Capillary tube thermostats

Product catalog summary

Overview: The document provides a comprehensive overview of Frico's range of thermostats and controls, highlighting their applications, features, and technical specifications. These products are designed for both public and commercial premises as well as home environments, offering solutions for various heating and cooling systems.

Applications: Frico thermostats are suitable for controlling electrical and water-borne floor heating, heat pumps, electric radiators, convectors, air conditioning, radiant heaters, fan heaters, and air curtains. They are available in both advanced processor-controlled models and simpler bimetal versions.

Comfort and Operation: The thermostats ensure even temperature distribution and a good indoor environment. They offer integrated control of room and floor heating, with options to limit floor temperature for comfort. Precise control extends system life and reduces energy consumption, with features like save reduction and weekly programming for economic heating.

Design: The thermostats feature a timeless and discreet design suitable for any environment, with options for recessed installation.

Product Specifications: Key features include programmable functions, digital displays, internal and external sensors, save reduction, 2-pole switches, and protection classes up to IP55. They support both on/off and proportional control.

Specific Models:

Basic Offer Thermostats: Models like T10, TK10, and TKS16 offer processor-controlled room/floor heating with options for visible or concealed knobs and digital displays.
Electronic 2-step Thermostats: RTI models provide room heating/cooling with adjustable temperature differences and external sensor options.
Capillary Tube Thermostats: KRT models offer room heating/cooling with adjustable temperature steps and high protection classes.
Electric Heating Control: ERP models provide stepless pulse control for electric heaters, with options for external sensors and slave units for larger outputs.

Additional Controls: The document also describes other controls like CIRT for stepless output control with timers, S123 manual switches, KUR digital time switches, and CBT electronic timers, each with specific features and protection classes.

Technical Specifications: Detailed technical specifications are provided for each model, including voltage, maximum input, setting range, protection class, and dimensions.

Wiring Diagrams: The document includes internal wiring diagrams for various thermostat models, illustrating their connections and configurations.

Catalog excerpts

Operation and economy Design The thermostats can be used to control either slow systems such as floor heating or faster systems such as electric radiators/convectors. Correct control gives a longer service life of the system and lower energy consumption.Precise thermostats provide economical heating. With save reduction and weekly program functions one can choose to have lower temperatures, for example at night to give further savings. Timeless and discreet design, which blends in with > Comfort Our precise thermostats create an even temperature and good indoor environment. Processor controlled...

Open the catalog to page 2

T, TK, TD, basic offer thermostats RTI, electronic 2-step thermostats Processor controlled thermostats for room/floor heating. Available with concealed/visible knob or digital display. Model with visible knob also available with 2-pole switch and in 400 V. External sensor (RTS01) available as an accessory. CE compliant. Processor controlled 2-step thermostats for room heating /cooling. Available with concealed or visible knob. Adjustable temperature difference between the steps (110 degrees). Save reduction function via external connection timer (1֖10 degrees). External sensor (RTS01) available...

Open the catalog to page 3

TypeDescriptionERPRG Room sensor ERP ERPGG Floor/duct sensor ERP ERPS Slave unit ERP An overview of all thermostats' technical specifications and functions on page 88. >

Open the catalog to page 4

230/400V2~16IP44155x87x43 S123 230/400V3V~20IP4272x64x46 TypeVoltage (supply) [V]Max input [A]Protection classDimensions HxWxD [mm]CIRT KUR 230V~10IP44175x85x105 CBT 230V~16IP44155x87x43 >

Open the catalog to page 6
