TABLE 1 - STYLE CG & CGI TO ASME B16.20 TO SUITASME B16.5 FLANGES - IMPERIAL SIZES_8 TABLE 2 - STYLE CG & CGI TO ASME B16.2Q TO SUITASME B16.5 FLANGES- METRIC SIZES_9 TABLE 3 - INNER RING DIMENSIONS FOR STYLE CGI TO ASME B16.20_10 TABLE 4 - STYLE CG & CGI TO SUIT SMALL DIAMETER SCREWED OR SLIP-ON FLANGES_10 TABLE 5 - MAXIMUM BORE OF ASME B16.5 FLANGES_11_ TABLE 6 - STYLE CG & CGI TO ASME B16.20 TO SUIT LARGE DIAMETER ASME B16.47 SERIES B FLANGES_12 & 13 TABLE 6.1 - STYLE CG & CGI TO ASME B16.20 TO SUIT LARGE DIAMETER ASME B16.47 SERIES B FLANGES 12 & 13 TABLE 7 - STYLE CG & CGI TO ASME B16.20...

Worldwide Customer Service Network 0 Owned Manufacturing Plants Guadalajara, Mexico A Branch Offices & Warehouses Buenos Aires, Argentina Brisbane, Australia Edmonton, Alberta, Canada Cartec Sealing Technologies, Inc. Seoul, Korea Dragon Industrial Services Note: Over 500 stocking distributors in over 40 countries strategically located Engineering & Chemical Productions Lagos State, Nigeria Rotterdam, Netherlands Gasket Vedacoes Technicas Ltda. Greenville Rubber & Gasket Industrial Gasket & Supply Lake Charles Rubber Liaoning Cartec Sealing Benxi City, China Saudi Gasket Factory Jeddah, Saudi...

Introduction FIRST AND FOREMOST The concept of spiral wound gasket construction was originated by Flexitallic in 1912, inaugurating the beginning of a new era in safe, effective sealing. The primary purpose for this development was the increasingly severe temperatures and pressures used by U.S. refinery operators in the first half of the century. Metal Strip Filler Material The necessity for a gasket to have the ability to recover cannot be over emphasized. The effects of pressure and temperature fluctuations, the temperature differential across the flange face, together with bolt stress relaxation...

GASKET IDENTIFICATION GUIDE RING COLOR CODING For ease of identification, Flexitallic Spiral Wound Gaskets utilize a color coding system around the outside edge of the centering ring, thus permitting full identification of both the winding and filler materials. a solid color identification around the outside edge Light Green Stripe The gasket filler materials number of stripes placed at equal intervals around the centering ring. White Stripe Gray Stripe Flexite Super* Pink Stripe Fluorescent Green Stripe Light Blue Stripe

AVAILABLE GASKET MATERIALS METAL WINDING STRIP Stainless Steel CARBON STEEL FILLER MATERIAL Flexicarb® flexible graphite Flexite Super® Non-sintered PTFE high-temperature, sealing material is comprised of chemically exfoliat- ed and thermally exfoliated vermi- This revolutionary new product simulates the structure of exfoliat- ed graphite but with one notable exception... gaskets made with Thermiculite maintain their integri- ty, even at extreme temperatures. Thermiculite is thermally stable, ensuring against thermal oxidation, GUIDE RING MATERIAL Carbon Steel Stainless Steel Selected materials...

GASKET SELECTION What style of gasket should I select? Style CG - Utilizes an external ring which accurately centers gasket on flange face, provides additional radial strength to pre- vent gasket blow-out and acts as a compression stop. A general purpose gasket suitable for use with flat face and raised face class 2500. Above class 600 an internal ring is recommended. Style CGI - A Style CG gasket fitted with internal ring which gives an additional compression limiting stop and provides heat and corrosion barrier protecting gasket windings and preventing flange erosion. Suitable for use with...

SPECIAL GASKETS Gaskets of special design can be engineered and fabricated using the same basic fundamentals of Flexitallic Spiral Wound Gasket design and construction to cover a wide range of applications in installations for which there are no industry-wide standards. Special gaskets have been designed for valves, pumps, compressors, tur- bines, boilers, heat exchangers, etc. Consult with Flexitallic engi- neers as early in the design stage GOVERNMENT SPECIFICATIONS Flexitallic Spiral Wound Gaskets are available in accordance with Military Specifications MIL-G- latest revisions. When making...

TO SUIT ASME B16.5 FLANGES Inner rang* Sealing Element Inside Diameter Sealing Etenwnt Outside Diameter Centering Ring Outer Diameter *For Style CGI - see Table 3 for Inner Ring dimensions Gasket sizes 1/4" to 3" Class 300, 400 & 600 as well as sizes 1/2" to 2-1/2" Class 900 & 1500 are identical within their respective nominal pipe sizes, therefore inventories need not be duplicated. In accordance with ASME B16.20, Inner Rings are mandatory for the following flange designations (see Table 3). All PTFE filled gaskets All flexible graphite gaskets unless otherwise requested by the customer ASME...

TO SUIT ASME B16.5 FLANGES CENTERING RING Sealing Element Inside Diameter Sealing Element Outside Diameter Centering Ring Outer Diameter *For Style CGI - see Table 3 for Inner Ring dimensions. Gasket sizes 1/4" to 3" Class 300, 400 & 600 as well as sizes 1/2" to 2-1/2" Class 900 & 1500 are identical within their respective nominal pipe sizes, therefore inventories need not be duplicated. In accordance with ASME B16.20, Inner Rings are mandatory for the following flange designations (see Table 3). All PTFE filled gaskets All flexible graphite gaskets unless otherwise requested by the customer...

STANDARD INSIDE DIAMETERS OF INNER RINGS FOR STYLE CGI GASKETS TO ASME B16.20 TOSUITASME BIG.S FLANGES See Table 4 for small diameter screwed and slip-on flanges. DIMENSIONS IN INCHES & MILLIMETERS. TO SUITASME B16.5 & BS 1560 SMALL DIAMETER SCREWED OR SLIP-ON DIMENSIONS IN INCHES & MILLIMETERS. NOTE: The above style CG & CGI spiral wound gaskets are dimensioned to suit existing screwed or slip-on flanges for NPS 'U THE ANSWER IS ALWAYS J^XliaMc

MAXIMUM BORE OF ASME B16.5 FLANGES FOR USE WITH STYLE CG & CGI SPIRAL WOUND GASKETS This table shows the maximum bore of flanges for which the Spiral Wound gasket dimensions shown are recommended considering the tolerances involved, possible eccentric installation, and the possibility that the gasket may extend into the assembled flange bore. PRESSURE CLASS (includes nozzle" Schedule 10S bore descibed (excludes nozzle" WN flange with SW bore (excludes nozzle Note: SO = slip on and threaded; WN = welding neck; SW = standard wall. a Inner rings are required for Class 900 gaskets, NPS 24; Class...
