Centrifugal Pumps

section TWO | page 12 Centrifugal Pumps Performance CYCLONE™ STAINLESS STEEL CENTRIFUGAL PUMP FOR International & US MARKETS The combination of reliability, performance, and silent operation is what makes the Cyclone™ range the class leader and why these robust pumps are supported by many major customers and OEMs worldwide. The Hybrid Cyclone™ model was developed in response to industry application requirements and our customers needs to increase the pump’s versatility and performance criteria. Features • Heavy duty robust design • Stainless steel construction • Long life DC motor • Silent running...

section TWO | page 13 CENTRIFUGAL PUMPS Stainless Steel Pumps 4.82 (122.5) 3.07 (78.1) 3.50 (89) 6.37 (161.9) dimensional drawings Unless otherwise stated dimensions in [ ] are in mm . dimensional drawings Unless otherwise stated dimensions in [ ] are in mm . 4.39 (115.5) 3.50 (89) 8.2 (208.4) NPT 4.39 (111.5) NPT 3.50 (89) 6.26 (159.1) 3.07 (78.1) dimensional drawings Unless otherwise stated dimensions in [ ] are in mm . 50840 Series 50850 Series 50860 Series

section TWO | page 14 Centrifugal Pumps 2.36 (60) 2.71 (69) .74 (19) 3.811 (96.8) Circulation Pumps COMMERCIAL CIRCULATION PUMP 59510 SERIES | FOR International & US MARKETS dimensional drawings Performance 0 0 3.00 (0.20) 2.25 (0.15) 1.50 (0.10) 0.75 (0.05) Pressure/Head psi (bar) Amps Flow gpm (lpm) 130 (500) 260 (1000) 363 (1400) 3.75 (0.25) 0 1.2 0.9 0.6 0.3 1.5 Applications • 12.5 liters/min (3.3GPM) @ 0.12 Bar (1.74PSI) • Magnetic Drive - sealed pump chamber • Ignition protected • Meets EMC requirements • Connections for 19mm (3/4”) ID Hose • Continuously rated • Pumps water at 212°F (100°C)...

section TWO | page 17 CENTRIFUGAL PUMPS Performance NEW models Model #s Certifica tion Voltage Port DET AILS 416992 CE 230V 1Ph 50 Plain 5/8” (15mm) GPR10/15 | FOR International Markets Designed for continuous recirculation of carbonated water, aggressive chemicals, chilled water, pure or precious liquids in high pressure systems Features • Manufactured in chemically resistant thermoplastics • Operating at an optimum flow rate of 1.3 gallons/minute (5 liters/minute) • Magnetic coupling provides an energy efficient thermal shield, minimizing heat transfer to pumped fluid • Temperature stability...

section TWO | page 18 Centrifugal Pumps Performance NEMP20/12 | FOR US and International Markets For applications requiring safe, leak-free, high head, continuous flow of aggressive chemicals, acids, Alkalis, solvents, pure and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Multistage versions developed for high head with low flow • Magnetic couplings provide and energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings • Variable pump body orientation and mounting...

section TWO | page 19 CENTRIFUGAL PUMPS Performance NEMP20/18 | FOR US and International Markets For applications requiring safe, leak-free, high head, continuous flow of aggressive chemicals, acids, Alkalis, solvents, pure and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Multistage versions developed for high head with low flow • Magnetic couplings provide and energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings • Variable pump body orientation and mounting...

section TWO | page 20 Centrifugal Pumps Performance NEW models Model #s CErtifica tion Voltage Port DET AILS 456952 CE 230V 1Ph 50Hz Plain 5/8” (15mm) 456950 CE 110V 1Ph 60Hz Plain 5/8” (15mm) NEMP25/5 | FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove...

section TWO | page 21 CENTRIFUGAL PUMPS Performance NEW models Model #s CErtifica tion Desc ription Port DET AILS 406913 CE 230V 1Ph 50Hz Plain .8in (21 mm) 456957 CE 110V 1Ph 60Hz Plain .8in (21 mm) 426973 UL 100-110V 50/60Hz with UL Cable 1/2”(12.7mm) NPT ports 486910 UL 100-110V 50/60Hz with UL Cable .8in (21mm) hose barb ports NEMP40/4 | FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic...

section TWO | page 22 Centrifugal Pumps Performance NEMP40/6 | FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing. IP55 version available. • Deep groove ball bearings *Assuming maximum viscosity of 30cp. Refer to Totton Pumps for higher viscosities and specific gravities...

section TWO | page 23 CENTRIFUGAL PUMPS Performance NEMP50/7 |FOR US and International Markets For applications requiring safe, leak-free, continuous flow of aggressive chemicals, acids, alkalis, solvents, sterile and chilled fluids. Features • Manufactured in chemical resistant thermoplastics – entirely non-metallic • Magnetic couplings provide an energy efficient thermal shield, minimizing heat transfer to the pumped fluid • IPX5 standard motor housing • Deep groove ball bearings *Assuming maximum viscosity of 30cp. Refer to Totton Pumps for higher viscosities and specific gravities Specifications...
