DVB/MPEG-2 & Graphics controller Products

DVB/MPEG-2 & Graphics controller Products

Product catalog summary

Introduction to Business Unit Multimedia
Fujitsu Microelectronics Europe's Business Unit Multimedia, based near Frankfurt, Germany, focuses on advanced multimedia products for digital TV, set-top boxes, and graphic display controllers. The unit supports applications in car navigation and industrial sectors, with Fujitsu being a key global supplier in multimedia, telecommunications, mobile communications, and automotive markets.

Business Unit Multimedia at FME
The unit provides single-package solutions for digital satellite television, MPEG-2 decoders for set-top boxes, single-chip MPEG-2 encoders, and graphic display controllers. The Frankfurt development center designs and supports these solutions, with the SmartMPEG product notably reducing system costs for set-top boxes.

Front-End for Digital Satellite Television
The MB86A15 is a highly integrated single-chip solution for digital satellite broadcasting, combining a tuner, QPSK demodulator, and Forward Error Correction Unit. It is optimized for DVB-S and DSS transmissions, offering reduced size, power consumption, and cost.

MPEG-2 Decoder for Digital Television
The SmartMPEG (MB86H2x) is designed for medium- and low-end set-top box applications, featuring MPEG-2 video and audio decoding, a 32-bit RISC CPU, and multiple transport stream decoders.

MPEG-2 Encoder
The MB86391 MPEG-2 encoder integrates video, audio, and system encoders, supporting MPEG-1 and MPEG-2 encoding, NTSC and PAL formats, with applications in video distribution systems, digital video recorders, and surveillance systems.

Graphic Display Controllers
Fujitsu's graphic display controllers, such as MB86290A 'Cremson' and MB86291A 'Scarlet', are optimized for embedded systems like car navigation and mobile terminals, supporting 2D/3D rendering and high-performance graphics operations.

Product Roadmap and Evaluation Boards
A product roadmap and evaluation boards are available to assist in the development and integration of these multimedia solutions.

Conclusion
Fujitsu's multimedia solutions provide advanced technology for digital television and graphic display applications, supported by a robust development and support infrastructure.

Overview of Graphic Controllers
The document details Fujitsu's graphic controller family, including models like 'Coral', 'Coral B', 'Coral P/PA', 'Lime', and 'Carmine', each designed for specific applications from 2D rendering to high-end multimedia.

Specifications

Coral Devices: Support up to 64MB of external memory, with display resolutions up to 1280 x 768, featuring a 6-layer overlay display and various graphic acceleration functions.
Coral B: Adds video input capabilities, supporting signals in PAL or NTSC formats with video scaling features.
Coral P/PA: Enhanced with PCI host interface and new video input scaling facility.
Lime: Optimized for 2D applications, compatible with the 'Coral' family.
Carmine: High-end extension with a new graphics core, offering significant performance improvements and dual-display output.

Key Features

CMOS technology from 0.18µm to 90nm.
Support for multiple overlay display layers and alpha blending.
External memory interfaces for up to 64MB graphic memory.
Temperature range from -40 to +85°C.

Evaluation Boards
Fujitsu provides evaluation boards for application development and functional evaluation, compatible with Windows environments, supporting various graphic controllers.

Conclusion
The document outlines Fujitsu's roadmap for future graphic controller devices, emphasizing multimedia integration and single-chip solutions for car navigation applications.

Catalog excerpts

DVB/MPEG-2 & Graphics controller Products-2

European Distributors & Representatives24-25 European Sales Offices Back Cover > Introducing Business Unit Multimedia1 Business Unit Multimedia at Fujitsu Microelectronics2 Front-End for Digital Satellite Television3-4 MPEG-2 Decoder for Digital Television5-7 MPEG-2 Encoder8 > Copyright 2006 Fujitsu Limited Tokyo, Japan and Fujitsu Microelectronics Europe GmbH. All Rights Reserved.The information contained in this document has been carefully checked and is believed to be entirelyreliable. However Fujitsu and its subsidiaries assume no responsibility for inaccuracies.The information contained...

Open the catalog to page 2

DVB/MPEG-2 & Graphics controller Products-4

A car infotainment system using Fujitsu Multimedia components. The following components areoffered from the Business Unit Multimedia: For complex components, the Business Unit Multimedia can also supply development kits to customers. These kits include an evaluation board, software and documentation. > ● Single-package front-end solutions for digital satellite television > ● MPEG-2 decoders for set-top box applications > ● Single-chip MPEG-2 encoders including audio encoders, video encoders & system multiplexers > ● Graphic display controllers for embedded solutions At the heart of Fujitsus Business...

Open the catalog to page 4

DVB/MPEG-2 & Graphics controller Products-6

The low power consumption will helpto further reduce costs and make design and implementation easier. Key Features > ● Multi-Chip-Package (MCP), using Fujitsus advanced MCP technology > Ң׏ For logic module: CMOS 0.25m technology > բ׏ For RF module: BiCMOS technology Key Applications > ● Includes Zero IF Tuner, QPSK Demodulator and Forward Error Correction > Monitor software for PC for the QPSK silicon tuner (MB86A15). ● DVB-S (SCPC, MCPC)) and DSS compatible > ● C/N Monitoring function (via I > ● Evaluation board including monitor software for PC is available. This software offers graphical BER...

Open the catalog to page 6

DVB/MPEG-2 & Graphics controller Products-9

Development Kit available which includes: > Flash8Mbit QPSKSilicon Tuner QPSKSilicon Tuner ● Evaluation Board with transport stream input and analogue video output, single 12V supply, USB for debug > I 2 CSmartCard IF SMIUPIDAC 1-5VideoRGB & YCLR7-Seg-CTRLS/P-DIF SmartMPEG I 2 SIR RxTS2TS1 AudioDAC SDRAM64Mbit SmartCardXTAL ● Application programming interface software (FAPI) will be provided by Fujitsu > XTAL 7-SegmentDisplayIR HDD ● Software example in Flash > Typical configuration using the MPEG-2 decoder SmartMPEG digital video recorder using two front-ends and ahard disk drive. Key Applications...

Open the catalog to page 9

DVB/MPEG-2 & Graphics controller Products-11

In-car navigation is a key target application for FujitsuҒs graphic display controllers. 09 >

Open the catalog to page 11

DVB/MPEG-2 & Graphics controller Products-20

D(0:31)A(0:23) Video inputand scaler HOST BUSINTERFACE PCI/HostInterface ExternalMemoryController YUV/RGB Key Features > Pixel Bus Digital RGB The new graphic controller Limeђ is the perfectchoice for 2D-optimised graphic systems based on the Coralђ family. MD(0:31)MA(0:14) 2DRenderingEngineDisplayController 64MByteSDRAMorFCRAM Limeђ is a low-end extension to theFujitsu Graphic Controller Family for 2D applications. This chip is based on the Coral family core functions, and optimised for 2D rendering. The display controller, renderingengine and video input unit are taken from the successful Coral...

Open the catalog to page 20

DVB/MPEG-2 & Graphics controller Products-21

BT656BT656 orDRGB666 RGB GeometryEngine RenderingEngineGraphics Local Bus CPU I/F(PCI 66MHz) Video CaptureDisplay Controller RGB The Carmineђ GDC is the first device of its kind to be fabricated in 90nm technology. Carmineђ is a high-end extension tothe Fujitsu Graphic Controller family. This chip will carry a brand new graphics core which will deliver 10x more performance as Coral PAђ. All relevant blocks inside the chip are redesigned and will be optimised for high-end in-car multimedia applications. Carmineђ will be 100% compatible to OpenGL ES 1.1. All transforming and lighting functions...

Open the catalog to page 21

DVB/MPEG-2 & Graphics controller Products-22

Roadmap of graphic controller devices. Under development >

Open the catalog to page 22

DVB/MPEG-2 & Graphics controller Products-23

The Cremsonђ Starterkit is a modularevaluation board, which provides a stand-alone embedded environment. The kit hardware consists of two parts, a CPU module, which carries a Fujitsu 32-bit RISC MCU MB91F36X and a set of sub-boards for the graphic controllers Cremsonђ, Scarletђ, Jasmineђ and Limeђ. In order to facilitate the appropriate configuration for the application requirements, the system allows easy interchange of the CPU type or the graphic controller.The interconnection between bothmodule boards is the host-CPU bus interface. All functions of the graphicdevices and the CPU are present...

Open the catalog to page 23

DVB/MPEG-2 & Graphics controller Products-24

DeviceNameChipMax Resolution2D3DTextureNumberLayer AlphaDrawing AlphaDual DisplayRGB Digital Frequency(typ. @60Hz)RenderingRenderingMappingof LayersBlendingBlendingOutputOutput MB87P2020Jasmine64MHz800 x 600x--4---xMB86290ACremson100MHz1024 x 768xxup to44-bit flag4-bit alpha--512 x 512blending fordrawingtop layerMB86291AScarlet100MHz1024 x 768xxup to44-bit flag 4-bit alpha-x512 x 512blending fordrawingtop layerMB86292Orchid100MHz1024 x 768xxup to44-bit flag 4-bit alpha- x512 x 512blending fordrawingtop layerMB86293Coral Q166MHz1024 x 768xxup to68-bit alpha-plane8-bit alpha-x4096 X 4096for 1 layer...

Open the catalog to page 24
