‘PAN-Ceph’ Application

Introduction Optimal radiographic results with maximum simplicity and safety, can nowadays be obtained against restraint costs thanks to a new control board technology. EVER ELETTRONICA's many years of experience in multiple motor equipment and variable projections stand for reliability and high diagnostic performances. Thanks to the DRK control board, a complete, modern and versatile system for the control of 4 interpolable axles, all radiographic projections of mayor interest can be realized..

The EVER ELETTRONICA control board consists of the following components: Digital 4 and analog I/O NVRAM for backup data (statistics, technical factors...) 5 3 Display LED control Interface and 2 buttons on control panel. 1 Interface control card X-ray D Control Ceph axle C Control cassette axle X Axle control for the bringing near to and the removal from the column. B A Control rotation axle Number and name 4 Components of the control board

Points of strength The knowledge which EVER ELETTRONICA acquired in the dental radiography sector in the past years, resulted into a concentration of all requirements of this sector in one single card. The innovative solution, shaped by the different needs, serves to create several programs, from simple panorama / cephalometric tests to TMJ tests, all in compliance with the existing regulations for electromagnetic compatibility and emissions. All this to ensure the user of a user-friendly system providing excellent results at the highest level. Points of strength of the EVER ELETTRONICA...

Points of strength – electronic CAM Points of strength of the EVER ELETTRONICA solution: Control of up to 4 interpolable axles with a precision of a hundredth of degree: „Ï Rotation Axle; „Ï X Axle (bringing near to and removal from the column); „Ï Casette Axle; „Ï Ceph Axle;

K:\VP8\2855_SensSysP\2855_Eng.vp tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:15.00pt "Tahoma", sans-serif; } .font1 { font:30.00pt "Tahoma", sans-serif; } Points of strength - (dental?) test programs Points of strength of the EVER ELETTRONICA solution: : Definition of any interpolation or CAM profile between the 4 axles for the execution of tests: ^ Panorama adult and child ^ Maxillary sinuses (left and right) and frontal ' Temporomandibular articulations with open or closed mouth ' Lateral - lateral ' Antero-posterior ' Carpo and Ceph ' Customized features on customer...

K:\VP8\2855_SensSysP\2855_Eng.vp tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:15.00pt "Tahoma", sans-serif; } .font1 { font:30.00pt "Tahoma", sans-serif; } Points of strength - tecnical factors, statistics Points of strength of the EVER ELETTRONICA solution: ^ PWM management for the dynamic adjustment and modulation of the tecnical factors KV, MA, S Pulses control for digital CCD sensor ' Control programmable filter soft parts Control Real time clock for the temporary events storage Storage of the machine alarms in a retentive buffer (16 alarms) ' Storage of machine...

Points of strength – Card programmability Points of strength of the EVER ELETTRONICA solution: The control board is programmed by means of the programming environment TRIPOS IEC1131 which is characterized by: „Ï High level debugging „Ï Control window events and parameters „Ï PC monitor „Ï Serial interfaces „Ï 32 bit Arithmetic & floating point and trigonometric functions „Ï Commands control „Ï 256 user variables allocated in a backup memory „Ï 8k retentive variables …….and many more Contact EVER ELETTRONICA for more information. Mail to : infoever@everelettronica.it
