2.4Connection, indicating and operating elementsThe interface converter is delivered from the factory pre-installed in the VISY- Command switch cabinet. Prior to the commissioning procedure, only the LON integration must be made according to the following terminal connection plan. Node-ID Setting the user address (NODE-ID) and reset modeS1:Reset modeS2...S8:user address (Node-ID) > Fig. 2: Connection plan LON integration Power Power supply, + 5 V Reset Reset button Coding switch S1 = ON: master reset (following commissioning) Coding switch S1 = OFF: normal reset (during normal operation) >...

Open the catalog to page 6

JP2-Boot For manufacturing purposes only; during normal operation, the jumper must be open JP1-Service For testing purposes only; during normal operation, the jumper must be open LED Service LED OFF:trouble-free operation LED flashing:defect on the interface converter LED TX-LON Lights up when the interface converter sends a message via the LON bus. LED RX-LON Lights up when the interface converter receives a message sent to it via the LON bus. LED Status LED OFF:trouble-free operation LED flashes once:disturbed communication of the interface converterwith the interface card VI-..., may...
