Fracmo right angled DC brushless geared motor

Product catalog summary

Overview: The document provides detailed specifications and features of various geared motor units and a compact torque motor developed by the Denis Ferranti Group under the Fracmo brand. These motors are designed for a range of applications, particularly in the mobility market.

G30/PM45 Geared Motor Unit:

Voltage Range: 12 to 180 VDC
Output Power: 37 to 250 watts
Speed Range: 55 to 450 RPM
Features: Reversible rotation, customizable output shaft, static parking brake, long-life low-noise brushes, IP44 enclosure, and four motor stack lengths.
Gearbox: Two-stage with hardened steel worm and bronze worm wheel, offering six gear ratios.

G34 Geared Motor Units (PM62, PM55, PM45):

Voltage Range: 12 to 180 VDC
Output Power: Varies by model, up to 500 watts
Speed Range: 57 to 250 RPM
Features: Reversible rotation, customizable output shaft, static parking brake, long-life low-noise brushes, IP44 enclosure, and 13 motor stack lengths.
Gearbox: Two-stage with a disengage mechanism for freewheeling, adaptable to different motor frames.

Fracmo Compact Torque Motor (CTM):

Models: CTM1 and CTM2
Voltage Range: 12 to 48 VDC
Output Power: CTM1: 150-240 Watts, CTM2: 150-350 Watts
Speed Range: Up to 4000 RPM
Features: Brushless technology, integral drive electronics, closed-loop speed control, IP54 enclosure, and maintenance-free design.

Performance Data: Detailed tables and graphs provide torque, speed, and power output for various motor configurations and gear ratios, assuming a 24 V DC supply.

Contact Information: For further details, the document provides contact information for the Fracmo sales team and the Denis Ferranti Group.

Catalog excerpts

Fracmo right angled DC brushless geared motor-2

● Voltage Range: 12 to 180 VDC. > Geared Motor Unit ● Rotation: Reversible. ● Connections: Flying leads or customer preferred plugs. ● Static parking brake 12/24 Volts with or without hand release. ● Output shaft tailored to customer requirements. ● Output power range 37 to 250 watts. ● Speed Range 55 to 450 RPM. ● Class F insulation. ● Long-life, low-noise brushes. ● Cartridge brush gear as standard for easy maintenance. ● Totally enclosed to IP44. ● Option of 4 motor stack lengths. > Performance Features

Open the catalog to page 2

Fracmo right angled DC brushless geared motor-3

Geared Motor Unit MINMAXMINMAXMINMAXMINMAX TORQUE Nm 1.285.12.56113.4114.3111 SPEED RPM 55450554505545055450 POWER WATTS 378075160100225120250 > Performance Data Fracmo. Denis Ferranti Group Օ Caernarfon Road Bangor Օ Gwynedd LL57 4SP Օ United Kingdom > Denis Ferranti Meters Ltd. Registered in England & Wales. Registered Number: 219880 . Registered Office: Gorddinog, Llanfairfechan, Gwynedd LL33 0HS size="-1">

Open the catalog to page 3

Fracmo right angled DC brushless geared motor-5

Geared Motor Unit ● Voltage Range: 12 to 180 VDC. ● Rotation: Reversible. ● Connections: Flying leads or customer preferred plugs. ● Static parking brake 12/24 Volts with or without hand release. ● Output shaft tailored to customer requirements. ● Output power range 100 to 500 watts. ● Speed Range 57 to 250 RPM. ● Class F insulation. ● Long-life low-noise brushes. ● Cartridge brush gear as standard for easy maintenance. ● Totally enclosed to IP44. ● Option of 13 motor stack lengths. ● Option of 3 motor Frame sizes. > Performance Features

Open the catalog to page 5

Fracmo right angled DC brushless geared motor-6

G34PM62 Engineering Drawing Geared Motor Unit MINMAXMINMAXMINMAXMINMAXMINMAX TORQUE Nm 5.813.47.317.49.221.513.232.316.542.0 SPEED RPM 5725057250572505725057250 POWER WATTS 100190130240160320240430320500 > Performance Data Fracmo. Denis Ferranti Group Օ Caernarfon Road Bangor Օ Gwynedd LL57 4SP Օ United Kingdom > Denis Ferranti Meters Ltd. Registered in England & Wales. Registered Number: 219880 . Registered Office: Gorddinog, Llanfairfechan, Gwynedd LL33 0HS size="-1">

Open the catalog to page 6

Fracmo right angled DC brushless geared motor-8

Geared Motor Unit ● Voltage Range: 12 to 180 VDC. ● Rotation: Reversible. ● Connections: Flying leads or customer preferred plugs. ● Static parking brake 12/24 Volts with or without hand release. ● Output shaft tailored to customer requirements. ● Output power range 45 to 250 watts. ● Speed Range 57 to 250 RPM. ● Class F insulation. ● Long-life low-noise brushes. ● Cartridge brush gear as standard for easy maintenance. ● Totally enclosed to IP44. ● Option of 13 motor stack lengths. ● Option of 3 motor Frame sizes. > Performance Features

Open the catalog to page 8

Fracmo right angled DC brushless geared motor-9

G34PM45 Engineering Drawing Geared Motor Unit MINMAXMINMAXMINMAXMINMAX TORQUE Nm 2.6648.65.211.47.617.4 SPEED RPM 57250572505725057250 POWER WATTS 45856513085170130250 > Performance Data Fracmo. Denis Ferranti Group Օ Caernarfon Road Bangor Օ Gwynedd LL57 4SP Օ United Kingdom > Denis Ferranti Meters Ltd. Registered in England & Wales. Registered Number: 219880 . Registered Office: Gorddinog, Llanfairfechan, Gwynedd LL33 0HS size="-1">

Open the catalog to page 9

Fracmo right angled DC brushless geared motor-11

Geared Motor Unit ● Voltage Range: 12 to 180 VDC. ● Rotation: Reversible. ● Connections: Flying leads or customer preferred plugs. ● Static parking brake 12/24 Volts with or without hand release. ● Output shaft tailored to customer requirements. ● Output power range 96 to 300 watts. ● Speed Range 57 to 250 RPM. ● Class F insulation. ● Long-life low-noise brushes. ● Cartridge brush gear as standard for easy maintenance. ● Totally enclosed to IP44. ● Option of 13 motor stack lengths. ● Option of 3 motor Frame sizes. > Performance Features

Open the catalog to page 11

Fracmo right angled DC brushless geared motor-12

G34PM55 Engineering Drawing Geared Motor Unit MINMAXMINMAX TORQUE Nm 7.1168.619.5 SPEED RPM 4225542255 POWER WATTS 96250115300 > Performance Data Fracmo. Denis Ferranti Group Օ Caernarfon Road Bangor Օ Gwynedd LL57 4SP Օ United Kingdom > Denis Ferranti Meters Ltd. Registered in England & Wales. Registered Number: 219880 . Registered Office: Gorddinog, Llanfairfechan, Gwynedd LL33 0HS size="-1">

Open the catalog to page 12

Fracmo right angled DC brushless geared motor-14

The all new Fracmo CTM (CompactTorque Motor) uses brushless technology and innovative design techniques to give greater reliability and efficiency from a significantlysmaller and lighter footprint.Weighing only 1.5kg,with a diameter of87mm and lengthof 70mm, theCTM1 is 30%smaller and18% moreefficientcompared withtraditionalmotors. It is alsomaintenance free &sealed for life.This powerful permanent magnetbrushless motor is suitable for a wide range of applications from the simplest drive applications to complex integrated drive solutions. > The versatility of Fracmos CTM is further enhanced by...

Open the catalog to page 14
