Concrete test chamber

Product catalog summary

Overview: The C700B PRO concrete test chamber is a specialized climatic chamber designed for concrete curing and durability tests. It features the SPS07 flooding system for controlled testing conditions involving temperature, humidity, and water immersion.

Specifications:

Volume: 700 liters, with other volumes available upon request.
Temperature Range: -25°C to +70°C.
Humidity Range: 10% to 98%.
Electrical Power: 220-240V / 50Hz or 110V.
Internal Dimensions: Width 600 mm, Depth 670 mm, Height 1340 mm.
Outer Dimensions: Width 750 mm, Depth 980 mm, Height 2100 mm.

Features:

Height-adjustable internal shelves.
Programmable controller (revoFACE) for cyclic tests.
Forced and uniform internal ventilation.
High and low temperature and humidity alarms.
Ultrasonic humidification system with integrated RO water filtration.

Supported Tests:

Freeze-thaw durability test.
Water absorption test.
Permeability test.
Weathering resistance test.
Accelerated curing test.

Compliance: The chamber complies with various standards including EN 1367-1, EN 12390-9, EN 12371, EN 1348, EN 1324, CEN-TR 15177, EN 12091, EN 772-18, ASTM C666 Method B, EN 539-2, PN-88/B-06250, and UNI 7087.

Performance Data:

Temperature Uniformity: ±0.5 to 2.5 K depending on setpoint.
Temperature Fluctuation: ±0.1 to 0.5 K depending on setpoint.
Humidity Fluctuation: ≤3% depending on setpoint.

Accessories: The chamber can be equipped with various accessories such as a USB port for data storage, Ethernet interface for remote connection, additional temperature and humidity sensors, water filtration system, CO₂ regulation system, and more.

Additional Features:

Sound-pressure level: 60 dB(A).
Refrigerant gas: R290.
Safety: Includes audio-visual alarms and independent adjustable temperature safety devices.

Catalog excerpts

Environment Makers FDM Environment Makers Products Climatic and Thermostatic Chambers Growth Chambers Environmental Chambers Custom Products F.lli Della Marca S.r.l. Viale Arcangelo Ghisleri 00176 Rome (Italy) Technical specifications are subject to change. Images for illustrative purposes. Non-binding renderings.

Open the catalog to page 1

Description The C700B PRO concrete test chamber is a specialized climatic chamber for concrete curing and durability tests. Equipped with the SPS07 flooding system, it enables testing under controlled conditions of temperature, humidity, and water immersion. The SPS07 system consists of two stainless steel tanks: one internal (112 L) for sample immersion and one external for automatic water management. It supports up to 9 concrete cubes of 150×150×150 mm. Supported test types include: • • • • • Freeze-thaw durability test Water absorption test Permeability test Weathering resistance test Accelerated...

Open the catalog to page 2

Model Temperature range without humidity [°C] Temperature performance Temperature uniformity depending on setpoint [± K] Temperature fluctuation depending on setpoint [± K] Average heating-up rate according to EN 60068-3-5 [K/min] Average cooling down rate according to EN 60068-3-5 [K/min] Performance Data Climate Temperature range [°C] humidity is on Humidity range in according to Chart*1 [% r.h.] Humidity fluctuation depending on setpoint [± %] Humidification system Water filter Max Water hardness permitted ≤3 Ultrasonic humidification system Water softening filter and replaceable cartridge...

Open the catalog to page 3

SPS07 Flooding System Internal Tank (gross volume) [L] Net Volume of Internal Tank [WxDxH] Sample Capacity External Tank With heating and pumping system Structure and insulation Exterior material Stainless steel AISI 304 Internal material Stainless steel AISI 304 Shelf grill Removable and height adjustable stainless steel plastic coated forced ventilation Safety Temperature Class 2 independent adjustable temperature safety devices (DIN 12880) Electrical data Rated Voltage [V] Nominal power [kW] Unit fuse [A] Phase (nominal voltage) Main Accessories • • • • • • • • • MINI T-RH – Temperature/Humidity...

Open the catalog to page 4
