Introduction
The LSF-Y20 series fiber laser marking machine by HGLaser is designed as a cost-effective and user-friendly solution for various laser marking applications. It is suitable for marking on metals, nonmetals, and plastics, and is particularly useful in high-precision marking tasks.

Features
The machine features a compact, integrated cabinet that saves space and offers high integration. It boasts excellent laser characteristics and pulse shape control, with waveform compensation to enhance pulse energy output. The interface is user-friendly, based on the Windows 7 system, and focuses on intuitive daily applications.

Product Parameters

• Output Power: 20 W
• Marking Range: 110mm x 110mm
• Lifting Mechanism: Manual, 400mm nominal travel
• Wavelength: 1064 nm
• Repetition Frequency: 30~60KHZ
• Beam Quality M2: ≤1.5
• Engraving Line Speed: ≤7000 mm/s
• Min Line Width: 0.2mm
• Min Character Height: 60 um
• Communication Interface: USB, RS232, Network Port
• Power: AV220V/50HZ ±5%
• Power Consumption: 1.0KW
• Operating Temperature: 0°C ~40°C
• Machine Weight: ≤120 KG

Applications
The LSF-Y20 is applicable in various industries including 3C, auto parts, hardware, electronics, medical, and craft gifts. It is used for marking tasks such as keyboard key marking, brand marking, metal scale marking, and QR code marking on car brake discs.

Additional Information
HGLaser offers reliable post-sale services to ensure customer satisfaction and support future task demands. The machine operates similarly to a desktop computer, making it simple, safe, and accurate to use.
