VU Series

Product catalog summary

Overview
This document outlines the specifications and guidelines for FASTER® check valves used in hydraulic systems, designed to ensure safety by shutting off the line at a preset crack pressure.

Specifications
Check valves are available in female, male threads, and compact versions. The standard crack pressure is 35 kPa (5 PSI), with options up to 950 kPa (138 PSI). Materials include AISI 316 Stainless Steel and steel with zinc plating and Cr III passivation. Seals are made from NBR Nitrile Rubber, with options for Viton, Neoprene, and EPDM. Operating temperature ranges from -25°C (-13°F) to +125°C (+257°F).

Features
Valves feature an elastomeric seal for reliable sealing under various conditions. The VU...S Series includes throated check valves for calibrated flow in one direction, while the VUC series offers metal sealing for enhanced durability.

Applications and Benefits
Designed for hydraulic systems to prevent malfunction and damage. Ensure compatibility with pressure and flow requirements before use. Original FASTER® spare parts are recommended for maintenance.

Recommendations
Users must ensure the product meets application requirements and maintain efficiency. FASTER® and its distributors are not liable for damages due to improper use. Product specifications are subject to change without notice.

Ordering Information
A wide range of thread sizes and settings are available. Custom settings and mixed thread options can be requested. A Product Definition Form is available to assist in selecting the appropriate product.

Guarantee
All products conform to UNI EN ISO 9001 and ISO/TS 16949 standards. FASTER® products are globally distributed through qualified distributors.

Technical Specifications
The document provides technical data for various sizes of check valves, including rated flow, maximum working pressure, and minimum burst pressure. The safety factor is specified as 1:4 for general use and 1:2 for static pressure.

Pressure Drop
Pressure drop values are based on a standard setting of 35 kPa.

Threaded Ends
Available threaded ends for different sizes are listed, with specifications for inlet and outlet threads according to ISO and SAE standards.

Settings and Spare Parts
VUC check valves are available with various settings, and spare parts kits are provided for maintenance and modification of crack pressure settings. The document includes a table for ordering codes and setting ranges.

Special Series
Special series such as VUCC micro check valves, VU... S throated check valves, and BVU manifold blocks are described, highlighting their design and application flexibility.

Quality and Distribution
FASTER® quick-release couplings conform to UNI EN ISO 9001 and UNI ISO/TS 16949 standards, ensuring quality and reliability. They are distributed globally through a network of qualified distributors.

Contact Information
Contact details for FASTER offices in Italy, Germany, the UK, France, and the USA are provided.

Catalog excerpts

FASTER Pressure settings could varywithin a range of ձ10%.In case of seals damage it isnecessary to replace them by ՕThe recommendations stated in this catalogue do not consider all risk factors in every possible application of > products aredesigned and producedin conformity with the regulations of Quality Managing Systemaccording to UNI EN ISO 9001 and UNI ISO/TS 16949. FASTER ΕThey bear the FASTER > Faster suggestions.ΕThe customer has to make surethat all requirements of chosen parts are respected, efficiency is maintened and the end user is informed about useand maintenance operations. >...

Open the catalog to page 3

▲ Features Shut-off system: valve with elastomeric sealՕThe elastomeric seal guarantees perfect and reliable sealing Standard setting 35 kPa (5 PSI) Օ Other settings and kits to update crack pressure availableup to 950 kPa (138 PSI) (see accessories page 14) Versions with female threads (VU...F series) Օ Versions with male threads (VU...M series) Special versions available on request Օ Also available in AISI 316 Stainless Steel (see at page 9) Also available with calibrated orifices (VU...S) * Safety factor = 1:4 - For static pressure safety factor 1:2 > բֲ Technical data > ▲ Accessories and...

Open the catalog to page 6

SizeCodeThread A1 (inlet)Thread ؘ A2 (outlet)Standards > On request mminc.Lmminc. > The descriptions and illustrations in this catalogue are for information only and are not binding. 7 >

Open the catalog to page 7

▲ Features Shut-off system: valve with elastomeric sealՕCompletely made of AISI 316 Stainless SteelThe elastomeric seal guarantees perfect and reliable sealing ՕStandard setting 35 kPa (5 PSI) Special versions available on request * Safety factor = 1:4 - For static pressure safety factor 1:2 > բֲ Technical data > ▲ Accessories and spare part kit Size DNNominaldiameter Ratedflow Max.workpressure Minimum burst pressure >

Open the catalog to page 9

SizeCodeThread A1 (inlet)Thread ؘ A2 (outlet)Standards > On request mminc.Lmminc. > The descriptions and illustrations in this catalogue are for information only and are not binding. 10 >

Open the catalog to page 10

Availablewith severalsettings Heavydutymanufacture ▼▼ ▼ ▼ ▼ ▼ ▼▼▼ ▼ ▼ ▼ > ▼▼ ▼ ▼ ▼ Wide rangeof threads > ▼ ▼ ▼ ▼ In the picture ▼▼ ▼ ▼ ▼ ▼ Special valvewith metalsealing Compactdesign > ▲ The descriptions and illustrations in this catalogue are for information only and are not binding. 11 size="-1">

Open the catalog to page 11

▲ Features Shut-off system: valve with metal sealingՕThe metal sealing guarantees perfect and reliable sealing Standard crack pressure 35 kPa (5 PSI) Օ Single piece body:extremely compact and robust Special versions available on request * Safety factor = 1:4 - For static pressure safety factor 1:2 > բֲ Technical data > ▲ Accessories and spare part kit Size DNNominaldiameter Ratedflow Max.workpressure Minimum burst pressure > Please contact FASTER Research & Development Dept. mm inc. l/min GPM MPa > PSI MPa PSI 3/806 5 0.20 20 5.3 40 5800 160 23200 1/2Ԕ08 7 0.28 40 10.6 40 5800 160 23200 3/412...

Open the catalog to page 12

SizeCheck valveSpare part kit (#)Setting range 1/404VU 14...KIT VU 14F...Among the whole setting range3/8Ԕ06VU 38...KIT VU 38F...Among the whole setting range1/208VU 12...KIT VU 12F...From 10 to 550 kPa From 600 to 950 kPa3/4Ԕ12VU 34...KIT VU 34F...Among the whole setting range116VU 1...KIT VU 1F...Among the whole setting range1-1/4Ԕ20VU 114...KIT VU 114F...Among the whole setting range1-1/224VU 112...KIT VU 112F...Among the whole setting range2Ԕ32VU 2...KIT VU 2F...Among the whole setting range #For the suffix indicating the setting please refer to the table at page 8. Example - kit code for...

Open the catalog to page 14

sales offices. > ▲ VUCC series > Micro check valves,cartridge design characterized by a very compact design, VUCC check valves are suitable for mounting in Metric, BSP or SAE housings. Designed in two versions for radial or axial flow, VUCC check valves can be customized for specific housings. For products information and ordering codes please contact our > ▲ VU...S series Throated check valves to guarantee a minimum calibrated flow.VU...S series valves are available in several models: calibrated flow in one direction,no flow in the opposite oneՕcalibrated flow in one directionand total flow...

Open the catalog to page 15

UNI EN ISO 9001 Cert.n2905 ISO/TS 16949 CAT0119/04/06-GB I - FASTER S.p.A. USA - FASTER Inc. MAUMEE, OH 43537-9505 - 6560 Weatherfield, Ct.(+1) 419-868-8197 - (+1) 800-231-2501 - Fax (+1) 419-868-8360www.fasterinc.com - [email protected] I-26027 RIVOLTA DВADDA(CR) Italy - Via L.Ariosto, 7(+39) 0363.377211 - Fax (+39) 0363.377333www.faster.it - [email protected] F - FASTER - Franois Divet F-35200 RENNES- 11, Rue Jean Bras(+33) (0) 2.99.51.44.94Fax (+33) (0) 2.99.51.00.13 [email protected] D-BENELUX - FASTER - Jrgen Gamers UK - FASTER - Richard Bennett D-40764 LANGENFELD GER - Ursulaweg,...
