Diaphragm Pumps

Operational “Box” for ITT Flojet Diaphragm Pumps (Options below are not available to all ranges) Pressure 0-160 (0 - 11 bar) Open Flow 0.3-7 GPM (1.14 - 26.5 LPM) Elastomers Santoprene, Viton, Buna, Geolast, EPDM, Silicone, Kalrez Body Materials Polypropylene, Celcon, Nylon Switch Range 20-160 PSI (1.4 - 11 Bar) or no switch Bypass Range 15-150 PSI (1.0 - 10.4 Bar) or no bypass Power Electric: 12-48VDC, 110VAC, 230VAC Gas: Air, Co2 or Nitrogen section THREE | page 50 Diaphr agm Pumps Introduction 5 Chamber - 12, 24VDC Diaphragm Pump Product Range 160 (11.03) 150 (10.34) 140 (9.65) 130 (8.96)...

section THREE | page 51 Diaphr agm PUMPS Introduction The Principal Behind Positive Displacement Diaphragm Pumps features and benefits Expect only the best. With over 30 years of pump design and manufacturing experience, ITT Flojet is committed to delivering the hardest working and longest lasting pumps. No matter the application, ITT Flojet can provide a superior pump to match all your requirements. Self-Pr iming Even When Dry Dry vertical lift from 2.5ft (0.75m) up to an outstanding 27.9ft (8.5m). Can run dr y without damage • ITT Flojet diaphragm pumps can run dry for extended periods with...

section THREE | page 52 Diaphr agm Pumps Motor Driven LF Series | FOR International & US MARKETS This ultra compact pump uses the duplex diaphragm design to deliver flow and pressure comparable to much larger pumps. Pressure/Head psi (bar) 50 (3.4) 40 (2.8) 30 (2.1) 20 (1.4) 10 (0.7) 0 .2 (.75) .8 (3.0) 1.0 (3.8) .6 (2.3) .4 (1.5) 0 Flow gpm (lpm) FEATU RES • Sealed pressure switch automatically starts and stops pump when discharge valve opens and closes • Self-priming so pump can be located above supply tank • Can run dry for extended periods of time without damage • Built-in thermal protector...

section THREE | page 53 Diaphr agm PUMPS Motor Driven Models Model #s CE Switc h PSI (BAR) Bypass PSI (BAR) Voltage Diap hragm Check Valve Open Flow GPM (LPM) coments LF112201 RLF112201 35 (2.5) No 12V Santoprene Viton 1.0 (3.8) Fins, Inline Connector, Inline Fuse, Rocker Switch LF112421 RLF112421 40 (2.8) Yes 12V Santoprene Viton 1.0 (3.8) Fins, Inline Connector, Inline Fuse, Rocker Switch LF121421 RLF121421 40 (2.8) Yes 12V Santoprene Viton 0.7 (2.6) LF122002 RLF122002 No No 12V Santoprene EPDM 1.0 (3.8) LF122005 No No No 12V Geolast Viton 1.0 (3.8) RLF122205 Yes 35 (2.5) No 12V Geolast Viton...

section THREE | page 54 Diaphr agm Pumps 3.19 (81.026) 1.44 (36.58) 2.25 (57.15) 7.92 (201.168) 2.43 (61.722) 2.02 (51.308) 3/8 NPT PORTS Demand Pump 3.24 (82.296) .56 (14.224) 3.63 (92.202) DUPLEX II SERIES PUMPS | FOR International & US MARKETS The Duplex II series of pumps incorporate the best technology and features developed by ITT Flojet. Everything from the back flow preventer, check valves, bearings and diaphragm assembly to the motor, have been designed to make this truly the most advanced and reliable diaphragm pump available. Higher efficiency of the pump is evident in the longer life...

section THREE | page 55 Diaphr agm PUMPS (3.0) 6 0.0 Amps (A) (6.0) 6 0 (3.0) 0.0 Amps (A) (6.0) 0 (3.0) 0.0 Amps (A) (6.0) 0 (.75) (6.0) (7.6) 0.0 Amps (A) (8.3) 0 (.75) (6.0) (7.6) 0.0 Amps (A) (8.3) 0 (3.0) 0.0 Amps (A) (6.0) ( 0 Pressure/Head psi (bar) Flow Rate gpm (lpm) Pressure/Head psi (bar) Flow Rate gpm (lpm) Pressure/Head psi (bar) Flow Rate gpm (lpm) Pressure/Head psi (bar) Flow Rate gpm (lpm) Pressure/Head psi (bar) Flow Rate gpm (lpm) Pressure/Head psi (bar) Flow Rate gpm (lpm) DUPLEX II SERIES PUMPS | FOR International & US MARKETS perf ormance Curve 1 Curve 4 Curve 2 Curve 3 Curve...

section THREE | page 57 Diaphr agm PUMPS DUPLEX II SERIES PUMPS | FOR International & US MARKETS **Available in 24V. Consult your local ITT Flojet representative for correct part number * Consult your local ITT Flojet representative Models (Continued) Model #s Model #s CE ce rtified Voltage Switc h PSI (BAR) Bypass PSI (BAR) Diap hragm Check Valve Open Flow GPM (LPM) Curve # Comments D3835B7011 Not Available* 115VAC 100 (6.9) Yes BUNA BUNA 2.0 (7.6) 5 6' (1.83m) cord D3835E7011 Not Available* 115VAC 100 (6.9) Yes EPDM EPDM 2.0 (7.6) 5 6' (1.83m) cord D3835H5011 Not Available* 115VAC 60 (4.1)...

section THREE | page 58 Diaphr agm Pumps triplex compact range | FOR International & US MARKETS The Triplex Compact range pump was designed specifically for the Agricultural market. ITT Flojet’s new three chamber design and versatile features make it ideal for sprayers and many other transfer and dispensing applications. This automatic demand pump is fitted with a sealed pressure switch and motor, is self-priming, can run dry, and can be installed in compact spaces. SPECI FICATIONS Pump Design Motor Operated 3 Chamber diaphragm Motor Design Permanent Magnet TENV (non-ventillated) Voltage 12 VDC...

section THREE | page 60 Diaphr agm Pumps Triplex Hi-Pressure Pumps | FOR International & US MARKETS ITT Flojet Triplex Hi-Pressure diaphragm pumps are capable of pressures up to 150 PSI (10.3 Bar), some of the highest pressures available in the diaphragm pump industry. This is ideal for applications such as spraying, misting, filtration, cooling, dispensing and pressure boosting. FEATU RES • Constructed from a selection of materials suitable for handling a broad range of chemicals. • Sealed pressure switch and motor • Self-priming up to 8 feet (2.4m); pump can be located above supply tank • Can...

section THREE | page 62 Diaphr agm Pumps triplex hi-flow range | FOR International & US MARKETS ITT FLO JET Triplex High Flow Series pumps are designed for a wide range of applications and are constructed from a selection of materials suitable for handling a broad range of chemicals. The Triplex High Flow pumps are self-priming and can run dry without harm. Specifications Pump Design 3 chamber diaphragm Motor Design Permanent magnet DC Voltages 12, 24 VDC, 110VAC, 230VAC Pump Rating IP 54 (splash proof) Amp Draw 5 amps @ 10 psi for 12 VDC 3 amps @ 10 psi for 24 VDC 9 amps @ 10 psi for 12 VDC...
