Magnetic Float Level Transmitter
Open the catalog to page 1WORKING PRINCIPLE The "Magnet Float Level Transmitter" is composed of a float and sensing rod (shown below). As the float is raised or lowered by the liquid level, the sensing rod will induce a resistance output, which is directly proportional to the liquid level. The Magnet Float Level Transmitter is a sturdy, reliable and durable device that is applicable across most industries. 1 Optional TAB-2100 (see p3) to produce a 0/4~20mA signal 1 Optional PB series bargraphic display scaling panel meter for level control and display 1 Sensing elements are protected with a plastic package for...
Open the catalog to page 2HOUSING DIMENSIONS Material : Aluminum Material : PP+Fiber Material : Aluminum Material : Aluminum Material : Aluminum Enclosure : CESI 03 ATEX 108 Material : Aluminum
Open the catalog to page 3FLOAT SPECIFICATIONS • FLOAT SPECIFICATION
Open the catalog to page 4MODEL: TAB-2110 Transducer : 12~36Vdc : Loop power 4~20mA : RL(Max)=50(Vs-8) : -40~80BC : 0~80% RH : A0.1%(25BC) : 0.01%F.S./BC : Span Adjustment 20% FS Zero Adjustment 5% FS Power Supply Output Current Load Resistance Ambient Temperature Ambient Humidity Accuracy Temperature Effect Adjustment Range Current Input PB Series Panel Meter
Open the catalog to page 5Connection Cable: Silicon cable 3Cx 1M Operating Temp.: PP tube -10°C~ 80 °C Output: 3-wire resistance output PVDF tube -20 °C ~ 120 °C Total Resistance: 1MQ (Max.) SUS tube -20 °C ~ 120 °C Float Type Tube Type Connecting Type
Open the catalog to page 6STANDARD 0 B type housing, dimension see page 2. 1 SPECIFICATION Operating Temperature: -20 ~ 120 BC Ambient Temperature: 0~70 BC Terminal Housing: Aluminum, IP65 Output:4~20mA, 2-wire Total resistance : 1MW (Max.) Tube size & Material (D) Float type & Material Suitable S.G. Measuring Range Length (unit: mm) Float Type Tube Type Connection Type Housing Type Resolution C: 6.35mm (2 wire) D: 12.7mm (2 wire)
Open the catalog to page 7ANTI-CORROSIVE 0 C type housing, dimension see page 2. material PVDF SUS pipe D Wetted parts: PVDF 1 SPECIFICATIONS Operating Temperature: PP jacket tube-10 ~ 80 BC PVDF jacket tube -20 ~ 120 BC Total resistance: 1MW (Max.) Terminal Housing: PP +Fiber, IP65 Output: 4~20mA, 2-wire Ambient Temperature: 0~70 BC Tube size & Material (D) Float type & Material Suitable S.G. Measuring Range Every unit is protected by a PP or PVDF flange to prevent the sensing rod from corrosion. Length (unit: mm) Float Type Tube Type Connection Type Housing Type Resolution D: 12.7mm (2 wire)
Open the catalog to page 80K type ATEX Explosion proof enclosure can be selected (see p2). K type housing D Wetted parts: PVDF 1 SPECIFICATION Terminal Housing: K type --- Aluminum, ATEX Ex d IIB T6 Output: 4~20mA, 2-wire Ambient Temperature: 0~70 BC Total resistance: 1MW (Max.) Tube size & Material (D) Operating Temperature: PP tube -10 ~ 80BC PVDF tube -20 ~ 120BC SUS tube -20 ~ 120BC Float type & Material Suitable S.G. Measuring Range FGA/B...Max.6M FGC/D...Max.6M FGA/B...Max.6M FGC/D...Max.6M Length (unit: mm) Float Type Tube Type Connecting Type Housing Type Resolution C: 6.35mm (2 wire) D: 12.7mm (2 wire)
Open the catalog to page 9TERMINAL HOUSING (see page 2) B : Aluminum C : P.P D : Aluminum E : AL. G : PC K : Aluminum N : SUS F : Aluminum - : None S : Others X : Aluminum CONNECTION Specification TUBE TYPE & MATERIAL 0: f12.7 (SUS304) Only available for resolution 12.7mm. Only available for resolution 12.7mm. FLOAT TYPE (see page 2) Material PIPE SHIELD 0 Total product length’s margin of error A5mm. 0 Characteristics, specifications and dimensions are subject to change.
Open the catalog to page 10ENCLOSURE EXPLOSION NEPSI PROOF No.GYJ111211 Ex d IIC T3~T6 PTB PROOF No. 05 ATEX 1028 II 2G Ex d IIB T3~T6 II 2D Ex tb IIIC PROOF T85BC~T200BC Db IP65 0 D or N type housing can be selected. f113 material PVDF material PVDF D Wetted parts: PVDF Terminal Housing: D type --- Aluminum N type --- SUS Output: 4~20mA, 2-wire Ambientt: 0~70 BC MODEL NO . FG7 Tube size (D) & Material Wetted parts: PVDF Total Resistance: 1MW (Max.) Operation Temperature: PP tube -10 ~ 80 BC PVDF tube -20 ~ 120 BC Float type & Material Suitable S.G. Measuring Range Length (unit: mm) Float Type Tube Type Connecting...
Open the catalog to page 11TERMINAL HOUSING (see page 2) D: AL N: SUS CONNECTION Specification TUBE TYPE & MATERIAL 0: f12.7 (SUS) C: f12.7 (SUS316) Only available for resolution 12.7mm. Only available for resolution 12.7mm. 4: f14 (SUS) B: f14 (SUS316) 5: f17.2 (P.P.) D: f17.2 (SUS316) 6: f16 (PVDF) E: f21.7 (SUS316) 7: f17.2 (SUS) F: f27.2 (SUS316) 8: f21.7 (SUS) 9: f27.2 (SUS) ※ For 5&6,measuring range>500mm,onlyK12.7mm resolution is available. FLOAT TYPE (see page 2) Type Material Plastic TAG 0 Total product length’s margin of error A5mm. 0 Characteristics, specifications and dimensions are subject to change. 11
Open the catalog to page 12► The float level transmitter should be mounted ► A pipe shield or an equivalent device can far away from the inlet, Any rigorous liquid help normalize the indicator actuation turbulence will produce error output signals. especially when an agitator is present. ► Another useful alternative is an L type support ► It is recommended to select the standpipe frame when the level indicator is mounted in with diameter (d) larger than the float for the concrete wall tank as figure below. installation process.
Open the catalog to page 13Mini Float/Magnetic Float Level Switch Magnetic Float Level Transmitter Side Mounting Float Switch Cable Float Level Switch Thermal Dispersion Flow Switch Paddle Flow Switch Optical Level Switch Rotary Paddle Level Switch Capacitance Level Switch Pressure Level Transmitter Vibrating Probe Level Switch Tuning Fork Level Switch RF-Capacitance Level Transmitter RF-Capacitance / Admittance Level Switch Magnetostrictive Level Transmitter By-Pass Level Transmitter FMCW Radar Level Transmitter Electromechanical Level Measuring System Ultrasonic Level Transmitter Mini By-Pass Level Transmitter...
