EVI-IHM-INOX (US)

Product catalog summary

Specifications:

Display Options: Available in sizes 12.1", 13.3", 15.6", 21.5" for the stainless steel display, and 12.1", 15", 17", 19", 21.5", 23.8" for the waterproof monitor.
Touch Technology: PCAP Touch and Resistive touch are optional, with optical bonding PCAP touch and surface hardness of ≥7H.
Temperature Range: Operating temperature from -20°C to 70°C (-4°F to 158°F) and storage temperature from -30°C to 80°C (-22°F to 176°F).
Humidity and Vibration: Relative humidity of 5%~95% at 40°C, non-condensing, and vibration protection of 1.5 Grms according to IEC 60068-2-64.
Power Specifications: Power consumption is ≤30W, with an optional AC/DC 12V/5A, 60W power adapter. Power input via SP13 or M12 waterproof connectors for 12V~24V DC.
Environmental Protection: Full IP66/IP69K protection against dust and water.
EMC Compliance: Certified with CE, FCC Class A, and ROHS standards.

Features:

Anti-static protection with 8KV~15KV rating.
Low power consumption design.
24/7 operational capability with OVP (Over Voltage Protection), OCP (Over Current Protection), and RPP (Reverse Polarity Protection).

Connectivity:

Video: 1 x Waterproof Connector for HDMI/VGA (optional).
USB: 1 x SP13 or M12 Waterproof Connector for Touch USB2.0.
Other Interfaces: Includes a power switch.

Catalog excerpts

Industrial Monitor Waterproof Monitor PCAP Touch / Resistive touch(Optional) a Be Stainless Steel Display PCAP Touch / Resistive touch(Optional) LCD Size: 12.1" / 13.3" / 15.6" / 21.5" (Optional) Full IP66/IP69K -20C~70C OVP / OCP / RPP 7/24 Working

Open the catalog to page 1
