• System: Utilizes Intel® Meteor Lake processor with support for Windows 10, Windows 11, and Linux operating systems.
• Memory: 1 x SO-DIMM, DDR5 5600MHz, up to 32GB.
• Storage: Options include 1 x M.2 M Key 2280 (NVMe/SATA) and 1 x 2.5" SATA3.0.
• Display: Supports four displays via 2 x HDMI 2.0 and 2 x Type-C ports.
• USB Ports: Includes 2 x USB3.2 Gen2 Type-A and multiple Type-C ports with 4K@60Hz support.
• Communication: Features dual LAN ports (Intel I219-LM and I210) and RS232 support.
• Expansion: 1 x M.2 E Key 2230 for WiFi & Bluetooth.
• TPM: TPM 2.0 for enhanced security.
• Watchdog Timer: Programmable from 1 to 255 levels.

• Easy installation via DIN rail.
• Power input of DC 19V with a consumption of 46.35W.
• Compact dimensions of 120.0x120.0x53.8mm and a net weight of 0.91kg.
• Operating temperature range from -5 to 45℃.
• Storage temperature range from -20 to 70℃.
• Relative humidity tolerance of 5% to 95% at 40℃ (non-condensing).
• Vibration and shock resistance compliant with IEC standards.
• EMC compliance with CE/FCC Class A.

• CPU options include Ultra 5 125H, Ultra 5 135H, and Ultra 7 155H with varying core counts and base frequencies.
• Memory options range from 8GB to 32GB DDR5.
• Storage options include M.2 SSD and 2.5" SATA3.0 with capacities from 128GB to 2TB.

The product measures 120.00 mm in width and height, with a depth of 53.80 mm.

Estone Technology has offices in the U.S. (West Coast and Headquarters), Europe, and Japan.
