CPV-CNV-CVV Series
20Pages

CPV-CNV Series CVV Series Threaded sleeve for screw connection.Օ Screw-on system ensures connection under pressure. Friction ring to prevent accidentaldisconnection under heavy vibrations.Օ Interchangeable to German market. Internal components purposelydesigned to reduce turbolences and consequent pressure drop.Օ Rolled surfaces in sealing area to ensure the lowest roughness. Hardened valve bodies to standcrashes.Օ Contenitive washer with specialseal to reduce risk of extrusion. Guidevalve with mechanical backstop to prevent partial enclosures of valves due to peaks and reverse flow.Օ Parts...

Improper use and incorrectmaintenance of products with high internal working pressures could cause malfunctioning and damage topersons and machines. Therefore it is necessary to carefully conform to the simpleinstructions contained in this catalogue.For any further information plea-se contact ՕWhen connecting and disconnecting CPV-CNV series,be sure there is no pressure in both halves. When a disconnection is performed, there could be a ՕThe recommendations stated in this catalogue do not consider all risk factors in everypossible application of All FASTER > ծ quick-release couplings are...

▲ Dust protections CPV-CNV series couplings) have the > YELLOW standard colour.Polyethylene protections (suitable for CPV-CNV series couplings) and Polyethylene (suitable for Original FASTER > protections are very useful:they keep the matingsurfaces clean and protect the latching elements when the coupling halves are disconnected. Protections made of oilproof PVC (suitable for CVV CVV series couplings) have the series couplings)endure temperatures ranging from -30ΰC (-22F) to +100аC (+212F). For higher temperatures and/or particular applications the use of original FASTER protections made...

▲ FASTER CNV...F series Female coupling with PUSH-PULL connection system complying with ISO 7241-1 part A (CPVSeries), equipped with a lighter spring in the sleeve.In such a way it can be connected as a standard NV series coupling by pulling back the sleeve. Those versions can be produced on request in 08 size with the same threaded ends as CPV Series couplings (see at page 5). For further details contact > Research & Development Dept. > ΢ֲ FASTER CVF...M series > CVF series male coupling equipped with a special threaded sleeve in brass with wing nuts and hexagon shaped interchangeable with...

▲ VF series Agricultural series conforms to ISO 5676 Standards.It is produced to connect the hydraulic brake systems and is used in the whole Europe. The conformity to ISO 7241-A Standards assures a perfect interchangeability between agricultural machines in the world. The most major manufacturers of tractors and agricultural machines in the world. This series of quick-release couplings has been specifically designed and produced for agricultural applications. Most couplings of this series are interchangeable and are used by > For further informationand technical details please ask for the...

/06-GB 4 UNI EN ISO 9001 Cert.n2905 ISO/TS 16949 CAT 0116/0 I - FASTER S.p.A. USA - FASTER Inc. MAUMEE, OH 43537-9505 - 6560 Weatherfield, Ct.(+1) 419-868-8197 - (+1) 800-231-2501 - Fax (+1) 419-868-8360www.fasterinc.com - eng@fasterinc.com I-26027 RIVOLTA DВADDA(CR) Italy - Via L.Ariosto, 7(+39) 0363.377211 - Fax (+39) 0363.377333www.faster.it - faster@faster.it F - FASTER - Franois Divet F-35200 RENNES- 11, Rue Jean Bras(+33) (0) 2.99.51.44.94Fax (+33) (0) 2.99.51.00.13 francois.divet@wanadoo.fr D-BENELUX - FASTER - Jrgen Gamers UK - FASTER - Richard Bennett D-40764 LANGENFELD GER -...
