Industrial Automation www.esahmi.com

your hands Making industrial processes simpler, safer and more productive Established in 1975 in Italy, ESA elettronica is now a multinational company with 37 years’ experience in the field of Industrial Automation. It has foreign branches strategically located in important countries around the world and agents in over 40 nations, offering friendly, attentive customer service and impeccable post-sales assistance. We aim to always to provide the very best solutions for controlling industrial processes in as straightforward, secure and productive a manner as possible. We design all of our...

ESA solution In a world where communication boundaries are constantly evolving, people need to analyse and process a large amount of information before making important decisions in an increasingly shorter amount of time. Our aim is to meet this requirement by offering a “truly successful solution”, not only through state of the art hardware and software products, but also through expertise support by means of our professional, timely and friendly aftersales service. Touch-screen operator terminals and terminals with keypads permitting unrivalled connectivity (in industrial environments and...

Specialist A history characterised by the entrepreneurial spirit and dedicated to offering only the best: 1975 The company was established with the name Tecno System by 4 partners. Year after year, it constantly grew in the electrical equipment manufacturing sector. ESA elettronica was founded and supported Tecno System in the development of electronic equipment, in both custom and made-to-order, for industrial machinery ESA elettronica launched its first range of HMI products (human-machine interfaces) moving away from made-to-order production and focusing on solutions fully meeting all...

ESA Software & Automation India Pvt. Ltd. Bosnia Herzegovina Czech Republic Costa Rica South Korea United Kingdom Saudi Arabia South Africa United Arab Emirates Asia, India and Australia Africa and Middle East For an updated list of the available countries and distributors please visit www.esahmi.com

6 keys 'g 49 keys | 320x240 IL^P 320x240 I 25 keys " j^^B Monochrome "' 4 tones of blue |°MJ 320X240 ESA's HMI family is a complete range of flexible, universal operator terminals, that can meet any automation requirement. The use of specially designed materials as well as the complete absence of moving mechanical parts (ie: fans and Hard Disks) make ESA terminals extremely robust and perfectly suitable for use in industrial environments and in harsh operating conditions (such as in area with a high concentration of dust or intense vibrations).

The ESA series 5,7”>7” IT105BK 5,7“ STN 320x240 16 tones of blue VT560W 5,7” STN 320x240 8 tones of blue /16 colors VT565W 5,7” STN 320x240 8 tones of gray /256 colors Programming software

IT107W 7“ 800x480 65.536 colors Available with stainless steel front panel

12,1“ TFT 800x600 65.536 colors Available with stainless steel front panel

State of the art industrial displays with strong backlight and White-LED or CCFL technology Option to use any terminal in the IT range both horizontally and vertically IP66 protection of the entire front part IP66 No moving mechanical parts, (ie: fans and Hard disks) RAM memory up to 128 MB and internal Flash memory up to 64 MB Front USB port with IP66 protection for connecting peripheral devices and for easy data import/export (available only on IT115 models) Wide Viewing Angle Technology allowing perfect view of the display from any angle 4 or 5-wire resistive touch-screen that ensures...

IT series features Second serial port SP2 (RS232/RS485 with integrated MPI) CAN, Profibus-DP or ProfiNet interface Extended range power supply 18...32 Vdc with very low power consumption Second slot Compact Flash memory connection (available only on IT110, IT112 and IT115 models) Slot for Secure Digital and MultiMedia Card (MMC) memory connection 10/100 Mbit Ethernet port (double Ethernet port available on IT110, IT112 e IT115 models) allowing for management of two different protocols simultaneously on each port SP1 serial port (RS232/RS485 with integrated MPI) equipped with its own...

Data collection and processing The operator panels in the IT range can be connected to a production plant and the production data can be exported directly to a remote PC through the integrated Ethernet port. Just indicate the names of the variables to be monitored and, when necessary, their values are automatically read by the PLC and processed directly in a CSV file. In addition, the file can be saved on removable media devices automatically or on a shared folder on a remote PC. It’s also possible, directly from HMI panels, to export any data toward the most common relational databases,...

Compact Flash Secure Digital PLC devices SP2 (RS-232, RS-485 and MPI), CAN, Profibus-DP or ProfiNet Drivers for the following manufacturers ABB Modbus (Serial), AC550 PM (Codesys) Allen Bradley Micrologix 1500, Ethernet IP Micrologix-Contrologix PLC5/Contrologix 5 series, AB Ethernet Hitachi Keb Kernel Sistemi Kuhnke EH150, H250-252-B-C, H302, H702, H1002-2002-4002 F0-F4-C-FAF-F4S-S4 Series Combivert F5-Eth CombiControl C5(Tcp/IP Codesys) Kernel protocol Kubes, Ventura (serial Codesys), Ventura 100 PLC (Tcp/IP Codesys) Ventura Skaleo (Tcp/IP Codesys) A series, FX Series, FX2 Series...

IT104G Display Technology Colours/levels Size Resolution Backlight 65.536 colors 4,3” 480 x 272 pixel White LED Life (min. at 25 °C) Touch screen Terminal Processor CPU clock RAM Flash Interfaces First port Second port Network USB Host port USB Device port CardBus slot Dimensions External (W/D/H) Cut-out (W/H) Technical specifications Power supply Power consumption Operating temperature Storage temperature Humidity Hardware clock Weight Protection level Certifications Programming software 166 x 112 x 31 (mm) (50 with double port) 157 x 103 (mm) 18...32 Vdc ~ 7 W (24 Vdc) 0...+50 °C...
