When practicality and innovation unite, then utility takes on a new dimension, and becomes INDISPENSABLE. represents a perfect conjugation of design and technology.The valorisation of human resources, continuous search for the best solution, operative flexibility, ergonomics and an obsession for detail, are our values.Going beyond the customary to establish a new benchmark. FAMATEC Friendly >

Famatec Friendly FamatecFriendly Philosophy >

Famatec Friendly Famatec Friendly is an innovative product that has flexibility as its main advantage. Adapting to any handling need (working height or geometry of the load to be handled), Friendly combines unique practicality with fundamental benefits in reliability, safety and price, all offered by industrialization of the product. Ergonomics, simplicity itself in use and natural movement are the essence of . Supplied with compressed air only, the suction pad grip system offers a quick and safe hold on the part to be handled, adapting with many and rapid adjustments to any shape. Perfect...

FAMATEC Friendly is fitted with a console that's unique in its kind: ergonomic, harmonious in style and pleasant to use. The controls are all simply and intuitively arranged and the operator feels at ease right from the start. He'll be able to exploit all functions to their best and to guide the product safely in any direction with minimum effort. The console can slide along the handle to adapt to the many working situations, letting the operator choose the position that's best for him. > On the console are the controls that adjust the balancing forces to counteract the weight of the...

FAMATEC Friendly Product gripping is quick and safe, thanks to the suction pads, controlled by a highly efficient vacuum system. can handle various product geometries; the suction pads can be quickly adjusted in both directions and/or aligned to take up very long and narrow products. Product release is safe; a special FAMATEC safety device supports the product until it reaches destination before allowing release, avoiding accidents due to incorrect >

Using the two handy controls on the console you can tilt the product to the required angle, with smooth progressive action.The operator can tilt the product from 0 to a maximum of 93а, quickly, efficiently and in complete safety.The maximum tilting angle can be varied and adjusted, speeding up the working cycle in the case of load positioning on inclined carriages.To maximise safety and avoid the operator being struck by the product during tilting, the console moves smoothly, bringing the operator near the load or moving him away from it as necessary. from 0 to 93а >

Product rotation using the gripping system is free and continuous round the axis, thanks to a rotary coupling that avoids twisting the air connection. If product rotation with respect to the gripping tool is needed, the console has practical controls for smooth and progressive pneumatic rotation to the needed position. The operator can rotate the product quickly and efficiently under compressed air power from 0 to 180а while carrying out other operations, thus greatly speeding up the working cycle. >

Product rotation Product tilting >

FAMATEC Friendly can integrate perfectly with the working area where it is positioned. There are many available solutions, and all can be customised on request: column-mounted on a base fixed to the floor, hanging from the ceiling to cover a substantially circular area, a solution with a self-standing base that can be lifted with a fork truck or transpallet to allow easy manipulator positioning, or an overhead system mounted on the user's own or Famatec-supplied supporting structures. For those who need to operate over a large working area, FAMATECFriendly has developed an overhead...

There's a wide range of accessories for FAMATEC Friendly , that can satisfy any need. From quick suction pad adjustment with recirculating ball slides, to a suction pad kit for handling products with very rough surfaces. We also have accessories to customise the unit as to the type of working environment, such as special filters for dusty conditions, or self-standing bases for rapid shift using a transpallet or fork truck. >

Maximum weight :150 kg (FR-V150) 250 kg (FR-V250) Minimum size :1250x450 (800x600) Maximum size :4000x2500 Narrow products :300x4000 Travel allowed : Manual rotation :continuous Pneumatic rotation :180 Tilting :90а adjustable Pad adjustment as to length and width Pad type :double lip. >

FAMATEC UK Ltd loddon business centre roentgen road-basingstoke rg24 8ng - hampshire - U.K. Phone +44 (0) 1256 460706 Fax +44 (0) 01256 460698 FAMATEC S.p.A | Via dell'Industria 15 - 38010 TAIO (TN) ITALIA Tel. 0039 0463 461911 - Fax 0039 0463 461955 >
