faac J275 Mobile solutions for vehicle access control and city traffic

FAAC J275 MOBILE SOLUTIONS FOR ACCESS CONTROL AND URBAN TRAFFIC. FAAC J275 is a highly impact- and weather-resistant metal cylinder, equipped with a piston mechanism to allow controlled movement. It is housed in a specially designed compartment placed in the road paving for use as a traffic and/or parking bollard. FAAC J275 offers help and an intelligent solution as an alternative to fixed stations, gates, barriers, chains and other, making it possible to regulate vehicle entry and/or exit in certain areas and prevent unauthorised parking. The bollard therefore covers multiple uses: it...

Truly innovative and unique bollard FAAC J275 is characterised by its high innovation content and, compared to the traditional bollards currently being sold, it features many important advantages. J275 was specifically designed to minimise the complexity and burdens of the excavation, installation, accessibility and maintenance stages: 1. Mobile hydraulic unit integral with the cylinder 2. High resistance steel structure 3. Fast moving cylinder 4. “Fully optional” version including all main accessories 5. Lowered maintenance costs, due to one man servicing 6. Flexible control unit that...

FAAC j 275 Automatic version DISAPPEARING TRAFFIC BOLLARD - Hydraulic FAAC J275 Automatic disappearing traffic bollard is recommended in situations of heavy daily transit. It can be controlled automatically using commands carried out by authorised persons (cards, remote controls, etc.) or using automatic set time commands. The device is equipped with a single-effect hydraulic drive. Available versions Painted steel standard versions • FAAC J 275/600 HA painted steel - steel cylinder 7 mm thickness treated by cataphoresis and painted - powder painted dark grey metallised RAL 7021 -...

(*) By emergency release activation • Pit heater JH 275 (to extend operation up to -25°C) • Control unit JE 275 (up to max n. 4 bollards)

DISAPPEARING TRAFFIC BOLLARD - Semi-Automatic This type of bollard is recommended in cases when accesses are limited, or when used together with the automatic version. This bollard solves transit/stopping problems without requiring electricity. With its single-effect, gas-powered spring, raising is done automatically by key release and lowering is done by ap- plying slight pressure with the foot to the head of the bollard. AVAILABLE VERSIONS PAINTED STEED STANDARD VERSION • FAAC J275/600SA painted steel -steel cylinder 7mm thickness treated by cataphoresis and painted -powder painted dark...

FAAC J275 Fixed version TRAFFIC BOLLARD-Fixed FAAC J275 Fixed bollard is suitable for installations when all bollards don't need to be automated. The fixed bollards can maintain aesthetic appearances for sites, thus reducing costs and time of installation. AVAILABLE VERSIONS PAINTED STEEL STANDARD VERSIONS • FAAC J 275/600 F painted steel - steel cylinder 4 mm thickness treated by cataphoresis and painted - powder painted dark grey metallised RAL7021 • FAAC J 275/800 F painted steel - steel cylinder 4 mm thickness treated by cataphoresis and painted - powder painted dark grey metallised...
