Overview: The document outlines specifications and guidelines for the 'Standard' series quick-release couplings, specifically the ANV and HNV series, which comply with ISO 7241-1 standards. These couplings are designed for agricultural and industrial applications, ensuring global interchangeability and reliability.

Specifications:

Interchangeability: Conforms to ISO 7241-1 standard.
Materials: Available in AISI 316 stainless steel and brass, with seals in NBR (nitrile rubber) and PTFE back-up rings.
Design: Features include a high number of latching balls, rolled surfaces for low roughness, hardened valve bodies, and a carbonitrited sleeve on female couplings.
Threads: Available in BSP, NPT, SAE, and metric.

Procedures:

Connection and Disconnection: Achieved by pulling back the sleeve, ensuring no pressure in both halves during these operations.
Maintenance: Regular lubrication of seals and checking of threads for correct sealing is recommended. Damaged components should be replaced with original spare parts.

Recommendations:

Ensure compatibility with pressure and flow characteristics of the application.
Protect disconnected couplings with original plugs to prevent dirt inclusion.
Use decompression valves if pressure cannot be decreased before disconnection.

Technical Data:

Working Temperatures: Standard seals in NBR from -25°C to +125°C.
Pressure Ratings: Detailed pressure ratings and flow rates are provided for various sizes, ensuring suitability for different applications.

Responsibilities:

Faster and its distributors are not liable for damages due to improper use or maintenance.
Customers are responsible for ensuring product suitability and informing end-users about maintenance operations.

Ordering Information: A comprehensive ordering chart is provided, detailing available item codes and specifications for different thread types and sizes.

Materials and Construction: The document details materials such as steel, high-grade carbon steel, and brass, with treatments like zinc plating and Cr III passivation. Seals are available in standard oilproof NBR, with options for Viton, Neoprene, and EPDM. Antiextrusion rings are made from pure PTFE.

Performance and Standards: Working temperatures for standard seals range from -25°C to +125°C. Pressure ratings include maximum working pressure and minimum burst pressure, with a safety factor of 1:4 for static pressure.

Features and Functionality: Quick-release couplings feature a connection and disconnection system by pulling back the sleeve, a poppet valve shut-off system, and are designed for connectability without pressure. Disconnection under pressure is not allowed, and the products are interchangeable with the US market.

Technical Data: Includes a pressure drop graph tested to ISO 7241-2 specifications, with details on rated flow, fluid spillage, force to connect, and nominal diameter for various sizes ranging from 1/4” to 2”.

Accessories and Spare Parts: References to accessories and spare part kits are provided, with further details available on specific pages.

Series Overview:

NZ Series: Designed for the New Zealand transport market, these couplings have a 1” BSP threaded size, a working pressure of 23 MPa, and a flow rate of 160 litres per minute (42 GPM).
NVB Series: Tailored for the American market, these couplings feature a safety lock, with sizes of 1/4” BSP, BSPT, NPTF, and SAE threaded. They have a working pressure of 40 MPa and a flow rate of 8 litres per minute.
CPV-CNV and CVV Series: Primarily used in agriculture, these couplings conform to ISO 7241-1 part A standards for global interchangeability. They feature a push-pull system for easy connection and disconnection.

Agricultural Series: Designed for agricultural applications, these couplings are interchangeable and conform to ISO 7241-A and ISO 5676 standards. They allow connection under pressure, feature a push-pull connection, and have a breakaway feature for disconnection.

Quality and Distribution: All FASTER® quick-release couplings are manufactured in compliance with UNI EN ISO 9001 and UNI ISO/TS 16949 standards. They are distributed worldwide through a network of qualified distributors.

Contact Information: For ordering codes and further technical details, contact Faster Research & Development Dept. or refer to the specific catalogues available in multiple languages.

Catalog excerpts

Quality ManagingSystem according to UNI ENISO 9001 and UNI ISO/TS 16949. Faster CustomerService. When connecting and disconnecting, be sure there is no pressure in both halves.Օ When a disconnection is performed, there could be a > quick-release couplings are designed and produced in conformity with the regulations of Ε They bear the FASTER residual pressure that dependingon temperature and position could reach high values. This prevents opening the valveand, as a consequence, the connection is not possible. > ծ couplings. The final choice of the product is under customerՒs responsibility who...

Open the catalog to page 3

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part A standard(1/2size only)ԕ Balls latching system Guidevalve with mechanical backstop Օ Perfect interchangeability with ball valve couplings NS series > ▲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage >

Open the catalog to page 6

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: ball valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part A standard(1/2size only)ԕ Balls latching system Metal to metal sealing Օ Guidevalve with mechanical backstop Perfect interchangeability with poppet valve couplings NV series > բֲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage...

Open the catalog to page 8

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: free flowՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part A standard(1/2size only)ԕBalls latching systemFor small quantity orders NL couplings are supplied with the NVcoupling body (see pages 6-7) Data in the following tables are referred to minimum order quantities and FASTER stock availability > բֲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow...

Open the catalog to page 10

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valve (SV series) or ball valve (SS series) Օ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part A standard(1/2size only)ԕBalls latching systemAdditional safety sleeve to prevent accidental disconnection ՕPerfect interchangeability with NV and NS series couplings > ▲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure...

Open the catalog to page 12

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part A standard Balls latching systemՕ Guidevalve with mechanical backstop > ▲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage > Connected Male Female l/min GPM N lb MPa PSI MPa PSI MPa PSI MPa PSI cc max. 1/404 4.5 0.18...

Open the catalog to page 14

▲ Features Connection system: pulling back the sleeveՕ Disconnction system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part B standardBalls-latching systemՕGuidevalve with mechanical backstop Suitable for industrial applications ՕAvailable versions in AISI 316 stainless steel (HNV...2 series)and in Brass (HNV...5 series)Available versions for free flow (HNL series) and with additionalsafety sleeve (HSV series)ՕSeals in Viton, EPDM and other compounds > ▲ Special...

Open the catalog to page 16

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part B standard Balls latching systemՕ Completely made of AISI 316 stainless steel Polishing treatment is a standard Օ Seals in Viton, EPDM and other compounds > ▲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage > Connected...

Open the catalog to page 18

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 7241-1 part B standard Balls latching systemՕ Completely made of brass according to EN 12164 standard Seals in Viton, EPDM and other compounds > բֲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage >

Open the catalog to page 20

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: US market Balls latching systemՕ Internal components with increased flow section > ▲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage >

Open the catalog to page 22

▲ Features Connection system: pulling back the sleeveՕ Disconnection system: pulling back the sleeve > Shut-off system: poppet valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: US market Balls latching systemՕ Completely made of brass according to EN 12164 standard > ▲ Accessories and spare part kit See at pages 28-30. > ▲ Technical data Size DNNominaldiameter Ratedflow Force toconnect Max.workpressure Minimum burst pressure Fluidspillage >
