Swivel Joints are sealing devices which allow the leakproof transfer of fluid to and from slow and intermittent rotatingmachinery.These products are intended for use in a factory environment. Contact us if the installation is subjected to climatic conditions.A few typical applications are shown on p3. Fluids should be free of abrasive particles and water systems should be treated if scalingӔ is likely to occur. The majority of FILTON SWIVEL JOINTS use industrial standard ball bearings. These have the distinct advantage that sparebearings are available anywhere in the world. These bearings do...

ծ FLEXIBLE HOSE > Where pipework connections are made withflexible hose and movement occurs the hose can have a short life. Remove the strain by using aFILTON SWIVEL JOINT INDEXING MACHINES > A double flow FILTON SWIVEL JOINT can be used to supplypneumatic or hydraulic services for functional or sensingpurposes on a semi rotary machine table. SWIVEL JOINT HOSE REELS > A FILTON SWIVEL JOINT will allow leak prooftransfer from a bulk supply tank to a hose reel system for distribution purposes. DELIVERY SUPPLY SUPPLY 1 INDEXING TABLE SUPPLYSWIVEL JOINT FLEXIBLEHOSE PIPE MOVEMENT SUPPLY 2DISTRIBUTOR...

1.Body - steel 2.Seal - nitrile rubber 3.Circlip - spring steel 4.Ball bearings 5.Circlip - spring steel 6.Spindle - e.ni platedSPECIALS ARE AVAILABLE SEE PAGE 10 The LD SWIVEL JOINT is generally used for slow continuous rotation and intermittent angular movements for modestpressures. > FLUIDS Water, mineral oils, lubricated air and natural gas (see page 11 for specials if general gas leakage detection is not available). Sizes 32 (1 FLOW CAPACITY > NominalLiquids 3 * > Air 3 1 / > Sizem /hl/minm /h 4 Δ) to 50 (2) - Natural Gas on application.All fluids must be clean and free of abrasive and corrosiveelements....

Flow at a velocity of 3 m/s Flow of free air at 15 m/s and 6 bar > 4 28010021716512810088456011145bar Dimensions in millimetres ԑG is the designation for parallel pipe threads to B.S.2779 and ISO.228/1 (formerly B.S.P. parallel).҆The machine recess dimension should be H8 - BS.4500 and ISO.R286. FBB HJ B CBDBEGKBL I > 6 HOLES M on N PC Dia.

Flow at a velocity of 3 m/s Flow of free air at 15 m/s and 6 bar > 4 280100217165128100601114520bar Dimensions in millimetres ԑG is the designation for parallel pipe threads to B.S.2779 and ISO.228/1 (formerly B.S.P. parallel).҆The machine recess dimension should be H8 - BS.4500and ISO.R286. OHCBDBOL I > 6 HOLES M on N PC Dia.

The standard SWIVEL JOINTS shown in this technical manual do not always meet the application required, we do thereforeconsider other applications.A simple variation from our standard product may be all that is required. Simple variations can be obtained by adding the suffixcode shown below to the standard part number.We also offer a bespoke service when required. The illustrations shown below and on the opposite page gives some idea of ourcapabilities. > Connections:- Seal Materials:- EP = Ethylene propylene N = Nitrile PU = Polyurethane TF = P.t.f.e base V = Fluorocarbon NPT = American taper...

OVERSHAFT SWIVEL JOINTS > FOR RADIAL CONNECTION The illustration on the right shows a two port OvershaftSwivel Joint for fluid transfer through radial ports into the rotating shaft.Single and multiple port systems are also possible usingthe same principle. FOR AXIAL CONNECTION > The illustration on the left shows a two port Overshaft SwivelJoint for fluid transfer through axial ports in the Swivel Joint sleeve which rotates with the shaft.Alternatively the ports in the sleeve can exit radially outwards. PIGGYBACK SWIVEL JOINT > The illustration on the right shows a Piggyback Swivel Joint with...

Rotary unions are self-contained and self-supporting rotaryseals used to transfer fluids such as steam, water, air or oil, to and from rotating machinery.The range of standard models from G > 1 4 "to G.6"(BSP) forsingle or dual flow are available with a choice of ball bearings for temperatures up to 160ΰC and with carbonbearings for temperatures up to 300C. Pressure range is740mm of Hg vacuum to 70 bar with rotating speeds up to 3000 rpm. It is possible to exceed these conditions, but please consult our technical department.Filton undertake to design and manufacture special rotaryunions. > Our...
