• Voltage Range: 12 to 48 VDC
• Output Torque Range: 3.61 to 24.59 Nm
• Continuous Output Power Range: 80 to 500 Watts
• Rotation: Reversible
• Connections: Flying leads or customer preferred plugs
• Static Parking Brake: 12/24 Volts with or without hand release
• Output Shaft: Tailored to customer requirements
• Speed Range: 112 to 333 RPM
• Insulation: Class F
• Brushes: Long life, low noise
• Maintenance: Cartridge brush gear as standard
• Enclosure: Totally enclosed to IP44
• Motor Stack Lengths: Option of 5 lengths

The PoweredAxle is designed for high power specifications required by modern mobility and light industry drive manufacturers. It includes an electromagnetic brake, high-quality gear train, and differential drive in an aluminum pressure die-cast housing. The gearbox is filled with high-grade grease and sealed for life. Output shafts can be customized, and rubber end boots reduce shock loading and aid assembly. The motor is a 4-pole high-efficiency permanent magnet motor with high-quality ferrite magnets and profiled brushes for reduced noise.

The PoweredAxle offers versatility with extendable axle lengths and a unique motor fixing arrangement that accommodates all Fracmo PM62 Frame Motors, providing flexibility for end users. Performance data includes torque, speed, and power ranges for different motor frames and gear ratios.

• Shaft details
• Brake type
• Motor length
• Supply lead configuration

The rating table assumes a 24 V DC supply; for other voltage ranges, contact the sales team.

The document includes tables showing typical performance metrics for various motor frames and gear ratios, detailing torque, speed, and power outputs.
