Tightening automation. Putting the innovation into productivity, increasing reliability. Tightening module with automatic screw feeding to be integrated into automatic production systems

TIGHTENING MODULE WITH AUTOMATIC SCREW FEEDING Effective, fast and safe production cycles. Concentrated innovation for a faster, more reliable production process: these are the MCA tightening module. Suitable for large batches of the same screws. They can be integrated into existing production systems such as assembly lines, manipulators, electric Cartesian axes and collaborative robots, in order to obtain complete and independent tightening cycles using a simple external start (from PLC, dual command, start button, pedal, etc.). They offer concrete productivity benefits because:  screws are...

For all type of screws metric, self-threading, self-tapping, self-drilling, three-lobe, etc. Perfect integration on any production line: single workstations, turntables, automatic pallet lines MCA on anthropomorphic arm Installation on X,Y and Z axes in order to tighten at different working heights Can be installed on anthropomorphic scararobots and Cobots to obtain versatile solutions, that can always be reconverted and that work safely side by side of operators MCA for automatic lines with pallet transfer Multiple levels of accuracy offered by: air shut-off or DC-driven nutrunner motors, which...

Screw feeders VIBRATING BOWL They manage the entire working cycle with great flexibility: they manage tightening sequences quickly and easily, customizing them to the different applications. The INTEGRATED PLC (and also portable for ED S model), governs all machine parameters according to the assembly needs. Fastening slides They ensure a precise approach stroke of the nutrunner motor/ screw-retaining head to the component, guaranteeing high reliability of the assembled product. Can be used on manipulators, electric axes or robots and they withstand important axial thrust Devices for Cobots Designed...

VIBRATING BOWL SEGMENT CONVEYOR EasyDriver ED S - Silent Feeder • The device is designed to be fixed to the Cobot’s wrist with a bracket and can communicate with network PLC Fastening slides with OFF-SET device COMPACT FASTENING SLIDE FOR SMALL SPACES OR TO TIGHTEN FROM THE BOTTOM TO THE TOP TIGHTENING DEVICES FOR COBOT Available also with “screw at sight” function (SW models) E-MCB ELECTRIC NUTRUNNER MOTORS ELECTRIC NUTRUNNER MOTORS WITH MECHANICAL CLUTCH AND AUTOMATIC SHUT OFF ELECTRIC NUTRUNNER MOTORS WITH TORQUE/ANGLE CONTROL BY: - CURRENT CONTROL - BUILT-IN TRANSDUCER AND ENCODER WITH TORQUE/ANGLE...

screw feeders Screw feeding technology: vibrating bowl High working autonomy The vibrating bowl of models available, ensure different working autonomies and the vibrator timed system, managed by the PLC, automatically stops screw feeding when not needed thereby reducing the consumption of electricity The high selection speed allows to reach high screw feeding frequencies;t he screw shooting in a closed chamber ensures a low noise level and there are no compressed air dissipations and any screw jam is eliminated No jamming The ‘overload’ photocell makes sure no screws get jammed in the selection...

When activated, the "too full" photocell blocks the tilting bit, interrupting the loading of the screws. High working autonomy The tank capacity of about 2 liters guarantees high working autonomy. Inside the tank there is an integrated sensor that activates a visual signal on the portable PLC screen of the feeder, which will start flashing when the screws are to be loaded. Maximum silence The screw is fed by the movement of a segment conveyor inside the tank that aligns the screws and sends them towards an inclined rail that acts as an accumulator, exploiting the principle of gravity. The absence...

EasyDriver ED B screw feederFeeds screws optimally without jams. Circular, 240 mm in 0 For screws between 10 and 35 mm in lenght 1 x 240 mm 0 bowl feeds an air/electric screwdriver Vibrating bowl: Screws: • Low level sensor: device for the bowl feeder indicates when the bowl needs screw reloading. Upon request: • Basic structure to support the feeder, equipped with aluminum base plate already prepared with the holes that allow to fix the suitable feeder on it. With aluminum profiles with channels for cables and tube bundles inside the slots positioned under the support surface, is available with...

Used when the job involves large screws and also in the event of high production rates to allow the system to run unaided for longer. Vibrating bowl: Circular, 420 mm in 0 Screws: For screws between 35 and 60 mm in lenght Key: MAXI 1|1 = 1 x 420 mm 0 bowl feeds • Low level sensor: device for the bowl feeder indicates when the bowl needs screw reloading. Upon request: equipped with aluminum base plate already prepared with the holes that allow to fix the suitable feeder on it. With aluminum profiles with channels for cables and tube bundles inside the slots positioned under the support surface,...

EasyDriver ED B 1|2 screw feederCapable to feed 2 single or dual stroke fastenind slides. The work cycleinvolves selecting and firing two screws simultaneously. Vibrating bowl: Circular, 240 mm in 0 Screws: For screws between 10 and 35 mm in lenght Key: 1|2 = 1 x 240 mm 0 bowl feeds an air/electric • Low level sensor: device for the bowl feeder indicates when the bowl needs screw reloading. Upon request: • Basic structure to support the feeder, equipped with aluminum base plate already prepared with the holes that allow to fix the suitable feeder on it. With aluminum profiles with channels for...

EasyDriver ED S screw feeder - Silent Feeder Used as a much quieter alternative to vibrating bowls, is equipped with a segment conveyor that loads, aligns and sends the screws to an inclined rail optimally and without jamming. Tank: 2 Lt capacity (Approx. 2000 screws M4x16 DIN912 type) Screws: • Screw shank L = max 25 mm (6 mm to be evaluate depending on application) No wood screws with deep thread and sharp point. No screws with loose or captive washers. Key: the tank feeds an air/electric • Low level sensor: device for the bowl feeder indicates when the bowl needs screw reloading. The signal...
