EXstatic 311
2Pages

Catalog excerpts

Process Equipment EXstatiC 311 TriClamp connection Designed according to hygienic criteria Surface finish Ra<0,78 or Ra<0,37 Stainless steel AISI 316L / 1.4404 EPDM sealings with FDA and USP VI approval Optional sensor protection cage Up to 10 bar and 140 °C Protection cap for cable connection Static probe housing with T riClamp connection for permanent installation of 012mm/12Omm-sensors in tanks or pipes max. pressure max. temperature material surface sealing material material cable guard certificates option sensors process connection 10 bar 140°C 14404 / 316L Ra<0,78 or Ra<0,37 EPDM / FDA / USP VI or FPM (Viton) PA6.6 GF30 material, surface, sealing material with protection cage or without protection cage 120mm / PG13,5 TriClamp 1.5" (050,5) or TriClamp 2" (064) Exner Process Equipment GmbH //CarL-Metz-Straf$e 26 // 76275 EttLingen // Germany fon +49 (0)7243-94 54 29-0 // fax +49 (0)7243-94 54 29-99 u mail info@e-p-e.de Geschaftsfuhrer: MichaelTottewitz, Detlef Exner//Amtsgericht Mannheim, HRB706 588 u Ust-ldNr. DE264742343

Open the catalog to page 1

Ordercode Code Material (wetted parts) 0408 Stainless Steel 14404 / 316L Ra0,78 Code Sealing material (wetted sealings) EPD EPDM/FDA/USP VI Code Sensor type 120 120mm PG 13,5 012mm Code Process connection TC15 TriClamp 1-1,5" (OD 050.5mm) Code Immersion length 045 45mm under process connection 080 80 mm under process connection Code Protection cage 0 without 1 with protection cage >x<EXNER Process Equipment Delivery 2 weeks 4 weeks Delivery 2 weeks 2 weeks Delivery 2 weeks Delivery 2 weeks 2 weeks Delivery 2 weeks 2 weeks Delivery 2 weeks 2 weeks Exner Process Equipment GmbH...
