"COMFORT 2006" catalogue
128Pages

1999. The civil and industrial sector were sold and taken over by new shareholders. Euroklimat was formed, concentrating on the production of industrial cooling and air-conditioning systems. The technological experience, the in-depth knowledge of the market and the ability to respond with flexible products to the varied and specific customer requirements soon put Euroklimat on the international map: more than 60% of its products were exported. Euroklimat products with their high technological impact also stood out for the energy saving features and respect for the environment. Euroklimat...

INDEX euroklimat PRODUCT RANGE CATEGORY TYPE AND SIZE FEATURES REFRIGERANT PAGE Close control Close control air conditioners air conditioners BXK.O A031 E ÷ G302 E OVER - Remote Air Cooled condenser R-407C 08 AXK.O A031 E ÷ G262 E OVER - Water Cooled condenser R-407C 09 BXK.U A031 E ÷ G302 E UNDER - Remote Air Cooled condenser R-407C 10 AXK.U A031 E ÷ G262 E UNDER - Water Cooled condenser R-407C 11 DXK.O A031 X ÷ G251 X OVER - Evaporating Units R-407C 12 DXK.U A031 X ÷ G251 X UNDER - Evaporating Units R-407C 13 CWK.O A010 W ÷ G100 W OVER - Chilled water units 14 CWK.U A010 W ÷ G100 W UNDER...

INDEX euroklimat PRODUCT RANGE CATEGORY TYPE AND SIZE FEATURES REFRIGERANT PAGE Air conditioners Free standing evaporating units and Roof Top DXK.O A031X ÷ G251X OVER R-407C 70 DXK.O/PC A031X ÷ G251X OVER R-407C 71 DXK.U A031X ÷ G251X UNDER R-407C 72 Free standing chilled water units CWK.O A010 W ÷ G100 W OVER 73 CWK.U A010 W ÷ G100 W UNDER 74 High capacity air conditioners BIK.O 0202 E ÷ 0702 S OVER - Remote Air Cooled condenser R-407C 75 AIK.O 0202 E ÷ 0702 S OVER - Water cooled condenser R-407C 76 Roof Top RTK.E 0071 E ÷ 0302 E Scroll Compressors R-407C 77 RTK.E/PC 0071 E ÷ 0302 E Scroll...

ifi i.:jj.i.jjj!j:i:i..i.::r,ii,.iI!i..!Iu:. ,i.!i!!!::iM!j",:vj!.:.v - ■ ^. : i ■ : 11 ^. ? i ■ i - ■..!■.^:li. ■ i ■ ^ : ■ ".:ii.-SiiMu!^.11""-■'-! l!...J.:.n:,.^:V..^:i:.,: i:i.:ii!iij.:j:j:i;u:u.:j!!j:i:i! i \\i.:.!11.!.:..!.viiv.,y...iV ii,,i:!!.,:,.,.i!!".ii.:.'iv',:i.v ■irillliկlHliﯮVjlJblLIliilLj J,.;'jMJJJ.L!U"ij﯏'!j^jV, ,:.ii,,'IiIi-!i!!j!.!iI-^!i^Vj ■

www.euroklimat.it 8 • Fan driven by belt (from size C) • F5 filter • Special filter plenum for air outlet • Air outlet plenumRoom thermostat • Air damper • Water heating coil • Electric heating coil. • Compressor power-factor capacitor • Contacts for smoke/fire alarm • Upgrading electronic control • Clock board • Serial interface board • Water on the bottom alarm • Dirty filters alarm • Low air flow alarm • Solenoid valve (up to 6HP) • Compressor insulation • Sound absorber plenum for air outlet • Vibration isolation frame with bearings • ON/OFF condensing control • High dehumidification...

www.euroklimat.it 9 C065 E C081 E C091 E D082 E D102 E D122 E E122 E E132 E E162 E F182 E G182 E G202 E kW 25,9 29,4 33,9 35,4 37,8 44,3 48,3 50,3 57,4 67,8 71,8 81,4 kW 25,4 28 32,5 34,7 35,6 41,7 47,4 48,2 55,2 63,7 70,4 76,6 0,98 0,95 0,96 0,98 0,94 0,94 0,98 0,96 0,96 0,94 0,98 0,94 n°xkW 1x5,5 1x5,2 1x5,6 2x2,7 2x3,5 2x4,0 2x4,0 2x4,5 2x5,2 2x6,1 2x6,1 2x7,1 A 11 12 11 10 14 15 15 18 24 27 27 28 n° 1 1 1 2 2 2 2 2 2 2 2 2 m3/h 8200 8200 8200 10500 10500 10500 14000 14000 14000 16000 20000 20000 Pa 100 100 100 100 100 100 100 100 100 100 80 80 n°xkW 2x0,5 2x0,5 2x0,5 3x0,5 3x0,5 3x0,5...

www.euroklimat.it 10 1 solution T - Technological 2 versions ST - Standard SP - Special 1 equipment AS - Standard equipment BXK.U euroklimat • Housing: Base made of painted galvanised steel; frame complete with service panels designed to grant proper operation during maintenance. The aestethic panelling, externally coated with an innovative double plastic film, is internally lined to reduce the noise level. • Compressor: HERMETIC SCROLL type, complete with thermal protection and rotalock fittings (from 7,5 HP size); mounted on antivibration mountings and complete with oil charge. • Fan:...

www.euroklimat.it 11 CLOSE CONTROL AIR CONDITIONERS Centrifugal Fans One and Two SCROLL Compressors - One and Two Circuits Water Cooled condenser Downflow • Fan driven by belt (from size C) • F5 filter • Special filter plenum for air outlet • Air outlet plenum • Motorized air dumper • Water heating coil. • Electric heating coil • Pressostatic valve • Compressor power-factor capacitor • Contacts for smoke/fire alarm • Upgrading electronic control • Clock board • Serial interface board • Water on the bottom alarm • Dirty filters alarm • Low air flow alarm • Compressor insulation • Sound...

www.euroklimat.it 12 DXK.O euroklimat Technical data referred to: Standard version with direct expansion coil - (1) Inlet air 24°C, 50% rH - Evaporating temperature 5°C - (3) Sound pressure at 1 m in open field. CLOSE CONTROL EVAPORATING UNITS Centrifugal Fans Upflow EX Unit - Extra Coil R134a R407C Ecological gas High efficiency ecological gas R22 Efficient gas • Housing: Base made of painted galvanised steel; frame complete with service panels designed to grant proper operation during maintenance. The aestethic panelling, externally coated with an innovative double plastic film, is...

www.euroklimat.it 13 DXK.U euroklimat Technical data referred to: Standard version with direct expansion coil - (1) Inlet air 24°C, 50% rH - Evaporating temperature 5°C - (3) Sound pressure at 1 m in open field. CLOSE CONTROL EVAPORATING UNITS Centrifugal Fans Downflow EX Unit - Extra Coil R134a R407C Ecological gas High efficiency ecological gas R22 Efficient gas C101 X D122 X D132 X E132 X E182 X F182 X G202 X G262 X kW 34,0 37,4 43,5 48,3 58,1 65,3 69,3 83,0 kW 32,3 35,6 40,9 47,4 54,6 60,9 67,3 77,2 0,95 0,95 0,94 0,98 0,94 0,93 0,97 0,93 n° 1 2 2 2 2 2 2 2 m3/h 8200 10500 10500 14000...
