Catalog Medicair
Catalog Medicair
- Med Series: Entry-level compressors without silencing devices and driers, compact and upgradeable with a drier kit or soundproofing cabin.
- Dr Sonic Series: Super-silenced compressors with necessary accessories, ideal for minimizing noise near work areas.
- Secure starting system for easy restart after power failures.
- Compressed air free from oily residues, pollutants, condensate, and odors due to advanced filtration and drying systems.
- Internal tank surfaces coated with anti-oxidant epoxy paint for air quality and hygiene.
- Aluminum alloy cylinders with reduced friction treatment.
- Self-lubricating pistons and bearings.
- Electric motor with thermal protection and manual reset.
- Double vibration reduction system for stress-free operation.
- Dr. Sonic 110 - Med 110: Suitable for one dental chair.
- Dr. Sonic 160 - Med 160: Suitable for two dental chairs.
- Dr. Sonic 210 - Med 210: Suitable for three dental chairs.
- Dr. Sonic 320 - Med 320: Suitable for four dental chairs.
- Dr. Sonic 420 - 640: Suitable for six to eight dental chairs, available only in the silenced version.
- High-capacity fan and forced air system for enhanced cooling efficiency.
- Secure starting solenoid valve and air outlet filter for safety and performance.
- Tank vibration pads with suction cups for stable installation.
- Double handle for easier handling and motor thermal cut-out for protection.
- Energy-saving electronic control equipment for optimal compressor usage.
- Noise level: 64 dB(A).
- Models available with different voltage and frequency ratings upon request.
- Various tank capacities ranging from 6 to 100 liters.
- Single and double-cylinder compressor pumps, both lubricated and oilless options.
- Dr. Sonic 640-90F-ES-6: Features a 4500 RPM motor, 6 HP, and a noise level of 64 dB(A).
- Lab 1850: Available in 24 and 50-liter tanks, with an oilless compressor pump and motor thermal protection.
- Lab 110-160-210-320: Silenced models with 50 and 100-liter tanks, featuring thermostated electric fans.
- Dryer kits include brackets, heat exchanger fans, and condensate separators.
- Silencer kits with soundproofing lining and thermostat-controlled cooling fans.
- Various filters and condensate drains available for different models.
- Noise levels measured according to PNEUROP/CAGI PN8NTC 2.3 standards.
- Free air delivery measured as per ISO 1217 standards.
Catalog excerpts
Compressed air output by a MedicAir compressor is: Laria compressa prodotta da un compressore MedicAir Ҩ: > - free of oily residues, thanks to dry compression; - free of polluting waste, thanks to material and filters; - free of condensate, thanks to the twin-tower adsorbption drier with high drying power; - free of any smell, thanks to tank inner coating with anti-oxidant epoxy paint. > - priva di residui oleosi, grazie alla compressione a secco; - priva di scorie inquinanti, grazie ai materiali ed ai filtri utilizzati; - priva di condensa, grazie allҒessiccatore ad adsorbimento bi-colonna ad...
Open the catalog to page 2
Pistoni e segmenti speciali interamente realizzati in materiale antifrizione autolubrificantead alta scorrevolezza Carenatura di convogliamentoe protezione Casing for conveyingand protection Special pistons and segments, completely made of anti-frictionand self-lubricated material, very smooth Filtri aspirazionein materiale antiurto Intake filters made in shockproof material Maniglie di trasporto Carrying handles Rubinetto a sfera Ball cock Filtro in uscita dal serbatoio Filter at tank out Protezione internaanti-ossidazione Internal oxidation-proofedprotection Rubinetto scarico condensa Condensate...
Open the catalog to page 3
Sistema di essiccazione a doppia colonna con rigenerazione Double columns dryingsystem with regeneration > 4 size="-1">
Open the catalog to page 4
- 24 and 50-lt tank.- On-off switch. - Cable with Plug-and-Play socket. - Single-cylinder compressor pump (MK) and oilless double-cylinder (VKM) from 1.5 up to 3 HP. - Double handle for easier handling. - Motor thermal protection. - 4 vibration-damper feet. - Silenced model, on 6 and 24-lt tank.- On-off switch. - Cable with Plug-and-Play socket. - Oilless compressor pump. - Electromechanical pressure switch. - Accessories unit with pressure gauge and universal quick cock. - Large handle for easier handling. - Silenced models.- 50 and 100-lt tank. - Oilless and lubricated compressor pumps. - Wheeled...
Open the catalog to page 10
Kit essiccatore composto da: staffe, scambiatore di calore completo di elettroventola, separatore di condensa con scarico automatico, essiccatore ad adsorbimento, collegamenti elettrici e pneumatici. Kit silenziamento composto da: cabina componibile in materiale fonoassorbente, elettroventola di raffreddamento comandata da termostato. Dryer kit made up of: brackets, heat exchanger fan, condensate separator with automatic drain, adsorbption dryer, accessories for electrical and pneumatic connections. Silencer kit made up of: plastic shells with soundproofing lining, cooling fan controlled by thermostat....
