www.fam.de Forderanlagen Magdeburg Engineering and Fabrication Under One Roof FAM - Flexibility And More Competency in Modern Opencast Mining Technology ■ Consulting ■ Project Management ■ Scheduling ■ Schedule Monitoring ■ Development ■ Engineering ■ Designing ■ Fabrication FAM is an international organization headquartered in Germany with a proven history as a manufacturer of modern bulk material handling systems and a heritage dating back to the 19th century. We have broad expertise in opencast mining technology, stockyard systems, mineral processing, loading equipment, conveying...

www.fam.de Forderanlagen Magdeburg Turnkey Installations Opencast Mining Equipment ■ Stationary ■ Shiftable ■ Mobile Leach-pad system Copper oxide, copper sulfide 3500 t/h Leached copper ore 4000 t/h Chile Opencast mining system Stockyard capacity 42000 t Red mud tailings 600 t/h Australia Leach-pad system Copper oxide, copper sulfide 3500 t/h Leached copper ore 4000 t/h Chile Mass distributor Overburden 8000 m3/h Coal 5250 m3/h Germany In-pit crushing plant Overburden 3x5250 t/h Uzbekistan In-pit crushing plant Phosphate ore 2300 t/h Overburden 1050 t/h .

www.fam.de Forderanlagen Magdeburg Block Excavation Bench Excavation Opencast mine Bucket wheel excavator SR301R Compact type Bucket wheel 0 7,1 m Cutting height 11 m Excavation depth -0,5 m Drive power of bucket wheel 250 kW Number of buckets 18 Chalk 1500 m3/h, 2040 t/h Germany Opencast mine Bucket wheel excavator SR300R5 Compact type Cutting height 5/10 m Excavation depth -1,4 m Drive power of bucket wheel 315 kW Number of buckets 9 Leached copper ore, copper oxide, copper sulfide 2500 m3/h, 4000 t/h Chile Opencast mine Bucket wheel excavator SR300R5 Compact type Cutting height 11 m...

www.fam.de Forderanlagen Magdeburg ■ Bucket wheel excavators are continuous mining machines for overburden, brown coal or hard coal, marl and other mineral resources, which can be extracted by means of specially designed buckets. Our machines are able to efficiently extract raw materials from deposits of different sizes. In most cases, conveying equipment is integrated into the excavating system to enable the transportation of the material obtained. Bucket wheel excavator SR800P9 Cutting height 9,5 m Excavation depth -0,5 m Drive power of bucket wheel 1000 kW Number of buckets 16 Leached...

www.fam.de Forderanlagen Magdeburg Leach-pad system Crawler-mounted conveyor bridge MSB3480.6TC Tripper car TC1219 Crawler-mounted conveyor bridge MSB3480.9TC Tripper car TC1219 Long distance conveyor LDC1200x2047 Long distance conveyor LDC1200x1660 Copper oxide, copper sulfide 3500 t/h Leached copper ore 4000 t/h Chile Crawler-mounted conveyor bridge MSB6500.7TC With tripper car Centre distance 350 m Belt width 1800 mm Crawler units 7x2 Copper ore 6500 t/h Myanmar Spreader ST2063.45 Boom length 45 m Belt width of boom conveyor 1219 mm (48‘‘) Dumping height 5 m Copper ore 2060 t/h Chile...

FAm www.fam.de Forderanlagen Magdeburg Crawler-Mounted Conveyor Bridges The crawler-mounted conveyor bridges were specifically designed for a continuous dynamic operation to streamline the technological process of piling the ore, reclaiming leached stockpiles and creating new ore stockpiles space-efficiently and in a timely manner. Besides their regular productive deployment in transportation of copper and nickel ores for the dynamic leach-pad systems, FAM mobile conveyors have been found to be perfectly suitable for a different purpose at the landfills for red mud tailings which are...

www.fam.de Forderanlagen Magdeburg Bridging Crawler-Mounted Belt Wagons Belt wagons are standalone machines built on crawlers which serve to transport and discharge the overburden or minerals. In opencast mining these machines are very important links for continuous excavating, transporting and discharging activities especially when mining and dumping areas are spread apart over significant distances. The belt wagons help save on overall investments and operating costs which otherwise would be substantially higher due to the need to acquire larger main equipment. Crawler-mounted transfer...

Förderanlagen Magdeburg Direct Discharge Systems Spreader ST4200.55 Compact type Boom length 55 m Belt width of boom conveyor 1524 mm (60‘‘) Dumping height 6 m Copper oxide 4200 t/h, 2700 m³/h Chile Spreader ST1050.31U Boom length 31 m Belt width of boom conveyor 1200 mm Dumping height 15 m Overburden 1050 t/h Morocco 17 In-pit crushing plant Spreader ST1700.140 Boom length 140 m Belt width of boom conveyor 1200 mm Dumping height 30 m Overburden 1700 t/h, 1380 m³/h Ru

www.fam.de Forderanlagen Magdeburg ■ FAM spreaders mounted on crawlers are utilized in opencast mines for the last step in the continuous dumping process. Spreader ST12100.60 Boom length 60 m Belt width of boom conveyor 1200 mm Dumping height 22 m Overburden 12100 t/h, 8100 m3/h Uzbekistan Spreader ST3500.40 Compact type Boom length 40 m Belt width of boom conveyor 1219 mm (48‘‘) Dumping height 15 m Leached copper ore 3500 t/h, 1950 m3/h Chile Spreader ST1700.140 Boom length 140 m Belt width of boom conveyor 1200 mm Dumping height 30 m Overburden 1700 t/h, 1380 m3/h Russia Spreader...

Förderanlagen Magdeburg Opencast Belt Conveying Systems In-Pit Crushing Systems Conveying system 4x stationary belt conveyors GF1800x190-522 Overburden 1700 t/h Kazakhstan The in-pit crushing plants are used to reduce the size of hard materials for their further transport by conveyors. The crushed overburden is delivered onto the belt conveyor of the crusher’s discharge boom which transfers it further to the mobile conveyor bridge. In-pit crushing system FPB1320-20 On crawlers Apron feeder AF2200x9 Impact crusher PB1320 Stationary belt conveyor GF2000x14 Overburden, chalk-marl-rock 1900 t/h...

www.fam.de Forderanlagen Magdeburg Long Distance Conveyors Vertical and Curved Belt Conveyors22 Long distance conveyor LDC1200x6532 Stationary Belt width 1200 mm Centre distance 6532 m Drive power 1200 kW (3x400 kW) Belt speed 3,1 m/s Limestone 1150 t/h Vietnam Vertical conveyor VC650.150-S S-conveyor Belt width 650 mm Side wall height 150 mm Centre distance 58,3 m Drive power 7,5 kW Belt speed 0,46 m/s Copper ore 50 t/h Chile Long distance conveyor LDC1500x2600 Shiftable Belt width 1524 mm (60‘‘) Centre distance 2600 m Drive power 2000 kW (4x500 kW) Belt speed 4 m/s Copper oxide 4200 t/h...
