademark of Spansion Inc.SPANSION is a trademark of Spansion Inc.ՕAmplify is a registered trademark of Synplicity, Inc.Other company names and brand names are the trademarks or registered trademarks of their respective owners. >

Open the catalog to page 4

Page No. ASSP TelecomTelephones 2Mobile, Wireless communicationPLL Frequency Synthesizers 4Short range wireless 8VCO, Transmitter Module, SAW Duplexer 10SAW Filter > ASSP 12Dual SAW Filter 12Communication ControlCommunication NetworkCommunicationControlISDN 14 > IP Packet Processing Engine 14 > High-speed IPsec Processing Engine 14 > CommunicationNetwork LAN 14Video Equipment ProductsDisplay Control Products 16Video/Audio Products 18Digital Demodulator 20ISDB-T OFDM 20Video Encoder, Decoder 20 > Power Management Applications AC/DC Converters 22General Purpose DC/DC Converters 22DC/DC Converters...

Open the catalog to page 5

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:7.00pt "Arial", sans-serif; } .font1 { font:8.00pt "Arial", sans-serif; } .font2 { font:16.00pt "Arial", sans-serif; } .font3 { font:7.00pt "Courier New", monospace; } Tlphone Products T驩lphones Part number Features ISDN tl驩phones digital Serial MB86434 AIU * LSI for ISDN digital telephone *: Audio Interface Unit Digital telephones mobile MB86435 3 V single power supply AIU n MB86437 3 V single power supply AIU 2

Open the catalog to page 6

Package Part number Functions CODEC Power supply voltage (V) QFP MB86434AIU for ISDN digital telephonesCODEC, DTMF tones, service toneInternal ringer toneA-laW -laW14-bit linear+5ձ5%64P > ASSP Package: P - Plastic > Package Part number Functions Compression law Power supply voltage (V) LQFP MB864353 V single power supply AIUA-laW -laWlinear2.7 to 3.664P MB8643748P Package: P - Plastic >

Open the catalog to page 7

Mobile, WirelessCommunicationInput frequency band of prescalerPLL typePrescaler divide ratioPart numberFeatures PLL Frequency SynthesizersLow Noize Single Integer-N PLL100 MHz to 2.5 GHzRFInteger-N32/33, 64/65 MB15E07SRFor digital telecommunications equipment, Low noise700 MHz to 3.0 GHzRFInteger-N64/65, 128/129 MB15E06SRFor digital telecommunications equipment, Low noise300 MHz to 2.0 GHzRFInteger-N64/65, 128/129 MB15E05SRFor digital telecommunications equipment, Low noiseSingle Integer-N PLL700 MHz to 2.5 GHzRFInteger-N32/33, 64/65MB15E07SLFor digital telecommunications equipment, Low power...

Open the catalog to page 8

tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:5.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:8.00pt "Arial", sans-serif; } .font3 { font:13.00pt "Arial", sans-serif; } .font4 { font:16.00pt "Arial", sans-serif; } Mobile, Wireless Communication Products Mobile, Wireless Communication Products PLL Frequency Synthesizers Low Noize Single Integer-N PLL Part number Input frequency band (Hz) PLL Type Divide ratio Power supply current Power save current Power supply voltage (V) Package min max Prescaler Program counter Swallow counter Reference...

Open the catalog to page 9

(Continued)(Continued) Input frequency band of prescalerPLL typePrescaler divide ratioPart numberFeatures Dual Integer-N PLL400 MHz to 2.6 GHzRFInteger-N32/33, 64/65MB15F78ULFor digital telecommunications equipment Low noiseLow power dissipation100 MHz to 1.2 GHzIFInteger-N16/17, 32/332.0 GHz to 6.0 GHzRFInteger-N16/17, 32/33MB15F76ULFor digital high-speed telecom-munications equipment100 MHz to 1.5 GHzIFInteger-N4/5, 8/9 (Fixed part 4 division)2.0 GHz to 4.0 GHzRFInteger-N64/65, 128/129MB15F74UVSmall Package 200 MHz to 2.0 GHzIFInteger-N32/33, 64/65MB15F74ULFor digital high-speed telecom-munications...

Open the catalog to page 10

Dual Integer-N PLL Package: P - Plastic Input frequency band (Hz) Power supply voltage (V) Divide ratio Power supply currenttyp (mA) Power save currenttyp ( Package Part number PLLType min max Prescaler Program counter Swallow counter Reference counter յ A) min typ max > BCC TSSOP MB15F74UV2.0G200M4.0G2.0G Integer-N > RF : 64 / 65 , 128 / 129 − − > ASSP IF : 32/33, 64/65 RF : 64/65, 128/129 Binary 11bit 3 to 2047Binary 7bit 0 to 127Binary 14bit3 to 163836.52.50.10.12.73.03.618P MB15F73UV200M50M2.25G600M 2.0 1.20.10.12.42.73.618P > IF : 8/9, 16/17 − MB15F72UV100M50M1.3G350M > RF : 64 / 65 , 128...

Open the catalog to page 11

(Continued)(Continued) Input frequency band of prescalerPLL typePrescaler divide ratioPart numberFeatures Single Sigma-Delta Fractional-N PLL100 MHz to 2.0 GHzRFSigma-Delta16/17MB15E65UVHigh-speed lock-up/Low noizeModulo : 2 > 18 / 2 > 15 100 MHz to 3.5 GHzRFSigma-Delta16/17MB15E64UVHigh-speed lock-up/Low noizeModulo : 2 > 18 / 2 > 15 Single Sigma-Delta Fractional-N PLL (RF) & Integer-N PLL (IF) 100MHz to 2.0 GHzRFSigma-Delta16/17, 20/21MB15F63ULHigh-speed lock-upModulo : 2 > 20 LPF switch50 MHz to 600MHzIFInteger-N8/9, 16/17Short range wireless430 MHzMB15H121Prescaler divide ratio8/9PA, Σ∆ PLL,...

Open the catalog to page 12

Single Sigma-Delta Fractional-N PLL Package: P - Plastic Input frequency band (Hz) Power supply voltage (V) Divide ratio Power supply currenttyp (mA) Power save currenttyp ( Package Part number PLLType min max Prescaler Program counter Swallow counter Reference counter յ A) min typ max BCC > ASSP MB15E65UV100 M2.0 GSigma-Delta16/17Binary 8 bit9 to 255Binary 4 bit0 to 15Binary 6 bit1 to 634.90.12.73.03.318P MB15E64UV100 M3.5 G16/17Binary 8 bit9 to 255Binary 4 bit0 to 15Binary 6 bit1 to 634.90.12.73.03.318P Single Sigma-Delta Fractional-N PLL (RF) & Integer-N PLL (IF) Package: P - Plastic Input...

Open the catalog to page 13

(Continued) ApplicationPart numberFeatures VCO * Single Type(700 MHz to 2500 MHz)CDMA, GSM, PCS, PHSVC-90 seriesCompact type with wide variable frequency bandV10x seriesUltra Compact type with wide variable frequency bandDual Type(800 MHz to 2500 MHz)CDMA, PCS, GSMV08 seriesCompact dual band type with band selection functionV09 seriesCompact dual band type with band selection functionTransmitter Module Single Type(824MHz to 849MHz)CDMA(CELL band)T021 seriesBuilt in Duplexer, PowerAmp and Band Pass FilterSingle Type(824MHz to 1980MHz)W-CDMA * I, V, VIII T031 seriesBuilt in Duplexer, PowerAmp and...

Open the catalog to page 14
