If the connection phase is carriedout at residual pressure,the required force could behigher than the human one, therefore it is necessary to reducethe internal pressure of thecoupling.Օ Dirt on male or female part duringcoupling operations can causeseals damage. In order to ensure long service life of seals it is recommendedto carefully clean mating parts,easily and quickly done thanks to coupling design.Օ In case of seals damage it isnecessary to replace them by The recommendations stated inthis catalogue do not considerall risk factors in every possibleapplication of ՕAll FASTER > quick-releasecouplings...

▲ Features Connection system: pushing the male couplingՕ Disconnection system: pulling back the sleeve Shut off system: flat valveՕ Connectability: without pressure Disconnection under pressure: not allowedՕ Interchangeability: according to ISO 15171-1 standardAllows a quick and preventive check by monitoring the internalsystem pressure in several parts of the circuitՕMale coupling to be assembled on the hydraulic line Female coupling to be assembled on the diagnostic equipment ՕBalls latching system Dust protection for male coupling ՕWide range of threads and connections Special versions available...

On request > The descriptions and illustrations in this catalogue are for information only and are not binding. 7 >

On request ORFS=O-RING FACE SEAL ORFS MaleFemale Thread (Nut) ORFS TerminaleInnesto maschioFiletto ANorme > On request ORFS=O-RING FACE SEAL > The descriptions and illustrations in this catalogue are for information only and are not binding. 8 >

Male Thread ORFS ORFS Male Threaded endMale couplingThread AStandards > On request ORFS=O-RING FACE SEAL Bulk Head Male Thread Male > Cmminc.Tmminc.Pmminc.CHMmminc.Threaded endMale couplingThread AStandards DF 04-12/14 SAE M9/16ؔUNFISO 8434-360,32,3717,750,7031,51,24190,75DF 04-12/38 SAE M11/16UNISO 8434-362,82,4717,750,7031,51,24190,75DF 04-12/12 SAE M13/16ԔUNISO 8434-377,13,0417,750,7036,51,44190,75 > On request ORFS=O-RING FACE SEAL > The descriptions and illustrations in this catalogue are for information only and are not binding. 9 >

This particular version of female coupling is characterized by an extended sleeve. Purposely designed to help connection and disconnection when the male couplings are placed in a position very difficult to be reached. > Please refer to the following table for ordering codes. > ▲ Dust protection Original FASTER > dust protections keep the mating surfaces cleanand protect the latching elements when the coupling halves are disconnected. Protections for DF couplings are made of oilproof PVC which endures temperatures ranging from -30ΰC (-22F) to +100аC (+212F). > SeriesSizeDust protection in PVCFemale...
