E-Z TEC® METAL DETECTORS MD-205X ®

® 2 The E-Z Tec® DSP Metal Detector is an extremely sensitive instrument used to detect the presence of ferrous and nonferrous metals. All industries which need product purity need metal detectors. The list of examples is almost endless, and includes food, textile, rubber, plastic, wood products, chemical, cosmetic, pharmaceutical and many other industries. Besides the obvious benefit of product purity, the metal detector will also protect downstream equipment from damage caused by metal in the product stream. Metal can enter the production process with the raw material or can get into the...

® 3 APERTURE MODELS SINGLE SURFACE MODELS VERTICAL DROP APPLICATIONS CONTROL SYSTEMS MECHANICAL CONVEYOR MODELS LIQUID FLOW APPLICATIONS PHARMACEUTICAL MODEL

® 4 Aperture Models Eriez E-Z Tec® DSP Metal Detectors are extremely sensitive instruments used to detect ferrous, non–ferrous and stainless steel metal contaminants. The advanced digital signal processing provides customers in the food, textile, pharmaceutical, rubber, chemical, and many other industries, with a unit designed for optimum performance and improved product purity. Another highlight of E-Z Tec DSP Metal Detectors is the easy–to–use Touch Screen (1/4 VGA) Interface. The 4–inch (101 mm) high x 5–inch (127 m) wide angled control, with a backlit screen, allows the user to quickly...

® 5 The E-Z Tec DSP SlimTec Aperture Model provides the same highly sensitive detecting capabilities as the E-Z Tec Aperture Model, in a design better suited to certain products and factory situations. It is particularly effective for detecting metallic contaminants in wide, thin products, such as plastics, rubber, wood, woven materials and particle board. The narrow profile and reduced metal– free area of the unit permit it to be installed in areas with limited space and with little isolation of any surrounding equipment. The oscillator and receiving coils are wound on a rigid frame and...

® 6 Single Surface Models The E-Z Tec DSP SlimTec Single Surface Model provides highly sensitive detecting capabilities in a design effective for detecting metallic contaminants in wide, thin products. The flat–surfaced detection area is positioned beneath the product or conveyor belt. This design can accommodate materials such as sheet plastics, wood, rubber, woven materials and particle board. The SlimTec is also ideal for inspecting liquids in metal– capped bottles. The unit’s oscillator and receiving coils are wound on a rigid frame and encapsulated within a painted, rectangular...

® 7 Eriez’ E-Z Tec DSP Flat Bed Single Surface Metal Detector is ideal for a number of applications, products and working environments. The produced electromagnetic field is greater than a standard E-Z Tec DSP single surface metal detector, thus offering increased protection against metal contamination further from the coil surface. It is particularly effective for detecting metallic contaminants in large or oversized applications. The flat– surfaced detection area is positioned beneath the belt or conveyor. This design can accommodate materials such as sheet plastics, wood, rubber, woven...

® 8 Vertical Drop Models Vertical Form, Fill and Seal (VFS) Eriez’ E-Z Tec® DSP Vertical Form, Fill and Seal (VFS) Metal Detectors are excellent for detection of ferrous, nonferrous and stainless metal contaminants. The E-Z Tec® DSP VFS Metal Detector will help improve product purity for products processed in Form Fill Seal Equipment and other applications where vertical heights are extremely restricted. The overall height of the metal detector can be either 4 or 6 inches. ELECTRONICS The E-Z Tec DSP VFS Metal Detector’s electronics are remote and can be mounted up to 100–feet (30m) from...

® 9 Eriez’ E-Z Tec® DSP Low Profile Vertical Reject LPVR Metal Detectors are excellent for detection and removal of ferrous, nonferrous and stainless metal contaminants in gravity fed dry powder or granulated products. These low profile units accommodate many applications with restrictive height requirements. The combination of negligible metal–free area and quick acting chute reject valve (optional) design provides a minimal height system. Upon detection, the E-Z Tec DSP Low Profile Metal Detector will activate a specially designed chute–type reject valve to remove the contaminant from the...

® 10 Eriez’ E-Z Tec DSP Narrow Profile Liquid Line Metal Detectors are used to detect the presence of ferrous, nonferrous and stainless metal contaminants in viscous products such as liquids, slurries, syrups, pastes and many other pumped products. When metal is detected in the product flow, a reject signal is channeled to one of the available output relays. The output relay can be used to activate a ball valve, control a visual or audio alarm, or send a signal to a PLC. In addition to enhancing product purity, Eriez E-Z Tec DSP Liquid Line Systems can protect vital downstream equipment...

® 11 Eriez’ E-Z Tec® DSP Pharmaceutical Gravity–Fed Metal Detector has been designed for the detection and removal of minute pieces of ferrous, nonferrous and stainless steel contaminants in tablets and capsules. This highly sensitive, compact designed metal detector system meets stringent FDA standards and accommodates space–restricted areas within tablet and encapsulation rooms. Eriez’ pharmaceutical unit has been engineered with an adjustable sensing head and has one of the largest and easiest to clean product chutes in the industry to optimize efficiency. The adjustable support stand...

® 12 CONTROL, MOTOR AND POWER OPTIONS • Central control NEMA 4x (STD) NEMA 7 and 9 • Control with start/stop switches for the conveyor. • Variable speed motor • 120/240V • Various HP and special motors ALARM AND REJECT DEVICE OPTIONS • Air blow off • Pusher arm • Diverter arm • Flip gates (standard and adjustable) • Belt reversing • Retractable head pulley • Horn and/or beacon • Stoppage of belt • Reject confirmation BELT AND FRAME OPTIONS • Sided and/or cleated belts • Plastic chain or vulcanized belts • Widths up to 84 inches (2134 mm) • Lengths 3 to 26 feet (1 to 8 m) • Stainless steel...
