Mise en page 1 (Page 1) tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:9.00pt "Arial", sans-serif; } .font2 { font:13.00pt "Arial", sans-serif; } .font3 { font:12.00pt "Times New Roman", serif; } .font4 { font:23.00pt "Times New Roman", serif; } Key technoiogy lor ensuring reiiaDinty Supports the current trend toward higher stress. High accuracy is increasingly demanded in the pursuit of reliability in the field of electronics. "Liquid-to-liquid" type thermal shock testing is now attracting attention for its ability to impose higher...

Mise en page 1 (Page 1) tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:9.00pt "Arial", sans-serif; } .font3 { font:10.00pt "Arial", sans-serif; } .font4 { font:11.00pt "Arial", sans-serif; } .font5 { font:8.00pt "Times New Roman", serif; } .font6 { font:10.00pt "Times New Roman", serif; } .font7 { font:19.00pt "Times New Roman", serif; } Utility 9 A number of mechanisms for drastically reducing brine consumption To reduce brine consumption, the airtightness of the test area has been enhanced...

‚R Utility Energy savings achieved Dramatic energy savings have been achieved through the adoption of a new refrigeration circuit, with power consumption slashed by as much as 52% (compared to former ESPEC models). Installation environment improved through reduced operation noise The operation noise level of the chamber has been reduced to as low as 61 dB (A-characteristic) by providing soundproofing panels for the noise-emitting machine compartment, including the refrigerator. HFC refrigerant used to protect the global environment HFC refrigerant that causes no damage to the ozone layer is used...

‚S Uses a color LCD interactive touchpanel system employed throughout the Thermal Shock Chamber Series A color LCD panel design allows settings to be made simply by touching the screen in accordance with the display. The test pattern, test area temperature, number of temperature cycles, trendgraph display, etc., are all displayed on the screen. Control operation Visibility and ease of use improved through interactive input using a touch-screen system and color LCD screen ..

Mise en page 1 (Page 1) tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:6.00pt "Arial", sans-serif; } .font1 { font:7.00pt "Arial", sans-serif; } .font2 { font:10.00pt "Arial", sans-serif; } PECIFICATIONS Model TSB-21 TSB-51 System Two-liquid bath System with spcimen basket transfer Brine Single-liquid or double-liquid fluorine deactivated brine ent Power supply (within ±10% of the rated voltage) 200V AC, 3<p, 3W, 50/60HZ ■em Maximum load current iquii Operating temprature 0 to +40°C (+32 to +104° F) >> Air-source pneumatic pressure 0.4 to 0.7MPa (4 to 7kgf/ cm2) Utilil Air-source...

‚U TEST STANDARDS (satisfied by all models in the TSB Series) .. ..

OPTIONS Specimen basket Equivalent to standard accessory. EMaterial Stainless steel (5-mesh) Caster Installed for mobility. EFree wheels: 4 Fixture for securing the body Used to bolt the chamber to the floor. Built-in air compressor Equipped when there is no air supply source. Temperature recorder (Digital display) |100 to {220Ž/ 100 mm RK-61: 1-pen RK-63: 3-pens RK-64: 6-dots Emergency stop switch Stops the chamber immediately. For future installation of a recorder If the user elects to prepare a custom temperature recorder or plans to add one at a later date, the necessary power cable, temperature...
