Mould cleaning machines

Product catalog summary

Overview: Finnsonic Oy provides ultrasonic cleaning systems for mould maintenance, offering a modern alternative to traditional cleaning methods. These systems are designed to be efficient, user-friendly, and environmentally friendly, eliminating the need for manual labor and solvents.

Key Features:

Short and simple wash process with no manual labor required.
High level of cleanliness without abrasion of precise edges and surfaces.
Suitable for all mould sizes, both large and small.
Constructed entirely of stainless steel with thermal and noise insulation.
Equipped with thermostat-controlled heating, drain valve, and water inlet valve.

Standard Features:

Low level protection and work support grills or bars.
Rim lip ventilation channels and protective guide rails.
Immersible transducer boxes for effective cleaning.

Optional Features:

Extraction fan and work platform.
Rinse tank with or without heating and dewatering tank with liquid sight glass.
Standard baskets, jigs for mould plates, and automatic lid.
Ultrasonic rinse, MCM, buffer tanks, and oil separators.

Product Range:

Small systems: m40im, m80im, MC-110 with varying ultrasonic power and tank volumes.
Medium systems: MC-170, MC-230, MC-360, MC-550 with increased capacity.
Large systems: MC-950, MC-1400, MC-2100, MC-2900 for high-volume cleaning needs.

Cleaning Process:

Cleaning at 80°C for 5-15 minutes using water with detergent.
Rinse with air bubble agitation at 60°C for approximately 1 minute.
Preservation with dewatering or hot passivation for approximately 1 minute.

Industry Applications: Suitable for plastics and rubber moulds, cold forming press tools, and casting foundries, effectively removing oxides, gases, release agents, metal debris, grease, oil, and other residues.

Benefits:

Significant reduction in labor input and time spent on mould maintenance.
Less wear and tear on moulds, leading to fewer quality problems and increased production.
Potential cost savings of up to 75% with Finnsonic mould cleaning systems.

References: Trusted by major companies such as BMW, Siemens VDO, Lego, Philips Components, and many others.

Catalog excerpts

Short and simple wash processՕ No manual labour required High level of cleanliness Օ No abrasion of precise edges and surfaces No solvents used Օ Suitable for all moulds, large and small User friendly process and machinery >

Open the catalog to page 1

Options Extraction fan Օ Ex-rated extraction fan Work platform Օ Rinse tank with or without heating Dewatering tank with liquid sight glass Օ Standard baskets Jigs for mould plates Օ Automatic lid Ultrasonic rinse Օ MCM Buffer tanks Օ Oil separators Standard features Totally stainlesssteel constructionՕ Thermal andnoise insulation Low level protection Օ Thermostat controlledheating Drain valve Օ Water inlet valve Work support grills or bars Օ Rim lip ventilation channels Protective guide rails Օ Immersible transducer boxes > MC-9506.010501170 x 570 x 1000MC-14008.414001550 x 550 x 1100MC-210012.021001550...

Open the catalog to page 4
