Product catalog summary

Gear Pumps

Junior Gear Puppy: Medium duty pump suitable for general use with a maximum viscosity of 150 Cs. It features an inlet filter, simple design, and fewer wearing parts. The output is 3.2 gpm (12.1 lpm) at a 16.4 ft (5m) head, self-priming to 3 ft (1.0m), ideal for transferring water, oil, and diesel.
Gear Puppy: Similar to the Junior Gear Puppy but with a higher output of 6.9 gpm (26.1 lpm) at the same head. It complies with USCG 183.410 standards.
Models: Available in 12V and 24V DC, suitable for automotive, bus, and truck applications.

Hand Pumps

Manual Operated Hand Pumps: Heavy-duty pumps with brass cylinders and oil-resistant plungers, available in five sizes, capable of 30 strokes per minute.
Amazon Warrior Portable Pumps: Made of ABS plastic with a comfort-grip handle, available in 24” and 48” sizes with hoses.
Specifications: Various models with different capacities, hose sizes, and weights, designed for utility and emergency uses.

Rotary Lobe Pumps

Ultima/55 Series Ultra Hygienic Positive Displacement Pump: Designed for high hygiene standards, tested to EHEDG, CIP, SIP, and bacterial tightness protocols. Features include low product shearing, rugged design, and high volumetric efficiency.
Hy~Line Super Hygienic Positive Displacement Pump: Incorporates the latest hygienic design concepts, with features like flush rotor fixing screws and front-loaded shaft seals for easy maintenance.
24 Series Hygienic Positive Displacement Pump: A proven design with adaptability as a key concept, allowing quick interchange of parts to suit various applications.

General Features and Options

Seals: Various seal options including single mechanical face type, double mechanical seals, and multiple PTFE lip seals for different applications.
Certifications: 3.1B Material Certification, 3A Sanitary Standards, and FDA compliance.
Connections: Compatible with US and European standards, offering flexibility in connection types and sizes.
Elastomers: Available in Nitrile, Viton, EPDM, and PTFE, conforming to sanitary standards.

Improved Hygienic Technology The pump features a fully swept pump chamber, sealed rotor spline, accessible seals, and approved sealing components to meet stringent international standards.
Construction Details

Sealed rotor splines for enhanced cleanability.
High-grade alloy bearing frame for strength and low weight.
Detachable ports for flexible connections.
Removable feet for optimal pump orientation.
High-specification tapered roller bearings for longevity.
Shaft sleeves under seals to reduce maintenance costs.
Precision-cut helical timing gears for reduced noise and maintenance ease.
Interchangeable seal types for various applications.
Interchangeable rotor options without re-timing, minimizing downtime.
Heavy-duty shafts for high pressure and minimal deflection.

24 Series Specifications The pump models range from S2 to E2, with varying port sizes, displacements, maximum flow rates, pressures, speeds, dimensions, and weights. They operate within a temperature range of -30°C to +150°C and handle viscosities from 1 to 1 million cP.
Seal Options

Single mechanical seals in hygienic design with materials like carbon and stainless steel.
Low pressure flushed seals for crystallizing products.
Double mechanical seals for hazardous or abrasive products.
Gland packing for non-hazardous liquids.
O-Ring seals for self-lubricating products.

Certification 3A variants with Nitrile or EPDM elastomers and various port options.
Rotors

Tri-lobe rotors for efficiency and versatility.
Bi-lobe rotors for delicate solids.
Rubber-covered tri-lobe rotors for hard solids.

Connections Compatible with US and European standards, offering interchangeable sizes.
Elastomers Available in Nitrile, Viton, EPDM, PTFE, or Kalrez.
Other Options

Pump head temperature control jackets.
Integral pressure relief valve.
Enlarged suction ports for viscous products.

Catalog excerpts

section SI X | page 136 GEA R Pumps geaR Pumps

Open the catalog to page 1

section six | page 137 GEA R PUMPS JUNIOR GEAR PUPPY GEAR PUPPY FEATU RES • Medium duty pumps for general purpose use. • Maximum viscosity 150 Cs • Inlet filter included • Simple design means fewer wearing parts • 3.2 gpm (12.1 lpm) output @ 16.4ft (5m) head • Self priming to 3 ft (1.0m) • Ideal for water, oil and diesel transfer FEATU RES • Medium duty pumps for general purpose use. • Maximum viscosity 150Cs • Inlet filter Included. • Simple design means fewer wearing parts. • 6.9 gpm (26.1 lpm) @ 16.4ft (5m) head • Ideal for water, oil and diesel transfer. • Meets USCG 183.410 Unless otherwis...

Open the catalog to page 2

Hand Pumps

Open the catalog to page 3

section sEVEN | page 139 HAN D PUMPS Manual Operated Hand pumps Ultimate heavy duty hand pump for utility and emergency uses. Made with long-life brass cylinders, high quality oil resistant plungers and impact absorbing end caps. Pumps never need coaxing and give full suction on the first stroke. Can be used in any position. Available in 5 sizes. Units are supplied with varying lengths of hose. Normal pumping capability is 30 strokes per minute. Amazon Warrior Portable Pumps Constructed of sturdy ABS plastic with comfort-grip handle providing smooth firm strokes. Available in 24” (610mm) with...

Open the catalog to page 4

Lobe pumps

Open the catalog to page 5

section EI GHT | page 142 ROTA RY LOBE Pumps section EI GHT | page 143 ROTA RY LOBE PUMPS Options Seals Front loaded single mechanical face type seals of hygienic design. Materials include carbon and silicon carbide. Low pressure flushed seals utilize the same single mechanical seal with an additional housing. A low pressure flush liquid washes away crystallizing products or liquids which ‘skin over’. Double mechanical seals utilizing all the components from single seals. Used for hazardous, toxic, highly abrasive or sterile products. Certification 3.1B Material Certification package. 3A Variants...

Open the catalog to page 6

section EI GHT | page 144 ROTA RY LOBE Pumps section EI GHT | page 145 ROTA RY LOBE PUMPS HYGIENIC Pumps Hy~Line Super Hygienic Positive Displacement Pump ITT Jabsco’s latest rotary positive displacement pump incorporates the very latest in hygienic design concepts in order to fulfill the ever increasing customer demands for improved cleanability, hygiene and sterilize ability. This 316 Stainless Steel design uses a bi-wing rotor, which encompasses the very best features of tri-lobe rotor pumps and circumferential piston pumps. The pump is built upon ITT Jabsco’s 40 year experience of producing...

Open the catalog to page 7

section EI GHT | page 146 ROTA RY LOBE Pumps section EI GHT | page 147 ROTA RY LOBE PUMPS HYGIENIC Pumps 24 Series Hygienic Positive Displacement Pump The 24 Series range of positive displacement rotary lobe pumps is a proven design spanning over 20 years. With thousands of pumps in use around the world, users agree that it is one of the best designed hygienic pumps on the market today. The 316 Stainless Steel 24 Series pump range incorporates improved technology in hygienic pump design and manufacturing techniques, yet utilizes the traditional tri-lobe rotor concept, which is so well accepted...

Open the catalog to page 8
