FCI
Industry Standard Connector - Basics +

Industry Standard Connector - Basics +

Product catalog summary

Overview: The FCI product catalog provides a comprehensive guide to the company's range of connectors, emphasizing high-quality and innovative solutions for both consumer and industrial applications. It is designed to assist users in product selection, accessing documentation, obtaining technical support, ordering samples, and retrieving commercial information through the Basics+ platform.

Key Sections:

Product Selection: Offers an overview of standard Basics+ products with additional options available through an online search feature.
Documentation Access: Users can download data sheets, product drawings, and specifications by entering the product number on the website.
Technical Support: Inquiries are addressed within 24 hours via an email hotline.
Sample Ordering: Online ordering of samples is available for immediate product testing.
Commercial Information: Registered customers can access pricing, packaging, order quantities, and lead times online.
Product Range: Includes board-to-board, wire-to-board, and cable-to-board connectors with detailed specifications.

Product Specifications:

BergStik® Unshrouded Headers: Available in various configurations with specifications including current rating, insulation resistance, and operating temperature range.
Minitek™ and Dubox™ Connectors: Include unshrouded headers, receptacles, and shunts with detailed technical data.
PV™ and Quickie® Systems: Offer high reliability with features like latching systems and compatibility with IR reflow soldering processes.

Application Overview: Highlights the versatility and adaptability of FCI's connector products for board-to-board, wire-to-board, and cable-to-board solutions.

New Products: Features new products such as the PV™ latching system and SMT Quickie® Low Profile Header, designed for high reliability and modern soldering processes.

Technical Specifications:

Electrical Performance: Current rating of 3 A continuous, insulation resistance of 5000 MΩ minimum, and dielectric withstanding voltage of 1500 V.
Mechanical Performance: Pin retention to housing is 8.88 N minimum, with a retentive leg insertion force greater than 44.48 N max.
Operating Temperature Range: -65°C to +125°C.
Materials: Housing made of high-temperature black thermoplastic with a flammability rating of UL 94 V-0. Pins are made of phosphor-bronze with gold or tin plating over 1.27 µm nickel.

Packaging and Reference Information:

Products are packaged in bags, with reference files E66906 and LR46923.
Specifications are subject to change without notice.

Mating Data:

Includes Dubox™ Crimp-to-wire contacts and housings, vertical and horizontal receptacles, and Quickie™ IDC receptacles.

Processing Information:

Compatible with wave, vapor-phase, and IR reflow soldering processes.

RoHS Information:

Products are RoHS compliant according to the European Union Directive 2002/95/IEC.

Typical Applications:

Includes solder side and mating side applications with specific dimensions provided.

Part Number and Layout Information:

Various part numbers are provided with specifications for pin style, plating, and recommended PCB layout.

Technical Data for Specific Products:

BergStik® Unshrouded Headers: Offers a variety of stack heights in 0.5 mm increments, with high-temperature plastic and selective plating.
Shunts: Dual-beam contacts for added reliability, with a current rating of 2.5 A max per contact and a dielectric withstanding voltage of 800 V.
Dubox™ Receptacles: Features a pre-stressed, dual beam design for low insertion force and a 4-wall contact design for signal protection.

Specifications:

Dielectric Withstanding Voltage: 500 V rms for some components, 1500 V for others.
Current Rating: Ranges from 1 A to 3 A continuous depending on the component.
Insulation Resistance: Minimum 10,000 MΩ to 50,000 MΩ.
Operating Temperature Range: -65°C to +125°C.
Flammability Rating: UL 94 V-0.
RoHS Compliance: All products are RoHS compatible according to the European Union Directive 2002/95/IEC.

Mechanical Performance:

Pin Retention to Housing: Minimum 20 N.
Mating Cycles (Durability): 100 cycles for most components.

Packaging:

SMT components are available in tape-and-reel packaging, PiP components in tubes.

Processing Information:

Compatible with wave, vapor-phase, and IR reflow soldering processes.

Typical Applications:

Ideal for daisy chain applications and other electronic interconnect solutions.

Product Variants:

Quickie™ IDC Receptacles: Available in various positions and configurations.
Minitek™ Headers: Available in unshrouded, right angle, and stacking configurations with various plating options.

Reference Information:

File numbers E66906 and LR46923 are associated with these products.
Product specifications and drawings are available by 5-digit base part number.

Note: Specifications are subject to change without notice.

Technical Data Overview:

Physical Specifications: Housing made of high-temperature, cream-colored thermoplastic with a flammability rating of UL 94 V-0. Pins are made from phosphor-bronze, plated with gold over 1.27 µm nickel.
Electrical Performance: Current rating of 2 A continuous, insulation resistance of 1000 MΩ minimum, contact resistance of 25 mΩ maximum, dielectric withstanding voltage of 650 V, and a voltage rating of 200 V.
Mechanical Performance: Rated for 100 mating cycles and operates within a temperature range of -40°C to +125°C.
Packaging: Standard packaging includes tubes and tape-and-reel options, with specific configurations for different positions.

Mating Data:

Includes Minitek™ contacts and housings, vertical receptacles, shunts, and IDC receptacles.

Processing Information:

Compatible with wave, vapor-phase, and IR reflow soldering processes.

RoHS Information:

The product complies with the European Union Directive 2002/95/IEC for RoHS compatibility.

Typical Applications:

Applications include various Minitek™ components such as shrouded right angle headers, crimp-to-wire contacts, and IDC receptacles.

Part Numbering System:

Details on part numbers, plating options, and packaging configurations are provided for different Minitek™ components.

Application Equipment:

Includes hand tools and crimping equipment for Dubox™ and Minitek™ contacts, with specifications on operation, tooling, and application rates.

Catalog excerpts

Industry Standard Connector - Basics +-3

The most industry-popular part numbers.Available from stock at our key distributors Industry-popular connectors.Components held in stock by FCI and assembled immediately to meet your order > The comprehensive selection of products found in this catalog > A huge range of specials to meet the most demanding design needs > Technical / Application Support / Drawings / Specifications / Samples: www.fciconnect.com/basics

Open the catalog to page 3

Industry Standard Connector - Basics +-5

The PV latching system is a highreliability system, particularly suited for shock and vibration applications. Pages 38-44 SMT Quickie > ٮ Low Profile Header. Page 46-47 The Pin-in-Paste Quickie > Low ProfileHeader features a special high tempe- rature housing and is compatible with IR reflow soldering processes. Page 46-47 > Technical / Application Support / Drawings / Specifications / Samples: www.fciconnect.com/basics

Open the catalog to page 5

Industry Standard Connector - Basics +-7

P. 16-19 P. 56-57 P. 24-29 P. 60-61 P. 16-19 P. 30-31 = 2.54mm = ThroughMount = 2.00mm = SurfaceMount > Technical / Application Support / Drawings / Specifications / Samples: www.fciconnect.com/basics

Open the catalog to page 7

Industry Standard Connector - Basics +-9

P. 50-51 P. 52-53 P. 48-49 P. 48-49 P. 70-71 P. 70-71 P. 56-57P. 70-71P. 66-67 P. 64-65 P. 44-47P. 50-51 = 2.54mm = ThroughMount = 2.00mm = SurfaceMount > Technical / Application Support / Drawings / Specifications / Samples: www.fciconnect.com/basics

Open the catalog to page 9

Industry Standard Connector - Basics +-10

Physical Electrical Performance min.Dielectric withstanding voltage: 1500 V Housing: High temperature, black thermoplastic Flammability rating: UL 94 V-0 Pin: Phosphor-bronze Plating: Gold or tin over 1.27 εm (50 ") nickel Current rating: 3 A continuous Insulation resistance: 5000 M Mechanical Performance Pin retention to housing: 9 N min. Operating Temperature Range -65հC to +125C Packaging Standard: Bags Optional:Tubes orTape-and-reel with pick-up cap(SMT pin style 01 only) Reference Information File no. E66906File no. LR46923Product drawing: By 5-digit base part number Product specification:...

Open the catalog to page 10

Industry Standard Connector - Basics +-11

02 to 36 = Single row TMT Through mount77311 03 to 17 = Single Row SMT = Single Row 04 to 72 = Double row TMT 77313 = Double Row 04 to 50 = Double Row SMT > Surface mount Through mount 08 to 50 = Double Row SMT with pegs Surface mount95293 > Pin styleMating Pin styleMatingSolderOAL = Single Row 01 5.84 01 5.842.4110.80 95278 = Double Row 02 8.08 18 5.843.0511.43 OptionPackaging 98401 = Double Row with pegs 02 5.843.4211.80 -Plastic bag 27 6.602.6611.82 A Tape-and-reel with pick-up cap 1 = 0.76 m (30յ") gold on mating area, tin on solder side 22 7.753.0613.35 B Tube with pick-up capavailability...

Open the catalog to page 11

Industry Standard Connector - Basics +-12

Physical Housing: High temperature, black thermoplastic Flammability rating: UL 94 V-0 Pin: Phosphor-bronze Plating: Gold or tin over 1.27 εm (50 > ") nickel Electrical Performance min.Dielectric withstanding voltage: 1500 V Current rating: 3 A continuous Insulation resistance: 5000 M Mechanical Performance Pin retention to housing: 8.88 N (2 lbf) min. Retentive leg insertion force: >44.48 N max.Retentive leg board retention: 2.22 N Operating Temperature Range -65հC to +125C Packaging Standard: Bags Optional:Tubes orTape-and-reel with pick-up cap > Reference Information Compatible with wave,...

Open the catalog to page 12

Industry Standard Connector - Basics +-14

Continuously molded and reeledHigh temperature plastic Various lengths cut from 1 part numberBenchtop machine cuts, polarizes, and applies retentive leg > Physical Housing: High temperature, black thermoplasticFlammability rating: UL 94 V-0 Pin: Phosphor-bronzePlating: Gold or tin over 1.27 m (50 յ") nickel Electrical Performance min.Dielectric withstanding voltage: 1500 V Current rating: 3 A continuous Insulation resistance: 5000 M Mechanical Performance Pin retention to housing: 8.88 N (2 ibf) min. Operating Temperature Range -65C to +125аC Packaging Reel Reference Information File no. E66906File...

Open the catalog to page 14

Industry Standard Connector - Basics +-16

High temperature plasticSelective plating > Physical Housing: High temperature, black thermoplastic Flammability rating: UL 94 V-0 Pin: Phosphor-bronzePlating: Gold or tin over 1.27 εm (50 > ") nickel Electrical Performance Current rating: 3 A continuousInsulation resistance: 5000 M min.Dielectric withstanding voltage: 1500 V Mechanical Performance Pin retention to housing: 8.88 N min. Operating Temperature Range > -65հC to +125C DuboxЙ Crimp-to-wire contacts34 Dubox Crimp-to-wire housings36 Duboxٙ Vertical receptacles24 Dubox Low profile vertical receptacles26, 28Duboxٙ Horizontal receptacles30...

Open the catalog to page 16

Industry Standard Connector - Basics +-17

Through mount77315 02 to 36 = Single row TMT = Single Row 04 to 72 = Double row TMT 77317 = Double Row > Pin style 7731577317MatingSolder 01 03 5.842.41 18 04 5.843.05 24 12 6.752.90 1 = 0.76 m (30յ") gold on mating area, tin on solder side 4 = tin 8 = 0.38 m (15յ") gold on mating area, tin on solder side 0,62 square pin 0,62 square pin > Dimensions in mm > 2.54 mm(.100") Technical / Application Support / Drawings / Specifications / Samples: www.fciconnect.com/basics >

Open the catalog to page 17

Industry Standard Connector - Basics +-18

Physical Housing: High temperature, black thermoplastic Flammability rating: UL 94 V-0 Pin: Phosphor-bronze Plating: Gold or tin over 1.27 εm (50 > ") nickel Electrical Performance min.Dielectric withstanding voltage: 1500 V Current rating: 3 A continuous Insulation resistance: 5000 M Mechanical Performance Pin retention to housing: 8.88 N min. Retentive leg insertion force: > 44.48 N max.Retentive leg board retention: > 2.22 N Operating Temperature Range -65հC to +125C Packaging Bags Reference Information > File no. E66906File no. LR46923Product drawing: 55101 or 55102 Product specification:...

Open the catalog to page 18

Industry Standard Connector - Basics +-19

1 = 0.76 m (30յ") gold 01 to 36 = Single row 2 = 0.38 m (15յ") gold 02 to 72 = Double row 4 = tin Single RowDouble Row > PostTail Base PNmm(in.)mm(in.) 68015 5.840.2302.290.095 68016 5.840.2303.050.120 > PostTail Base PNmm(in.)mm(in.) 68020 5.840.2302.410.095 68021 5.840.2303.050.120 0,62 square pin 0,62 square pin Dimensions in mm > 2.54 mm(.100") Technical / Application Support / Drawings / Specifications / Samples: www.fciconnect.com/basics >

Open the catalog to page 19
