Product catalog summary

Introduction to Advances in Robotics
This section highlights the advancements in Fisnar's robotics technology, emphasizing features such as simple programming, three and four axes models, and compliance with CE and RoHS standards. The robots are designed for a wide range of dispensing applications and offer interpolation in all axes.

Optima Series Benchtop Robots
The Optima series includes models like F7300N and F7400N, offering work areas of 300x300mm and 400x400mm respectively. These robots feature high-resolution capabilities, continuous path and point-to-point motions, and a user-friendly teach pendant for programming. They support up to 100 programs with a memory capacity of 50,000 points per program.

Plus Series Benchtop Robots
The Plus series, including models like F4300N and F4400N, provides excellent value with proven accuracy and reliability. These robots feature upgraded components for quieter and more efficient operation, with easy program transfer via USB.

Gantry and Cantilever Series Robots
These series are suitable for conveyorized production lines and applications requiring heavier dispensing systems. They are particularly suited for the solar assembly industry, with customizable sizes and optional bar-coded identity software.

Exacta Series Benchtop Robots
The Exacta series features highly accurate, closed-loop positioning robots with ball-screw drives for low vibration and rugged efficiency. They include servo drive technology and support program storage and transfer via RS232 port.

SCARA Robot
The F2004N SCARA robot is designed for high-speed industrial applications, offering flexibility for automated manufacturing environments. It supports high-volume dispensing and pick-and-place operations.

Lotus Series Benchtop Robots
The Lotus series offers superior I/O electronics and enhanced programming software, with options for offline programming and storage.

Benchtop Rotary and Z-Axis Systems
The RT404 and Z620 systems are designed for repetitive dispensing operations, offering features like dual-head rotary dispensing and simple up-and-down motion for filling and potting tasks.

Specifications Overview
The document provides detailed specifications and features of various benchtop and gantry robots designed for dispensing applications. These robots are suitable for tasks such as form-in-place gaskets, adhesives, potting, coating, and filling. Each model is equipped with a teach pendant for programming and offers high precision and repeatability.

Key Specifications

F4500N: Working area of 500 x 500 x 150 mm, maximum speed of 800 mm/sec for X&Y axes and 320 mm/sec for Z axis, supports 100 programs with 4,000 points per program, resolution of 0.001mm.
F4200N: Compact design with a working area of 200 x 200 x 50 mm, maximum speed of 500 mm/sec for X&Y axes and 200 mm/sec for Z axis.
F5200N: Gantry robot with a working area of 200 x 200 mm, ideal for conveyor-fed automation, features a micro stepping motor, supports 100 programs with 4,000 points per program.
F3300N: Benchtop robot with a working area of 300 x 300 mm, driven by a servo motor with ball-screw design, supports 100 programs with 20,000 steps/points, resolution of 0.001mm.
F3400N: Similar to the F3300N but with a larger working area of 400 x 400 mm, supports 100 programs with 20,000 steps/points.
F3000N: Dual station models with options for 300 x 500 mm or 400 x 600 mm working areas, features dual operation for fast changeover of parts.
F2200N: Economical model with a working area of 200 x 200 mm, resolution of 0.005mm for X&Y axes and 0.0025mm for Z axis.
F2300N: Popular Cartesian robot with a working area of 300 x 320 mm, featuring a 4th axis for tool rotation.

Features

High resolution and repeatability for precise dispensing.
Continuous path and point-to-point motion capabilities.
Quick fluid-purge button and software tip alignment for easy adjustments.
Step-and-repeat functions for programming multiple identical objects.
USB and RS232 interfaces for system updates and program interchange.

Power Supply and Interfaces
Most models support AC 95-132V and AC 180-250V power supply, with USB and RS232 external interfaces for connectivity.

Applications
These robots are ideal for various industrial applications, including medical and laboratory environments, due to their precision and ease of programming.

Conclusion
Fisnar robots offer versatile and precise solutions for industrial automation, with customizable options to meet specific operational requirements. Their advanced features and robust design make them suitable for a wide range of applications.

Catalog excerpts

Dispensing Automation

Open the catalog to page 1

Introducing Advances in Robotics Optima Series Benchtop Robots F7300N 3 & 4 Axes 300 x 300mm Work Area F7400N 3 & 4 Axes 400 x 400mm Work Area F7000NV Optima Series Vision System F7900N 3 Axes 200 x 200mm Work Area Plus Series Benchtop Robots F4300N 3 Axes 300 x 300mm Work Area F4400N 3 Axes 400 x 400mm Work Area F4500N 3 Axes 500 x 500mm Work Area F4200N 3 Axes 200 x 200mm Work Area F5200N UNITOP™ 200 x 200mm Work Area Exacta Series Benchtop Robots Lotus Series Benchtop Robots Gantry Series Robots Cantilever Series Robots SCARA Robot Benchtop Rotary and Z-Axis Systems F2004N 4 Axes 300 x 300...

Open the catalog to page 2

Fisnar Robotics - Dispensing Automation-3

Introducing Advances in Robotics Features • Dots, lines, circles & arcs • Simple programming • Three and four axes models • Suitable for a wide range of dispensing • Interpolates in all axes • CE and RoHS compliant Robots F7000N Benchtop - Optima - Series including Vision System Introducing the enhanced 32 bit F7000N series with upgraded features. These systems offer improved speed, reliability and performance. F7000N Optima robots are available in three and four axes models, together with vision options for three axes systems. Fisnar robots interpolate lines and curves in all axes. Robots are...

Open the catalog to page 3

Fisnar Robotics - Dispensing Automation-4

• Ideal for form-in-place gaskets, adhesives, potting, coating and filling • Performs continuous path and point-to-point motions • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • On board 100 programs, 5 million point memory capacity, 50,000 points per program • USB connector allows system updates and program interchange between robots • Available without Teach Pendant for multiple installations. The model F7300N is a RoHS...

Open the catalog to page 4

Fisnar Robotics - Dispensing Automation-5

• Ideal for form-in-place gaskets, adhesives, potting, coating and filling • Performs continuous path and point-to-point motions. • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • On board 100 programs, 5 million point memory capacity, 50,000 points per program • USB connector allows system updates and program interchange between robots • Available without Teach Pendant for multiple installations The model F7400N dispensing...

Open the catalog to page 5

Fisnar Robotics - Dispensing Automation-6

F7000NV - Series Vision System With Program Auto Alignment Function • Auto Aligns to within 5mm of workpiece offset • Ideal for irregular dispensing route per component • High Resolution 0.001mm Touch screen programming with simulation preview. • Automatic offset of dispensing route Vision system includes: • Robot 3 axes - optional 300 x 300mm or 400 x 400mm • Touch screen PC • Software • Color camera • Camera control • Exlite Cognate in-sight white LED • CCD conversion ring (5.20.40.60mm) • CCD fixture, LSC light fixture, control system fixture • Frame capture dongle USB, extended line, LAN...

Open the catalog to page 6

Fisnar Robotics - Dispensing Automation-7

• On board 100 programs, 400,000 point memory capacity, 4,000 points per program • Performs continuous path and point-to-point motions • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • Ideal for form-in-place gaskets, adhesives, potting, coating and filling • USB connector allows system updates and program interchange between robots by flash memory card • Available without Teach Pendant for multiple installations A powerful...

Open the catalog to page 7

Fisnar Robotics - Dispensing Automation-8

F4300N - 3 Axes Working Area 300 x 300mm • On board 100 programs, 400,000 point memory capacity, 4,000 points per program • Performs continuous path and point-to-point motions • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • Ideal for form-in-place gaskets, adhesives, potting, coating and filling • Available without Teach Pendant for multiple installations • USB connector allows system updates and program interchange between...

Open the catalog to page 8

Fisnar Robotics - Dispensing Automation-9

F4400N - 3 Axes • Ideal for form-in-place gaskets, adhesives, potting, coating and filling • Performs continuous path and point-to-point motions • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • On board 100 programs, 400,000 point memory capacity, 4,000 points per program • Available without Teach Pendant for multiple installations • USB connector allows system updates and program interchange between robots The model F4400N...

Open the catalog to page 9

Fisnar Robotics - Dispensing Automation-10

F4500N - 3 Axes Working Area 500 x 500mm • On board 100 programs, 400,000 point memory capacity, 4,000 points per program • Performs continuous path and point-to-point motions • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • Ideal for form-in-place gaskets, adhesives, potting, coating and filling • Available without Teach Pendant for multiple installations • USB connector allows system updates and program interchange between...

Open the catalog to page 10

Fisnar Robotics - Dispensing Automation-11

F4200N - 3 Axes • Ideal for form-in-place gaskets, adhesives, potting, coating and filling • Performs continuous path and point-to-point motions • Quick fluid-purge button located on front panel • Software tip alignment routine for quick program offsets when changing dispensing tips • Step-and-repeat functions _ program one object only for multiple identical objects • On board 100 programs, 400,000 point memory capacity, 4,000 points per program • Available without Teach Pendant for multiple installations The F4200N is a compact and economically priced benchtop robot. Designed for medical and...

Open the catalog to page 11
