Open the catalog to page 1FOD8383 2.5 A Output Current, High-Speed, MOSFET/IGBT Gate Drive Optocoupler in Optoplanar® Wide-Body SOP 5-Pin Features ■ Reliable and High-Voltage Insulation with Greater The FOD8383 is a 2.5 A output current gate drive optocoupler capable of driving medium-power IGBT/ MOSFETs. It is ideally suited for fast-switching driving of power IGBT and MOSFET used in motor-control inverter applications and high-performance power systems. than 10 mm Creepage and Clearance Distance and 0.5 mm Internal Insulation Distance 2.5 A Output Current Driving Capability for MediumPower IGBT/MOSFET – P-Channel...
Open the catalog to page 2VDD – VSS “Positive Going” (Turn-on) VDD–VSS “Positive Going” (Turn-off) ANODE CATHODE Description LED Anode LED Cathode Negative Supply Voltage Output Voltage Positive Supply Voltage ©2014 Fairchild Semiconductor Corporation FOD8383 Rev. 1.0.1 FOD8383 — 2.5 A Output Current, High-Speed, MOSFET/IGBT Gate Drive Optocoupler in Optoplanar® Wide-Body SOP 5-Pin
Open the catalog to page 3As per DIN EN/IEC60747-5-5, this optocoupler is suitable for “safe electrical insulation” only within the safety limit data. Compliance with the safety ratings shall be ensured by means of protective circuits. Installation Classifications per DIN VDE 0110/1.89 Table 1 For Rated Mains Voltage < 150 VRMS For Rated Mains Voltage < 300 VRMS For Rated Mains Voltage < 450 VRMS For Rated Mains Voltage < 600 VRMS Climatic Classification Comparative Tracking Index Input-to-Output Test Voltage, Method b, VIORM x 1.875 = VPR, 100% Production Test with tm = 1 s, Partial Discharge < 5 pC Input-to-Output...
Open the catalog to page 4Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be operable above the recommended operating conditions and stressing the parts to these levels is not recommended. In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability. The absolute maximum ratings are stress ratings only. TA = 25ºC unless otherwise specified. Storage Temperature Operating Temperature Junction Temperature Lead Solder Temperature Refer to Reflow Temperature Profile on page 15. Average Input Current Reverse Input...
Open the catalog to page 5Apply over all recommended conditions; typical value is measured at TA = 25ºC. Input-Output Isolation Voltage Isolation Resistance Isolation Capacitance Units VRMS Notes: 5. Device is considered a two-terminal device: pins 1 and 3 are shorted together and pins 4, 5 and 6 are shorted together. 6. 5,000 VACRMS for 1 minute duration is equivalent to 6,000 VACRMS for 1 second duration. Electrical Characteristics Apply over all recommended conditions, typical value is measured at VDD = 30 V, VSS = Ground, TA = 25°C unless otherwise specified. Input Forward Voltage Temperature Coefficient of...
